NetPerformer SDM-8400 Hardware Installation Guide
The following table describes the RJ-45 pinout for the LAN port.
4-6
Pin No. Usage
1 TX+
2 TX-
3 RX+
4 –
5 –
6 RX-
7 –
8 –
Table 4-4: RJ-45 pinout for Ethernet LAN port
Description
Transmit (+) Output
Transmit (-) Output
Receive (+) Input
(not used)
(not used)
Receive (-) Input
(not used)
(not used)
