Chain/Belt Tension; Remote Battery Replacement; Light Bulb Replacement - Genie Single Programming, Operation & Maintenance Manual

B - Chain/Belt Adjustments
If excessive chain/belt sag is noticed below the rail:
1. Open the door until carriage is about mid travel and stop.
2. Disengage the carriage and manually close the door.
3. Loosen nuts on turnbuckle using 7/16" wrenches.
4. Rotate turnbuckle counter-clockwise until slack is removed from chain/
belt.
5. When measured on the opposite side of the rail from the turnbuckle, a
properly adjusted chain/belt will have a 1/4" gap to the bottom of the rail.
6. Tighten nuts to secure turnbuckle.
7. Be sure that chain/belt is not twisted or bound.
8. Manually open door to re-engage carriage to turnbuckle.
C - Changing Remote Batteries
Remote Battery Replacement (1-button)
Replace remote battery with a CR2032 coin cell battery.
1. Slide the battery cover off.
2. Slide out the old battery and slide in the new. Be sure positive side (+) is UP.
3. Slide the battery cover on until it snaps into place.
Remote Battery Replacement (3-button)
Replace remote battery with a CR2032 coin cell battery.
1. Open remote case using a washer or coin that fits into the slot on the top of the remote.
2. Replace battery. Be sure positive side (+) is UP.
3. Align components and snap case closed.
D - Changing Lightbulbs
WARNING
!
• Use extreme caution when working from a ladder or step
stool or serious injury can occur.
• When replacing light cover, make sure wires are not pinched
or near moving parts.
• Use only properly rated incandescent, LED or CFL light bulbs.
• DO NOT use bulbs with a rating greater than 60 Watts.
• Use A19 size light bulbs. DO NOT use bulbs having a short
neck.
1. Disconnect power to opener.
2. Open powerhead lens covers by pressing down on upper locking tabs and pull away from powerhead.
3. Replace old light bulbs with 60 Watt MAXIMUM. incandescent, CFL or LED equivalent**.
* Genie LED light bulbs, which are specifically made for garage door openers, are recommended.
4. Install lens cover(s).
5. Reconnect power to door opener.
6. Test light operation.
NOTE: Use of standard LED bulbs may reduce the range of your remote controls*.
1 Light Models
Push down tabs
Pull light cover away from powerhead
Models equipped with LED lighting require specialty kits available for order in the
parts section.
**Integrated Aladdin Connect® models require a MINIMUM 40 Watt or equivalent
bulb, 60 watt maximum.
16
• Faire particulièrement attention lors de travaux effectués
depuis une échelle ou en escabeau.
• En referment le couvercle de l'éclairage, s'assurer que les fils
ne sont ni coincés ni près des pièces mobiles.
• Utilisez uniquement incandescence correctement classé, LED
ou des ampoules fluocompactes.
• NE PAS utiliser des ampoules avec une note supérieure à 60
Watts
• Utilisez A19 ampoules de taille. NE PAS utiliser des ampoules
ayant un cou court.
2 Light Models
Push down tabs
Pull light covers away from powerhead
AVERTISSEMENT
!
* Genie LED light bulbs are
designed to reduce or eliminate
reduced remote range issues
caused by common LED bulbs.
They also offer better product
life by making them resistant to
vibration caused by the opener,
and cold or damp weather. See
website for details at
www.GenieCompany.com.
1/4"
