Trane IntelliPak Signature Series Programming Manual page 33

Actuator Setup
Max Stroke Time
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Min Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Direct/Reverse Acting
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Stroke Time
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Min Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Direct/Reverse Acting
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Stroke Time
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Min Voltage
Note: Min. voltage should be set to 2.0 on units with IGV.
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Max Voltage
1. Press the NEXT key until the following screen is displayed.
Actuator Setup
Direct/Reverse Act
1. Press the NEXT key until the following screen is displayed.
PKG-SVP01E-EN
Water Economizer
150 Sec
Water Economizer
2.0 VDC
Water Economizer
10.0 VDC
Water Economizer
Direct Acting
Water Econ Bypass
150 Sec
Water Econ Bypass
2.0 VDC
Water Econ Bypass
10.0 VDC
Water Econ Bypass
Direct Acting
IGV/VFD Cmd
150 Sec
IGV/VFD Cmd
2.0 VDC
IGV/VFD Cmd
10.0 VDC
IGV/VFD Cmd
DIRECT ACTING
Programming SETUP
Used With: All Units when a waterside
economizer is installed.
Factory Presets: 150 Sec
Possible Values: 1-255 Sec
Used With: All Units when a waterside
economizer is installed.
Factory Presets: 2.0 VDC
Possible Values: 0-10 VDC
Used With: All Units when a waterside
economizer is installed.
Factory Presets: 10.0 VDC
Possible Values: 0-10 VDC
Used With: All Units when a waterside
economizer is installed.
Factory Presets: Direct Acting
Possible Values: Direct Acting, Reverse Acting
Used With: All Units when a waterside
economizer is installed.
Factory Presets: 150 Sec
Possible Values: 1-255 Sec
Used With: All Units when a waterside
economizer is installed.
Factory Presets: 2.0 VDC
Possible Values: 0-10 VDC
Used With: All Units when a waterside
economizer is installed.
Factory Presets: 10.0 VDC
Possible Values: 0-10 VDC
Used With: All Units when a waterside
economizer is installed.
Factory Presets: Direct Acting
Possible Values: Direct Acting, Reverse Acting
Used With: All Units when IGV/VFD is installed
Factory Presets: 150 Sec
Possible Values: 1 - 255 Seconds
Used With: All Units when IGV/VFD is installed
Factory Presets: 2.0 VDC
Possible Values: 0 to 10 VDC
Used With: All Units when IGV/VFD is installed
Factory Presets: 10.0 VDC
Possible Values: 0 to 10.0 Volts DC
Used With: All Units when IGV/VFD is installed
Factory Presets: DIRECT ACTING
Possible Values: DIRECT ACTING, REVERSE
ACTING
33
