OptiView
TM
Series II
Getting Started Guide
Analyzer Network Connections
Figure 12 shows the top view of the OptiView
Analyzers.
The internal wire map adapter, labeled Wire Mapper, tests patch
cables. To test patch cables, connect a cable from the 10/100 BASE-
TX connector to the Wire Mapper connector. The test is
automatically run. Go to the Cable Test screen to view the results.
VGA Out Port
Figure 12. Top View of the OptiViewTM Standard, Standard, Pro, and Pro Gigabit Analyzers
20
Note
10BASE-T
100BASE-TX
Standard Analyzer
10BASE-T
100BASE-TX
Pro Analyzer
10BASE-T
100BASE-TX
Pro Gigabit Analyzer
Standard, Pro, and Pro Gigabit
TM
aww10f.eps
