Trane IntelliPak Signature Series Programming Manual page 25

End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key to leave the submenu and show following screen.
Economizer Control Functions Submenu
Press ENTER to Review or Adjust
1. Pressing the NEXT key will bypass this section.
Economizer Priority
Choose Which Economizer Stages Up First
1. Press the + or - key until the proper value is displayed.
Unocc Water Economizer Function:
1. Press the NEXT key until the following screen is displayed.
Unocc Air Economizer Function:
1. Press the NEXT key until the following screen is displayed.
Disable WS Econ If Difference Between MA
Temp and Ent Water Temp Less Than 4.0 F
1. Press the NEXT key until the following screen is displayed.
End of Submenu (NEXT) to Enter SETUP
1. Press the NEXT key to leave the submenu and show following screen.
2. Press PREVIOUS to page back through the submenu.
Water Flow Control Setup Submenu
Press ENTER to Review or Adjust
1. Press the NEXT key until the following screen is displayed.
Periodic Water Purge Function:
Interval: 1Hr
1. Press the NEXT key until the following screen is displayed.
Water-Flow Init Time Delay:
Time to Establish Water Flow Before Diag
1. Press the NEXT key until the following screen is displayed.
Temp Stabilization Time Delay:
Water Flow Time for Valid Temp Readings
1. Press the NEXT key until the following screen is displayed.
Head Pressure Control Inactive Min:
Head Pressure Control Active Min:
1. Pressing the NEXT key will bypass this section.
PKG-SVP01E-EN
ENABLED
ENABLED
Duration: 1 Min
1 Min
Enabled
1 Min
10%
30%
Programming SETUP
Used with: Units with an airside or waterside
conomizer.
Possible Values: Waterside Econ, Airside Econ
Used with: Units with an airside or waterside
conomizer
Possible Values: Waterside Econ, Airside Econ
Used With: Units with a waterside economizer
installed
Factory Presets: Enabled
Possible Values: Enabled, Disabled
Used With: All Units when an airside
economizer is installed
Factory Presets: Enabled
Possible Values: Enabled, Disabled
Used With: Units with a waterside economizer
installed
Used With: All units water-cooled and all units
with waterside economizer installed
Used With: All units water-cooled and all units
with waterside economizer installed
Possible Values: Enabled, Disabled; Interval
= 1-999 Hrs; Duration = 1-9 Min
Used With: All units water-cooled and all units
with waterside economizer installed
Possible Values: 0-20 Min
Used With: All units water-cooled and all units
with waterside economizer installed
Possible Values: 0-20 Min
Used With: All units water-cooled units
Possible Values: 0-100%
25
