Initiate programming

0 Switching on and off the programming
mode of the system
1 Activate the programming mode of the
device
enter the master code (start with the pro-
gramming within the next 2 min)
Correct input
Wrong input, unknown master code
No input

Programming

2a Determine/change access codes
first access code
second access code
etc.
2b Send protocol when entering the code
2c Delete data set
for a specific memory location
2d Enter the AS address
at the control unit:
∙ Shortly press the RUN/PROG button, the LED blinks.
∙ Shortly press the RUN/PROG button, the LED lights up.
At the Axx5xxx0:
the two-coloured LED flashes green for 2 min
Input: * master code # (WE = 12345678)
A positive acknowledgement tone (1 x beep) sounds for 1 sec. The LED
blinks green for 2 min.
The device is ready for the programming.
A negative acknowledgement tone (3 x beep) sounds when pressing the
#-key. You can only enter a code 3 times incorrectly. Afterwards the
code input is locked for 2 min.
Then start again.
If no command is entered within the next 2 minutes, the device auto-
matically quits the programming mode. The LED expires.
Input: * 0 # SpNo1 # access code # access code #
Input: * 0 # SpNo2 # access code # access code #
SpNo = 1 to 10
access code = number with a maximum of 8 digits
When changing the code, the old code is overwritten wirh the new one.
Input: * 2 # SpNo # P #
SpNo = 1 to 10 (WE = 0 for SpNo 1 to 10)
P = 0 (door release protocol with unique AS address)
1 (control function1 with unique serial number)
6 (control function SpNo with unique serial number)
Input: * 3 # SpNo #
SpNo = 1 to 10 (data set inactive)
Input: * 4 # AS-address #
AS address = 0 to 63 (WE = 0)
P – protocol selection
