Installation Guide
Remote Human Interface
IntelliPak™ I 20-130 Ton Rooftop; Casing 2-9
Air Handler Units
IntelliPak™ II 90-162 Ton Rooftop; Casings
A-C Air Handler Units
Model
Used with
S*HL 20-75 Ton
S*HK 90-130 Ton
W*HE Casings 2-9
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
April 2020
S*HJ 090-162
W*HC Casings A-C
SAFETY WARNING
RT-SVN16B-EN
Advertisement
Related Manuals for Trane IntelliPak S HL Series
Summary of Contents for Trane IntelliPak S HL Series
- Page 1 Installation Guide Remote Human Interface IntelliPak™ I 20-130 Ton Rooftop; Casing 2-9 Air Handler Units IntelliPak™ II 90-162 Ton Rooftop; Casings A-C Air Handler Units Model Used with S*HL 20-75 Ton S*HJ 090-162 S*HK 90-130 Ton W*HC Casings A-C W*HE Casings 2-9 SAFETY WARNING Only qualified personnel should install and service the equipment.
-
Page 2: Warnings, Cautions, And Notices
(Global Harmonized System of Classification and compounds have the same potential impact to the Labeling of Chemicals) guidelines for information on environment. Trane advocates the responsible handling of allowable personal exposure levels, proper all refrigerants-including industry replacements for CFCs respiratory protection and handling instructions. -
Page 3: Revision History
Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change. - Page 4 Overview The Remote Human Interface Option enables the customer, building owner, or maintenance personnel, to communicate the necessary operating parameters for the Rooftop unit and to receive operating status information from within the occupied space. The Remote Panel is shown in Figure 1, p.
-
Page 5: General Information
General Information Location Recommendations Figure 1. Remote Human Interface Panel The microprocessor module is mounted inside a molded plastic enclosure for surface mounting. It is not weatherproof making it applicable for indoor use only. The Remote Human Interface Panel should be located in an area to insure that the communication link between the panel and the Unit or Units does not exceed 5,000 feet maximum or pass between buildings, see... - Page 6 General Information b. Remove the recessed hinge screw from the left 3. Remove the enclosure and drill the necessary holes in hand bottom end of the panel. the surface for the appropriate fasteners, (plastic anchors, molly bolts, screws, etc.) c. Unlatch the door of the enclosure as if to open it, and slide the left hand side of the door upward away 4.
- Page 7 General Information Figure 2. Mounting Holes and Knockout Locations ATTE Wiring the Remote Human – Communication link wiring must be 18 AWG shielded twisted pair (Belden 8760, or equivalent). Interface – Communication link must not exceed 5,000 feet maximum for each link. Table 1, p.
- Page 8 General Information starting of the unit by un-authorized personnel while completing the wiring at the Rooftop Unit. WARNING Hazardous Voltage! At the Rooftop Unit Disconnect all electric power, including remote disconnects before servicing. Follow proper lockout/ Connect the opposite end of the three (3) conductor 24 volt tagout procedures to ensure the power can not be wire to the appropriate terminal strip as follows: inadvertently energized.
- Page 9 General Information Figure 4. Typical inter-connecting Wiring Diagram (Panel to Unit #1) 2309-3601 Figure 5. IPak II Typical inter-connecting Wiring Diagram (Panel to Unit #1) RT-SVN16B-EN...
- Page 10 General Information Figure 6. IPak I Typical inter-connecting Wiring Diagram (Panel to Unit #1) Multiple Unit Operation In a multiple unit configuration, the Remote Human Interface Panel has the capability to communicate and To complete the installation of the remote Human control up to four (4) Units.
