Current Statistics Screens for the DS1 Interface

Examples of current statistics screens are shown below.
interface at the remote unit and line unit, respectively. These screens report 1-day, 1-hour, and 15-minute statistics.
Refer to Table 15 on page 39
Monitor Performance
-----------------------------------------------------------------------------
1 Day
Start 00:00
CV-L
ES-L
SES-L
UAS-L
PDVS-L
ES-P
SES-P
UAS-P
PRM-NE
PRM-FE
B8ZSS
MSEC 3482
------------------------------------------------------------------------------
Use <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
Monitor Performance
-----------------------------------------------------------------------------
1 Day
Start 00:00
CV-L
ES-L
SES-L
UAS-L
PDVS-L
ES-P
SES-P
UAS-P
B8ZSS
MSEC 3482
------------------------------------------------------------------------------
Use <Space> to cycle through
choices and <Enter> to view
ID: xxxx--xxxx--xxxx--xxxx
42
for descriptions of the kinds of errors reported on these screens.
Event Log Config
H2TU-R DS-1 Current Statistics
1 Hour 15 Min
12:00 12:30
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
No PRM Detected
No PRM Detected
0 0 0
1801 1
Press: C(l)ear Current Statistics
Interface
Statistics :
08/01/2001 07:05:33
Figure 22. H2TU-R DS1 Current Statistics
Event Log Config
H2TU-C DS-1 Current Statistics
1 Hour 15 Min
12:00 12:30
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
0 0 0
1801 1
Press: C(l)ear Current Statistics
Interface
Statistics :
08/01/2001 07:05:33
Figure 23. H2TU-C DS1 Current Statistics
