Trane IntelliPak Signature Series Programming Manual page 31

a. if no further changes are required and you want to
exit back to view the unit operationg status, press
the STATUS key once, or
b. if you want to remain in the temperature input
calibrartion submenu, press the SETUP key once
and it will return you to the beinning of that
particular submenu, or
Calibration and Offset Submenu
Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section or press ENTER key to vbiew the following
screens.
Temperature Calibration Offset For
RTM Zone Temperature Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
RTM Aux Temperature Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
RTM Outside Air Temperature Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
Heat Module Aux Temp Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
ECEM Return Air Temperature Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
WSM Entering Water Temp Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
WSM Mixed Air Temp Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
WSM Ent Cond Water Temp Input
1. Press the NEXT key until the following screen is displayed.
Temperature Calibration Offset For
Ckt 1 Sat Cond Temp Input
1. Press the NEXT key until the following screen is displayed.
PKG-SVP01E-EN
c. if you want to exit to another submenu in the SETUP
menu, press the SETUP key twice.Then press the
NEXT key to scroll through the SETUP sebmenu
cho98ices, or
d. if you want to exit to another menu, such as
CONFIGURATION, press that key once, then press
the NEXT key to scoll through tose screens.
0.0 F
0.0 F
0.0 F
0.0 F
0.0 F
0.0 F
0.0 F
0.0 F
0.0 F
Programming SETUP
Used with: All Units
Used With: All Units
Factory Presets: 0.0 F
Possible Values: Plus or Minus 5.0 F
Used With: All Units
Factory Presets: 0.0 F
Possible Values: Plus or Minus 5.0 F
Used With: All Units
Factory Presets: 0.0 F
Possible Values: Plus or Minus 5.0 F
Used With: All Units when Electric, or Hydronic
Heat is installed
Factory Presets: 0.0 F
Possible Values: Plus or Minus 5.0 F
Used With: All Units when comparative
enthalpy is installed
Factory Presets: 0.0 F
Possible Values: Plus or Minus 5.0 F
Used With: Water-cooled units and /or units
with waterside economizer is installed
Factory Presets: 0.0 F
Possible Values: 0.0-5.0 F
Used With: Water-cooled units and /or units
with waterside economizer is installed
Factory Presets: 0.0 F
Possible Values: 0.0-5.0 F
Used With: Water-cooled units and /or units
with waterside economizer is installed
Factory Presets: 0.0 F
Possible Values: 0.0-5.0 F
Used With: Water-cooled units and /or units
with waterside economizer is installed
Factory Presets: 0.0 F
Possible Values: 0.0-5.0 F
