"Remove the LCD module" on page 26
Step 1.
Remove six screws and then remove the battery pack.
Figure 8. Remove the battery pack
Screw specifications
M2 x L2
Go to
https://support.lenovo.com/partslookup
part:
Battery pack
Remove the solid-state drive (SSD) module
Make sure the following FRU (or CRU) has been removed.
"Remove the LCD module" on page 26
Step 1.
Remove one screw.
Figure 9. Remove one screw
Screw specifications
M2 x L2
Step 2.
Remove the SSD module by pulling it away from the slot.
Number of screws
6
to look up the Lenovo part number of the following replacement
Number of screws
1
.
Chapter 4
Removing a FRU or CRU
29
