ECS P965T-A Manual

Hide thumbs
Table of Contents
  • Table of Contents

  • Chapter 1 Introducing the Motherboard
    • Introduction
    • Feature
    • Motherboard Components

  • Chapter 2 Installing the Motherboard
    • Safety Precautions
    • Choosing a Computer Case
    • Installing the Motherboard in a Case
    • Checking Jumper Settings
      • Setting Jumpers
      • Checking Jumper Settings
      • Jumper Settings
    • Connecting Case Components
      • Front Panel Header
    • Installing Hardware
      • Installing the Processor
      • Installing Memory Modules
      • Installing a Hard Disk Drive/CD-ROM/SATA Hard Drive
      • Installing a Floppy Diskette Drive
      • Installing Add-On Cards
      • Connecting Optional Devices
    • Connecting I/O Devices

  • Chapter 3 Using BIOS
    • About the Setup Utility
      • The Standard Configuration
      • Entering the Setup Utility
      • Updating the BIOS
    • Using BIOS
      • Standard CMOS Features
      • Advanced BIOS Features
      • Advanced Chipset Features
      • Integrated Peripherals
      • Power Management Setup
      • PNP/PCI Configurations
      • PC Health Status
      • Frequency/Voltage Control
      • Load Fail-Safe Defaults
      • Load Optimized Defaults Option
      • Set Password
      • Save & Exit Setup
      • Exit Without Saving

  • Chapter 4 Using the Motherboard Software
    • About the Software CD-ROM
    • Auto-Installing under Windows 2000/XP
      • Running Setup
    • Manual Installation
    • Utility Software Reference

  • Chapter 5 Jmicron RAID Configuration
    • Before Creating a RAID Set
    • Entering the JMB363 RAID BIOS Utility
    • Creating a RAID Set
    • Deleting a RAID Set
    • Resetting Disks to Non-RAID
    • Solving a Mirror Conflict
    • Rebuilding a Mirror Drive
    • Saving the Settings and Exiting Setup

Advertisement

Available languages
  • EN

Available languages

  • ENGLISH, page 83

Quick Links

Advertisement

Table of Contents
loading

Related Manuals for ECS P965T-A

Summary of Contents for ECS P965T-A

  • Page 3 Preface Copyright This publication, including all photographs, illustrations and software, is protected under international copyright laws, with all rights reserved. Neither this manual, nor any of the material contained herein, may be reproduced without written consent of the author. Version 1.0C Disclaimer The information in this document is subject to change without notice.
  • Page 4 Declaration of Conformity This device complies with part 15 of the FCC rules. Operation is subject to the following conditions: • This device may not cause harmful interference, and • This device must accept any interference received, including interference that may cause undesired operation Canadian Department of Communications This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations.

  • Page 5: Table Of Contents

    T T T T T ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS ABLE OF CONTENTS Preface Chapter 1 Introducing the Motherboard Introduction....................1 Feature......................2 Motherboard Components................4 7 7 7 7 7 Chapter 2 Installing the Motherboard Safety Precautions..................7 Choosing a Computer Case...............7 Installing the Motherboard in a Case............7...
  • Page 6 Integrated Peripherals..............36 Power Management Setup............39 PNP/PCI Configurations .............41 PC Health Status................43 Frequency/Voltage Control ............45 Load Fail-Safe Defaults...............46 Load Optimized Defaults Option ..........46 Set Password ................46 Save & Exit Setup.................47 Exit Without Saving...............47 Chapter 4 49 49 49 49 Using the Motherboard Software About the Software CD-ROM..............49 Auto-installing under Windows 2000/XP...........49 Running Setup................50...

  • Page 7: Introducing The Motherboard

    Chapter 1 Introducing the Motherboard Introduction Thank you for choosing the motherboard. This motherboard is a high performance, en- hanced function motherboard designed to support the LGA775 socket Intel Core™2 Ex- treme/Core 2 Duo/Pentium D/Pentium 4/Celeron D processors for high-end business or personal desktop markets.

  • Page 8: Feature

    Feature Processor The motherboard uses an LGA775 type of Intel Core™2 Extreme/ Core™2 Duo/ Pentium D/ Pentium 4/ Celeron D that carries the following features: • Accommodates Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium D/ Pentium 4/ Celeron D processors •...
  • Page 9 Onboard LAN (Optional) This motherboard may support either of the following LAN chipset: • Supports 100/10 Mb/s N-Way Auto negotiation operation • Half/Full duplex capability • Supports Wake-on-LAN function and remote wake-up • Integrate 10/100/1000 transceiver • Supports PCI v2.3, 32-bit, 33/66MHz •...

  • Page 10: Motherboard Components

    Motherboard Components Introducing the Motherboard...
  • Page 11 Table of Motherboard Components LABEL COMPONENT 1 CPU Socket LGA775 socket for Intel Core 2 Duo/ Pentium D/Pentium 4/Celeron D CPUs 2 CPUFAN CPU cooling fan connector 3 DIMM1~4 240-pin DDR2 SDRAM slots 4 ATX1 Standard 24-pin ATX power connector 5 FDD1 Floppy diskette drive connector 6 JP1...
  • Page 12 Memo Introducing the Motherboard...

  • Page 13: Installing The Motherboard

    Chapter 2 Installing the Motherboard Safety Precautions • Follow these safety precautions when installing the motherboard • Wear a grounding strap attached to a grounded device to avoid damage from static electricity • Discharge static electricity by touching the metal case of a safely grounded object before working on the motherboard •...

  • Page 14: Checking Jumper Settings

    Do not over-tighten the screws as this can stress the motherboard. Checking Jumper Settings This section explains how to set jumpers for correct configuration of the motherboard. Setting Jumpers Use the motherboard jumpers to set system configuration options. Jumpers with more than one pin are numbered.

  • Page 15: Checking Jumper Settings

    Checking Jumper Settings The following illustration shows the location of the motherboard jumpers. Pin 1 is labeled. Jumper Settings Jumper Description Type Setting (default) 1-2: CMOS CLEAR 2-3: NORMAL 3-pin CLEAR CMOS Before clearing the CMOS, make sure to turn off the system. To avoid the system unstability after clearing CMOS, we recommend users to enter the main BIOS setting page to “Load Optimal De- faults”...

  • Page 16: Connecting Case Components

    Connecting Case Components After you have installed the motherboard into a case, you can begin con- necting the motherboard components. Refer to the following: Connect the CPU cooling fan cable to CPUFAN. Connect the system cooling fan connector to SYSFAN. Connect the Northbridge cooling fan connector to NBFAN.
  • Page 17 CPUFAN: CPU FAN Power Connector Signal Name Function System Ground Power +12V +12V Sense Sensor Control CPU FAN control Users please note that the fan connector supports the CPU cooling fan of 1.1A~2.2A (26.4W max.) at +12V. SYSFAN/NBFAN: System/Northbridge cooling FAN Connector Signal Name Function System Ground...

  • Page 18: Front Panel Header

    SPK1: Internal speaker Signal Name Signal Front Panel Connector The front panel connector (PANEL1) provides a standard set of switch and LED connec- tors commonly found on ATX or micro-ATX cases. Refer to the table below for informa- tion: Signal Function Signal Function...

  • Page 19: Installing Hardware

    Installing Hardware Installing the Processor Caution: When installing a CPU heatsink and cooling fan make sure that you DO NOT scratch the motherboard or any of the surface-mount resistors with the clip of the cooling fan. If the clip of the cooling fan scrapes across the motherboard, you may cause serious damage to the motherboard or its components.
  • Page 20 CPU Installation Procedure The following illustration shows CPU installation components. A. Read and follow the instructions shown on the sticker on the CPU cap. B. Unload the cap · Use thumb & forefinger to hold the lifting tab of the cap. ·...

  • Page 21: Installing Memory Modules

    Installing Memory Modules This motherboard accomodates four memory modules. It can support four 240-pin DDR2 800/667/533 DDR2 SDRAM. The total memory support capacity is 8 GB. DDR2 SDRAM memory module table Memory module Memory Bus DDR2 533 266 MHz DDR2 667 333 MHz DDR2 800 400 MHz...
  • Page 22 Table A: DDR2(memory module) QVL (Qualified Vendor List) The following DDR2 800/667/533 memory modules have been tested and qualified for use with this motherboard. Type Size Vendor Module Name A-DATA M2OHY2F3G3110A1B0Z DDR2 256MB Elixir M2U25664TUH4A0F-37B Infineon HYS64T32000HU-3.7-A Kingston KVR533D2N4 Ramaxel RML 1040M28D5F-533 AENEON AET660UD00-370A98X...

  • Page 23: Installing A Hard Disk Drive/Cd-Rom/Sata Hard Drive

    Installing a Hard Dish Drive/CD-ROM/SATA Hard Drive This section describes how to install IDE devices such as a hard disk drive and a CD-ROM drive. About IDE Device Your motherboard has one IDE channels interface. An IDE ribbon cable supporting two IDE devices is bundled with the motherboard.

  • Page 24: Installing A Floppy Diskette Drive

    Refer to the illustration below for proper installation: Attach either cable end to the connector on the motherboard. Attach the other cable end to the SATA hard drive. Attach the SATA power cable to the SATA hard drive and connect the other end to the power supply.

  • Page 25: Installing Add-On Cards

    Installing Add-on Cards The slots on this motherboard are designed to hold expansion cards and connect them to the system bus. Expansion slots are a means of adding or enhancing the motherboard’s features and capabilities. With these efficient facilities, you can increase the motherboard’s capabili- ties by adding hardware that performs tasks that are not part of the basic system.
  • Page 26 Follow these instructions to install an add-on card: Open the chassis and then remove the slot bracket from the case where you will be installing the expansion cards. Install your graphics card in the proper slot by pressing the card firmly into the slot.

  • Page 27: Connecting Optional Devices

    Connecting Optional Devices Refer to the following for information on connecting the motherboard’s optional devices: AUDIO1: Front Panel Audio header This header allows the user to install auxiliary front-oriented microphone and line-out ports for easier access. Signal Name Signal Name Signal Name Function PORT 1L...
  • Page 28 USB1/2/3: Front Panel USB headers The motherboard has four USB ports installed on the rear edge I/O port array. Additionally, some computer cases have USB ports at the front of the case. If you have this kind of case, use auxiliary USB connector to connect the front-mounted ports to the motherboard. Signal Name Function USBPWR...
  • Page 29 SATA1/3/5/6/7: Serial ATA connectors These connectors are use to support the new Serial ATA devices for the highest date transfer rates (3.0 Gb/s), simpler disk drive cabling and easier PC assembly. It eliminates limitations of the current Parallel ATA interface. But maintains register compatibility and software compatibility with Parallel ATA.

  • Page 30: Connecting I/O Devices

    Connecting I/O Devices (Optional) The backplane of the motherboard has the following I/O ports: PS2 Mouse Use the upper PS/2 port to connect a PS/2 pointing device. PS2 Keyboard Use the lower PS/2 port to connect a PS/2 keyboard. Parallel Port (LPT2) Use LPT2 to connect printers or other parallel communications devices.

  • Page 31: Using Bios

    Chapter 3 Using BIOS About the Setup Utility The computer uses the latest Award BIOS with support for Windows Plug and Play. The CMOS chip on the motherboard contains the ROM setup instructions for configuring the motherboard BIOS. The BIOS (Basic Input and Output System) Setup Utility displays the system’s configura- tion status and provides you with options to set system parameters.
  • Page 32 Press DEL to enter SETUP Pressing the delete key accesses the BIOS Setup Utility: Phoenix-AwardBIOS CMOS Setup Utility: Standard CMOS Features Frequency/Voltage Control Advanced BIOS Features Load Fail-Safe Defaults Advanced Chipset Features Load Optimized Defaults Integrated Peripherals Set Supervisor Password Power Management Setup Set User Password PnP/PCI Configurations...

  • Page 33: Updating The Bios

    Updating the BIOS You can download and install updated BIOS for this motherboard from the manufacturer’s Web site. New BIOS provides support for new peripherals, improvements in performance, or fixes for known bugs. Install new BIOS as follows: If your motherboard has a BIOS protection jumper, change the setting to allow BIOS flashing.

  • Page 34: Standard Cmos Features

    Standard CMOS Features This option displays basic information about your system. Phoenix-AwardBIOS CMOS Setup Utility Standard CMOS Features Date (mm:dd:yy) Wed, Jan 19 2005 Item Help Time (hh:mm:ss) 9 : 33 : 26 IDE Channel 0 Master Menu Level IDE Channel 0 Slave Change the day, month, IDE Channel 1 Master year and century...
  • Page 35 IDE HDD Auto-Detection Press <Enter> while this item is highlighted to prompt the Setup Utility to automatically detect and configure an IDE device on the IDE channel. If you are setting up a new hard disk drive that supports LBA mode, more than one line will appear in the parameter box.

  • Page 36: Advanced Bios Features

    Advanced BIOS Features This option defines advanced information about your system. Phoenix-AwardBIOS CMOS Setup Utility Advanced BIOS Features CPU Feature [Press Enter] Item Help Removable Device Priority [Press Enter] Hard Disk Boot Priority [Press Enter] Menu Level CD-ROM Boot Priority [Press Enter] Network Boot Priority [Press Enter]...
  • Page 37 DelayPrior to Thermal (16 Min) Enables you to set the delay time before the CPU enters auto thermal mode. Thermal Management (Thermal Monitor 1) This item displays CPU’s temperature and enables you to set a safe temperature to Prescott CPU. TM2 Bus Ratio (0X) This item represents the frequency (bus ratio) of the throttled performance state that will be initiated when the on-die sensor goes from not hot to hot).
  • Page 38 Hard Disk Boot Priority (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility Hard Disk Boot Priority Item Help 1. Pri.Master: 2. Pri.Slave: Menu Level 3. Sec. Master: 4. Sec. Slave: Use <...
  • Page 39 Network Boot Priority (Press Enter) Scroll to this item and press <Enter> to view the following screen: Phoenix-AwardBIOS CMOS Setup Utility Network Boot Priority Item Help 1. Network 0 : 2. Network 1: Menu Level 3. Network 2: 4. Network 3: Use <...
  • Page 40 For exp, If you installed one AXX DVD-RW in SATA7 port, please choose AXX DVD- RW from first boot device list to boot from AXX DVD-RW. If you insert AXX DVD- RW in SATA1 port, please choose “CD-ROM” item from first boot device list to boot from AXX DVD-RW.

  • Page 41: Advanced Chipset Features

    Advanced Chipset Features These items define critical timing parameters of the motherboard. You should leave the items on this page at their default values unless you are very familiar with the technical specifications of your system hardware. If you change the values incorrectly, you may introduce fatal errors or recurring instability into your system.

  • Page 42: Integrated Peripherals

    PEG Force X1 (Disabled) This item is used to select PCI Express X1 forcedly. Press <Esc> to return to the Advanced BIOS Features page. Integrated Peripherals These options display items that define the operation of peripheral components on the system’s input/output ports. Phoenix-AwardBIOS CMOS Setup Utility Integrated Peripherals Item Help...
  • Page 43 USB Controller (Enabled) Enables or disables the onboard USB controller. We recommend users keep the dafault value. Disabling it might cause the USB devices not to work properly. USB 2.0 Controller (Enabled) This item enables or disables the onboard USB 2.0 controller. USB Keyboard Support (Enabled) Enable this item if you plan to use a keyboard connected through the USB port in a legacy operating system (such as DOS) that does not support Plug and Play.
  • Page 44 Onboard FDC Controller (Enabled) Select Enabled if your system has a floppy disk controller (FDC) installed on the system board and you wish to use it. If you install an add-in FDC or the system has no floppy drive, select Disabled in this field. Onboard Serial Port 1 (3F8/IRQ4) This option is used to assign the I/O address and interrupt request (IRQ) for onboard serial port1.

  • Page 45: Power Management Setup

    Power Management Setup This option lets you control system power management. The system has various power- saving modes including powering down the hard disk, turning off the video, suspending to RAM, and software power down that allows the system to be automatically resumed by certain events.
  • Page 46 ACPI Suspend Type (S3(STR)) Use this item to define how your system suspends. In the default, S3 (STR), the suspend mode is a suspend to RAM, i.e., the system shuts down with the exception of a refresh current to the system memory. Run VGABIOS if S3 Resume (Auto) This item allows the system to initialize the VGA BIOS from S3 (Suspend to RAM) sleep state.

  • Page 47: Pnp/Pci Configurations

    Resume By PS2 MS/KS(S3) (Disabled) Enable or disable the function of waking up the system by the mouse/keyboard activity. Power on After Power fail (Off) This item enables your computer to automatically restart or return to its last operatingstatus after power returns from a power failure. ** Reload Global Timer Events ** Global Timer (power management) events are I/O events whose occurrence can prevent the system from entering a power saving mode or can awaken the system from such a mode.
  • Page 48 Init Display First (PCI Slot) This item allows you to choose the primary display card. Reset Configuration Data (Disabled) If you enable this item and restart the system, any Plug and Play configuration data stored in the BIOS Setup is cleared from memory. Resources Controlled By (Auto(ESCD)) You should leave this item at the default Auto (ESCD).

  • Page 49: Pc Health Status

    PC Health Status On motherboards that support hardware monitoring, this item lets you monitor the parameters for critical voltages, temperatures and fan speeds. Phoenix-AwardBIOS CMOS Setup Utility PC Health Status Item Help Smart Fan Control [Enabled] CPU Warning Temperature [Disabled] Menu Level CPU Temperature System Temperature...
  • Page 50 Smart Fan Control (Enabled) This item enables or disables the Smart fan function, when it is set at certaintemperature, , the PWM value will reach the certain value accordingly, and wecan adjust the CPU fanspeed by PWM. CPU Tolerance temp (2) This item is used to set the tolerance temperacture of CPU fanspeed.

  • Page 51: Frequency/Voltage Control

    Frequency/Voltage Control This item enables you to set the clock speed and system bus for your system. The clock speed and system bus are determined by the kind of processor you have installed in your system. Phoenix-AwardBIOS CMOS Setup Utility Frequency/Voltage Control CPU Clock Ratio [16X]...

  • Page 52: Load Fail-Safe Defaults

    Load Fail-Safe Defaults Option This option opens a dialog box that lets you install fail-safe defaults for all appropriate items in the Setup Utility: Press <Y> and the <Enter> to install the defaults. Press <N> and then <Enter> to not install the defaults. The fail-safe defaults place no great demands on the system and are generally stable.

  • Page 53: Save & Exit Setup

    Save & Exit Setup Highlight this item and press <Enter> to save the changes that you have made in the Setup Utility and exit the Setup Utility. When the Save and Exit dialog box appears, press <Y> to save and exit, or press <N> to return to the main menu. Exit Without Saving Highlight this item and press <Enter>...
  • Page 54 Memo Using BIOS...

  • Page 55: Using The Motherboard Software

    Chapter 4 Using the Motherboard Software About the Software CD-ROM The support software CD-ROM that is included in the motherboard package contains all thedrivers and utility programs needed to properly run the bundled products. Below you can finda brief description of each software program, and the location for your motherboardversion.

  • Page 56: Running Setup

    Setup Tab Setup Click the Setup button to run the software installation program. Select from the menu which software you want to install. Browse CD The Browse CD button is the standard Windows command that allows you to open Windows Explorer and show the contents of the support Before installing the software from Windows Explorer, look for a file named README.TXT, INSTALL.TXT or something similar.
  • Page 57 Click Next. The following screen appears: Check the box next to the items you want to install. The default options are recommended. Click Next run the Installation Wizard. An item installation screen appears: Follow the instructions on the screen to install the items. Drivers and software are automatically installed in sequence.

  • Page 58: Manual Installation

    Manual Installation Insert the CD in the CD-ROM drive and locate the PATH.DOC file in the root directory. This file contains the information needed to locate the drivers for your motherboard. Look for the chipset and motherboard model; then browse to the directory and path to begin installing the drivers.

  • Page 59: Jmicron Raid Configuration

    Chapter 5 JMB361 RAID Setup Guide JMicron ® RAID Configuration The JMicron Serial ATA controller allows you to configure RAID 0, RAID 1 and JBOD sets ® on the external Serial ATA hard disk drives. Before creating a RAID set Prepare the following items: Two SATA HDDs, preferably with the same model and capacity.

  • Page 60: Entering The Jmb363 Raid Bios Utility

    Entering the JMB361 RAID BIOS utility During POST, press <Ctrl-J> to enter the JBM361 RAID BIOS menu. The main JMB361 RAID BIOS menu appears. Use the arrow keys to move the color bar and navigate through the items. Creating a RAID set In the main JMB361 RAID BIOS menu, highlight Create RAID Disk Drive using the up/down arrow key then press <Enter>.
  • Page 61 When the Level item is highlighted, use the up/down arrow key to select the RAID set that you want to create. When the Disks item is highlighted, use the up/down arrow key to highlight an HDD that you want to belong to the RAID set, then press the space bar to confirm selection.
  • Page 62 When done, press <Enter> to confirm the creation of the RAID set. A dialogue box appears to confirm the action. Press <Y> to confirm; otherwise, press <N>. Pressing <Y> deletes all the data in the HDDs. The following screen appears, displaying the relevant information about the RAID set you created.

  • Page 63: Deleting A Raid Set

    Deleting a RAID set In the main JMB361 RAID BIOS menu, highlight Delete RAID Disk Drive using the up/down arrow key then press <Enter>. Use the space bar to select the RAID set you want to delete. A selected set shows a sign before it.

  • Page 64: Resetting Disks To Non-Raid

    Resetting disks to non-RAID An HDD that has been previously configured as part of another RAID set in another platform is called a broken RAID HDD. When you install a broken RAID HDD, you cannot select this HDD when configuring a RAID set through the JMB361 utility.

  • Page 65: Solving A Mirror Conflict

    Solving a Mirror conflict A Mirror conflict occurs when both disks in a RAID 1 (Mirror) configuration are unplugged from the system in turn, then plugged in again. Since both disks contain exactly the same data, the system will be unable to determine which of the two is the source drive. This option allows you to set the source drive and rebuild the Mirror drive according to the contents of the source drive.

  • Page 66: Rebuilding A Mirror Drive

    Rebuilding a Mirror Drive When one of the disks in a RAID 1 (Mirror) configuration is unplugged from the system, then plugged in again, a dialogue box appears to ask you to rebuild the Mirror drive. Press<Y>toconfirm;otherwise, press<N>. Press <Y> to confirm; otherwise, press <N>. This option allows you to rebuild the Mirror drive later and synchronize the data between two hard disks.
  • Page 67 Caractéristiques Processeur La carte mère utilise un type LGA775 d’Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D comportant les caractéristiques suivantes : • Peut recevoir les processeurs Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D •...
  • Page 68 LAN interne (Optionnel) Cette carte mère prend en charge les chipsets LAN suivants : • Supporte le fonctionnement en Auto-négociation N-Way en 100/10 Mb/s • Prend en charge la capacite half/full duplex • Prend en charge la fonction Wake-On-LAN (réveil par appel réseau) et le réveil à...
  • Page 69 Features Prozessor Das Mainboard verwendet einen LGA775 Typ Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D mit den folgenden Eigenschaften: • Nimmt Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D Prozessoren auf • Unterstützt einen Systembus (FSB) mit 1066/800/533 MHz. •...
  • Page 70 Integriertes LAN (optional) Dieses Mainboard kann einen der folgenden LAN-Chipsätze unterstützen: • Unterstützt den Betrieb bei 100/10 Mb/s N-Way Auto-Negotiation • Unterstützt Halb-/Vollduplex • Unterstützt Wake-On-LAN-Funktion und Remote-Wake-up • Enthält 10/100/1000 Transceiver • Unterstützung von PCI v2.3, 32-Bit, 33/66-MHz • Vollständige Unterstützung für IEEE802.3, IEEE802.3u und IEEE802.3ab Audio •...
  • Page 71 Caratteristiche Processore La scheda madre utilizza un tipo LGA775 di processore Intel Core™2 Extreme / Core™2 Duo / Pentium 4 / Celeron D/ Pentium D che offre le seguenti caratteristiche: • Compatibile con processori Intel Core™ 2 Extreme / Core™ 2 Duo / Pentium 4 / Celeron D /Pentium D •...
  • Page 72 integrata (Opzionale) La scheda madre offre supporto per uno dei seguenti chipset LAN: • Supporto di NWay Auto-negotiation a 100/10 Mb/s • Supporto di funzionalità half/full duplex • Supporto di funzionalità Wake-On-LAN e riattivazione remota del sistema • Transceiver 10/100/1000 integrato •...
  • Page 73 Características Procesador La placa principal usa un tipo LGA775 de Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D que lleva las sigtes. características: • Acomoda procesadores Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D •...
  • Page 74 LAN Abordo (optativo) Esta placa principal puede soportar uno de los sigtes. chipset LAN: • Soporta operación de Autonegociación N-Way de 100/10 Mb/s • Soporta capacidad duplex medio/completo • Soporta la función Wake-On-LAN y despertar remoto Transceptor 10/100/1000 integrado • •...
  • Page 75 Características Processador Esta motherboard usa um tipo de Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D LGA775 que possui as seguintes características: • Acomoda processadores Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D • Suporta um bus sistema (FSB) de 1066/800/533 MHz •...
  • Page 76 Onboard LAN (opcional) Esta motherboard poderá suportar qualquer um dos seguintes conjuntos de chips LAN: • Suporta operação de Auto-negociação N-Way 100/10 Mb/s • Suporta capacidade de duplex pela metade/ou na totalidade • Suporta função LAN de Despertar e despertar remoto •...
  • Page 77 機能 プロセッサ 本マザーボードは LGA775タイプのIntel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium Dを利用するもので、下記の特徴を持っています： • Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D プロセッサの搭載が可能 • 1066/800/533MHzのシステムバス(FSB)をサポート • “ハイパースレッド技術対応のCPUを取り付け可能 ハイパースレッド（HT） 技術というのは、オペレーションシステムに2つのプロセッサが存在すると認 識させることで、実際には2つのスレッドを1つのプロセッサで同時に執行させ、平行利用を可能とす る技術です。 チップセット P965 Northbridge (NB)とICH8 Southbridge (SB)チップセットは、実証された信頼性 と性能を持つ革新的で拡張性のあるアーキテクチャに基づいています。...
  • Page 78 オンボードLAN (オプション) 当マザーボードは次のLANチップセットのいずれかを搭載しております： • 100/10 Mb/s N-way自動ネゴシエーション操作をサポート • 半/全二重の機能をサポート • Wake-On-LANと遠隔wake-up機能をサポート • 10/100/1000 トランシーバーを搭載済み • PCI v2.3, 32-bit, 33/66-MHzへの対応 • IEEE802.3、IEEE802.3u、およびIEEE802.3abに完全対応 オーディオ • 8チャネルのDACで、 7.1オーディオソリューションの24/20/16-bit PCM形 式をサポート • 192K/96K/48K/44.1KHz DAC サンプリング率をサポート • 電源サポート： 3.3V(デジタル方式の場合)、3.5V~5.25V(アナログ方式の 場合) • Microsoft WHQL/WLP 2.x オーディオ基準に準拠 •...
  • Page 79 특징 프로세서 본 마더보드는 인텔 코어 2 익스트림/ 코어 2 듀오/팬티엄 4/ 셀러론 D/ 팬티엄 D의 ™ ™ LGA775 타입을 사용하였으며 다음과 같은 특성을 지닌다. • 인텔 코어 2 익스트림/ 코어 2 듀오/ 팬티엄 4/ 셀러론 D/팬티엄 D 프로세 ™ ™...
  • Page 80 오디오 • 8 채널 DAC, 7.1 오디오 솔루션을 위해 24/20/16 비트 PCM 포맷 지원 • 192K/96K/48K/44.1KHz DAC 샘플 속도 지원 • 전원 지원: 디지털: 3.3V; 아날로그: 3.5V~5.25V • Microsoft WHQL/WLP 2.x 오디오 요구 조건에 부합 • Direct Sound 3D 호환 •...
  • Page 81 功能 處理器 本主機板可安裝一個 LGA775型式之Intel Core ™ 2 Extreme/ Core ™ 2 Duo/Pentium 4/ Celeron D/ Pentium D，並具有如下特色： • 支援 Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D 處理器 • 支援高達 1066/800/533MHz之系統匯流排(FSB) • 支援使用超執行緒(Hyper-Threading)技術之CPU 利用“超執行緒(HT)”技術，可使作業系統在相當於裝上了兩具處理器的狀態下運 作：利用一個”實體”處理器模擬出兩個獨立的”邏輯”處理器，同時執行兩個工作 緒。 晶片組...
  • Page 82 音效 • 配備8通道之DAC，可支援 7.1音訊解決方案之24/20/16-bit PCM 格式 • 支援 192K/96K/48K/44.1KHz DAC 取樣率 • 電源支援： 3.3V(數位)、3.5V~5.25V(類比) • 符合Microsoft WHQL/WLP 2.x 音訊規格 • Direct Sound 3D 相容 • 配備Dolby ® Digital Encoder 輸出端子，可用來連接家用電子產品 擴充選項 本主機板包括下列擴充選項： • 2個繪圖介面用的PCI Express x16 插槽 (x16, x4) • 2個PCI Express x1 插槽...
  • Page 83 功能 处理器 此主板使用 LGA775 型 Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D 处理器，具有以下特点： • 支持 Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D 处理器 • 支持 1066/800/533 MHz 系统总线 (FSB) • 支持“多线程”技术 CPU “多线程”技术可以让操作系统认为自己连接了两个处理器，允许两个线程并行运行，...
  • Page 84 音频 • 8 通道 DAC，支持 24/20/16 位 PCM 格式用于 7.1 音频解决方案 • 支持 192K/96K/48K/44.1KHz DAC 采样速率 • 电源支持： 数字亮：3.3V；模拟量：3.5V~5.25V • 符合 Microsoft WHQL/WLP 2.x 音频要求 • 符合 Direct Sound 3D 规格 • 用于消费类电子应用的杜比 ® 数字编码器 扩展选项 此主板提供如下扩展选项： • 2 个用于图形接口的 PCI Express x 16插槽 (x16, x4) •...
  • Page 85 Характеристики Процессор Материнская плата построена для процессоров типа LGA775 Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D и обладает следующими свойствами: • Размещает процессоры Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D • Поддерживает системные шины (FSB) с частотой 1066/800/533MHz •...
  • Page 86 Встроенный сетевой адаптер LAN (опционально) Встроенный сетевой адаптер LAN обладает следующими характеристиками: • Поддерживает автоматическое определение скорости и режима соединения 100/10 Mb/s • Поддержка режимов Half и Full Duplex • Поддерживает функции Wake-On-LAN и remote wake-up • Интегрированный трансивер 10/100/1000 •...
  • Page 87 Cechy Procesor Płyta główna posiada podstawkę typu LGA775, która jest przystosowana do obsługi procesorów Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D i posiada następujące właściwości: • Dostosowana do procesorów: Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D •...
  • Page 88 Zintegrowana obsługa sieci LAN (opcjonalnie) Zintegrowana obsługa sieci LAN posiada następujące właściwości: • Obsluguje N-drożne automatycznie ustalane operacje z szybkościami 100/ 10 Mb/s • Zdolność Half/Full duplex • Obsługuje funkcję Wake-On-LAN i zdalnie sterowane wake-up (uruchamianie komputera) • Zintegrowany terminal nadawczo-odbiórczy 10/100/1000 •...
  • Page 89 Vlastnosti Procesor Základní deska používá patici typu LGA775 pro procesory Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D a vyznačuje se následujícími funkcemi: • Určená pro procesory Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D •...
  • Page 90 Vestavění síťové rozhraní LAN (volitelně) Vestavěné síťové rozhraní LAN nabízí následující možnosti: • Podpora 100/10 Mb/s N–cestného automatického přepínání provozu • Poloviční a plný duplex • Podpora funkce Wake–On–LAN a aktivace na dálku • Integrovaný transceiver 10/100/1000 • Podpora rozhraní PCI v2.3, 32bitové, 33/66 MHz •...
  • Page 91 Caracteristici Procesorul Placa de bază utilizează Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D de tip LGA775 cu următoarele caracteristici: • Acomodează procesoare Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D • Funcţionează cu bus sistem (FSB) de 1066/800/533 MHz •...
  • Page 92 Onboard LAN (opţional) Onboard LAN are următoarele caracteristici: • Suportă operaţii de autonegociere N-way de 100/10 Mb/s • Posibilitate semi-duplex şi duplex complet • Suportă funcţia Wake-On-LAN şi trezirea de la distanţă • Unitate de emisie/recepţie 10/100/1000 integrat • Suportă PCI, versiunea 2.3, de 32 biţi, la 33/66 MHz •...
  • Page 93 Спецификация Процесор Тази дънна платка използва сокет LGA775 за процесори Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D и поддържа следните спецификации: • поддръжка на процесори Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D •...
  • Page 94 Интегриран мрежов контролер (опция) Спецификация на интегрирания мрежов контролер: • Поддръжка на режими: 100/10 Mb/s с функция за определяне оптималната скорост на трансфер (N-Way Auto-negotiation). • Режим: Half/Full duplex • поддръжка на функция за “събуждане” Wake-On-LAN и дистанционен wake-up • Интегриран...
  • Page 95 Jellemző Processzor Az alaplap LGA775 típusú Intel Core™2 Extreme/ Core™2 Duo/Pentium 4/ Celeron D/ Pentium D processzort használ, a következő tulajdonságokkal: • Intel Core™ 2 Extreme/ Core™ 2 Duo/ Pentium 4/ Celeron D/Pentium D processzort akkomodál • 1066/800/533 MHz sebességű rendszerbuszt (FSB) támogat •...
  • Page 96 Alaplapon levő LAN (opcionális) Az alaplapon levő LAN jellemzői: • 100/10 Mb/s N-Way automatikus beállítással • Fél-/teljes duplex • Támogatja a Wake-On-LAN funkciót és a távoli ébresztést • Integrált 10/100/1000 adó-vevő • Támogatja a 32 bites, 33/66 MHz-es PCI 2.3-as változatát •...
