Hussmann RL2W Installation & Operation Manual page 45

3-2 D
rIp
Field-Installed
Drop Piping
Field-Installed
Coupling
Field-Installed
Water Seal
1. Tee is factory-installed. Do not overtighten
threads, or the drain fitting or tee may become
damaged.
2. Do NOT use thread sealer on ABS drain fitting.
If sealer is used the ABS drain fitting may crack
or leak! (If a tee needs to be installed it should
be tightened no more than 4 turns.) Do not
overtighten threads.
3. Dry fit the supplied water seal / trap to ensure
approximately /
1
2
bottom of the trap to the floor as shown.
P/N 3053328_C
p s
IpIng anD plashguarDs
Merchandiser
Bottom
Approx.
Approx.
Do NOT use Thread Sealer on Drain Fitting!
Do NOT use Thread Sealer on Drain Fitting!
in. of clearance from the
Merchandiser
Bottom
Maintain Clearance
to Bottom of Case
Field-Installed
Water Seal
Floor
U.S. & Canada 1-800-922-1919 • Mexico 1-800-890-2900 • WWW.HUSSMANN.COM
TEE-SIDE
1 / 1 / in. Clearance to Floor
in. Clearance to Floor
2
2
Factory-Installed
Factory-Installed
NOTE: It may be necessary to rotate water seal (trap)
inside the tee a few degrees to ensure clearance at
two locations. There must be clearance 1) between
the bottom of the water seal and the floor, and 2)
between the top of the water seal outlet and the
bottom of the merchandiser. Do not over-rotate or
gravity seal may be compromised. Always rotate trap
bottom toward merchandiser support rail.
Waste Outlet
(Drain Fitting)
(Drain Fitting)
Factory Installed (four turns)
Factory Installed (four turns)
Field-Installed
Adapter
Tee Fitting
Tee Fitting
Front of
Merchandiser
Waste
Outlet
Rotate Water Seal
Rotate Water Seal towards
towards back of
back of Merchandiser if
Merchandiser if required
required
/ in. Clearance to
1
2
Floor
Field-Installed
Plug
