3.3 Tools and materials required for mounting

The following are required when mounting the Robin SV:
 core drill, 90 mm in diameter
 masonry drill, 6 mm in diameter
 stone chisel
 general set of tools
anti-theft Allen key (supplied)

anti-theft screws (supplied)

 6mm wall plugs (supplied)
 drilling template (supplied)
 tie wrap (supplied)

3.4. Mounting instructions

Follow the step-by-step plan described below for problem-free mounting of the Robin SV.
Step-by-step plan:
1. Drill two holes of 90 mm in diameter and 60 mm in depth.
Use the drilling template supplied in the package for this.
2. Remove the cores from the drillings using the stone chisel.
Shape the hole so that the plastic housing of the Robin SV fits with room to spare.
3. Feed the cable into the hole, leave enough excess length for a loop in the hole.
4. Drill the four fixing holes for the front panel using the drilling template and insert the wall
plugs supplied with the set into the holes.
5. Connect the ethernet cable to the clamb connector. (page 10)
6. Optional - connect the cable for operating the door switch to the clamb connector.
7. Secure the cable to the plastic housing using a tie-wrap.
8. Position the Robin SV in the hole in such a way that the looped cable fits neatly behind the
device.
9. Fix the device securely in place using the anti-theft screws supplied in the package.
