- Page 1 ROTARY ORBITAL SANDER MODEL NO: CROS1 PART NO: 6462010 OPERATION & MAINTENANCE INSTRUCTIONS GC0913...
-
Page 2: Specification
INTRODUCTION Thank you for purchasing this CLARKE Variable Speed Orbital Sander, which is designed for DIY and light workshop use only. Before attempting to use this product, please read this manual thoroughly and follow the instructions carefully. In doing so you will ensure the safety of yourself and that of others around you, and you can look forward to your purchase giving you long and satisfactory service. -
Page 3: General Safety Rules
GENERAL SAFETY RULES WARNING: WHEN USING ELECTRIC TOOLS, BASIC SAFETY PRECAUTIONS SHOULD ALWAYS BE FOLLOWED TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK AND PERSONAL INJURY INCLUDING THE FOLLOWING. READ ALL THESE INSTRUCTIONS BEFORE ATTEMPTING TO OPERATE THIS PRODUCT AND SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE. GENERAL SAFETY IN THE WORKPLACE 1. -
Page 4: Dust Extraction
5. Before further use of the tool, it should be carefully checked to determine that it will operate properly and perform its intended function. Check for alignment of moving parts, binding of moving parts, breakage of parts, mounting or other condition that may affect its operation. 6. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS WARNING: READ THESE ELECTRICAL SAFETY INSTRUCTIONS THOROUGHLY BEFORE CONNECTING THE PRODUCT TO THE MAINS SUPPLY. Before switching the product on, make sure that the voltage of your electricity supply is the same as that indicated on the rating plate. This product is designed to operate on 230VAC 50Hz. -
Page 6: Product Overview
PRODUCT OVERVIEW DESCRIPTION DESCRIPTION Lock-On Button Speed Control Dust Bag Sanding Pad Trigger Adjustable Handle PREPARATION AND USE FITTING A SANDING DISC 1. Select the disc to be used. (this MUST be correct 125m dia disc with hook and loop backing). 2. -
Page 7: Fitting The Handle
3. Line up the holes in the disc with those on the machine sanding pad. (This is necessary for dust extraction purposes). Press the disc firmly onto the pad to secure it. FITTING THE HANDLE Your sander is fitted with an adjustable support handle. This can be adjusted for position by loosening handgrip lightly, (unscrew anticlockwise) and rotating the handgrip around the body of the machine to the desired position, then tightening securely. -
Page 8: Maintenance
SANDER DOES NOT OPERATE WHEN SWITCHED ON Check to ensure the fuse in the plug is sound and replace if necessary. If the fuse is sound or blows repeatedly, consult your CLARKE dealer. DUST IS NOT EXTRACTED The dust bag is full or the dust extractor flue is blocked, This is usually caused by allowing the bag to become too full. -
Page 9: Parts Diagram
PARTS DIAGRAM PARTS LIST DESCRIPTION DESCRIPTION Left Housing 16 6002 Bearing Screw 17 Fan Blade Nameplate 18 Shaft Base Power Cable 19 Base Cable Sleeve 20 Washer Cable Clamp 21 Spring Washer Parts & Service: 020 8988 7400 / E-mail: Parts@clarkeinternational.com or Service@clarkeinternational.com... - Page 10 28 Data Plate 14 Motor Rotor 29 Dust Bag 15 Bearing Holder When requesting spare parts, please quote the reference GR-CROS1 followed by the number listed. REPLACEMENT DISCS Random Orbit Sanding Discs 60 grit (pack of 5). Part No: 6463051 Random Orbit Sanding Discs 100 grit (pack of 5).
-
Page 11: Declaration Of Conformity
