Robin SmartView Manual page 18

Phonebook:
The green '+' creates a new line.
The '>>' behind a line opens the details for this line.
The red X behind a line deletes the line from the list.
 Description
 Number (see
comment)
 Profile
 Allow register
! Note: The number can be entered in various ways.
1. Just the number (e.g. 104, 1002, 6032 etc.). The handset is located on a connected PBX
in the same network.
2. The number, followed by the IP address of the handset that is to be dialled (e.g.
1000@10.0.0.53, 102@192.168.1.21 etc.). The handset and the Robin SV are
connected to each other directly, i.e. the call is not routed via a PBX. The Robin SV dials
the handset directly.
3. The number, followed by the IP address of a 'Proxy server'. The handset is connected to
a PBX that uses a separate 'Proxy server' (e.g. 1003@192.168.0.50, 703@172.16.2.5
etc.) The Robin SV places the call to the configured PBX via this 'Proxy server'. !
* Peer to Peer connection: If a direct connection between the Robin SV and a telephone set is
required - without the use of a SIP-PBX - please check our whitepaper: 'Peer to Peer connection'
on our support website: http://support.robin.nl
gf17
The name that is associated with this number.
The value entered for the telephone number (see
comment).
If required, you can select a 'Profile' for this number.
Select this option if the Robin SV has to support a
'Peer to Peer' connection with a telephone set (*)
Manual Robin SV ENG - v. 1.6
17
