- Page 1 Products Solutions Services SD02226D/06/EN/01.18 71402820 Valid as of version 01.00.zz (Device firmware) Special Documentation Proline Promass 300 PROFIBUS DP Web server...
-
Page 3: Table Of Contents
Proline Promass 300 PROFIBUS DP Table of contents Table of contents About this document ....4 Document function ..... -
Page 4: About This Document
• Via the W@M Device Viewer: enter the serial number from the nameplate (www.endress.com/deviceviewer) • Via the Endress+Hauser Operations App: enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. Technical documentation can also be downloaded from the Download Area of the Endress+Hauser web site: www.endress.com... - Page 5 Proline Promass 300 PROFIBUS DP About this document Symbol Meaning CAUTION! This symbol alerts you to a dangerous situation. Failure to avoid this situation can CAUTION result in minor or medium injury. NOTE! This symbol contains information on procedures and other facts which do not result in NOTICE personal injury.
-
Page 6: Basic Safety Instructions
It meets general safety standards and legal requirements. It also complies with the EC directives listed in the device-specific EC Declaration of Conformity. Endress+Hauser confirms this by affixing the CE mark to the device. Endress+Hauser... -
Page 7: Security
Proline Promass 300 PROFIBUS DP Basic safety instructions IT security Our warranty is valid only if the device is installed and used as described in the Operating Instructions. The device is equipped with security mechanisms to protect it against any inadvertent changes to the settings. - Page 8 Basic safety instructions Proline Promass 300 PROFIBUS DP • User-specific access code Protect write access to the device parameters via the local display, Web browser or operating tool (e.g. FieldCare, DeviceCare). Access authorization is clearly regulated through the use of a user-specific access code.
- Page 9 Proline Promass 300 PROFIBUS DP Basic safety instructions This includes organizational security measures such as the assignment of access authorization as well as technical measures such as network segmentation. Endress+Hauser...
-
Page 10: Product Features And Availability
Product features and availability Proline Promass 300 PROFIBUS DP Product features and availability Product features Thanks to the integrated Web server, the device can be operated and configured via a Web browser and via a service interface (CDI-RJ45) or via a WLAN interface. The structure of the operating menu is the same as for the local display. -
Page 11: Commissioning
Proline Promass 300 PROFIBUS DP Commissioning Commissioning Establishing a connection to the integrated Web server 1. Configure the computer → 11. 2. Check the settings on the measuring device and change them if necessary → 17. 3. Connect the measuring device to the computer → 17. - Page 12 Commissioning Proline Promass 300 PROFIBUS DP JavaScript JavaScript must be enabled. If JavaScript cannot be enabled: enter http://192.168.1.212/basic.html in the address line of the Web browser. A fully functional but simplified version of the operating menu structure starts in the Web browser.
- Page 13 Proline Promass 300 PROFIBUS DP Commissioning Configuring IP settings for Windows • To configure the IP settings, appropriate user rights (e.g. administrator rights) are required for the computer. • Before configuring the IP settings, close all the windows of the Web browser.
- Page 14 Commissioning Proline Promass 300 PROFIBUS DP 6. Right-click to open the picklist and select Properties. The Local Area Connection Properties dialog box opens. A0024300 7. Select the Internet Protocol Version 4 (TCP/IPv4) item. 8. Click the Properties button. The Internet Protocol Version 4 (TCP/IPv4) Properties window opens.
- Page 15 Proline Promass 300 PROFIBUS DP Commissioning 10. Enter the IP address, subnet mask and default gateway as indicated in the following table and then click Ok to confirm. Standard settings for IP address, subnet mask and default gateway IP address 192.168.1.XXX...
- Page 16 Commissioning Proline Promass 300 PROFIBUS DP Changing the proxy server settings To establish communication, the proxy server setting Use a Proxy Server for Your LAN must be deselected for the Web browser. To change the proxy server setting, appropriate user rights (e.g. administrator rights) are required for the computer.
-
Page 17: Prerequisites - Measuring Device
Proline Promass 300 PROFIBUS DP Commissioning Prerequisites - measuring device 4.2.1 Enabling the Web server The Web server must be enabled in the measuring device (factory setting). If the Web server is disabled it be enabled again via the Web server functionality parameter (→... - Page 18 Commissioning Proline Promass 300 PROFIBUS DP 3. If a 2nd network card is not used, close all the applications on the notebook. Applications requiring Internet or a network, such as e-mail, SAP applications, Internet or Windows Explorer. 4. Close any open Internet browsers.
-
Page 19: Establishing A Connection To The Web Server
Proline Promass 300 PROFIBUS DP Commissioning Establishing a connection to the Web server 4.4.1 Prerequisites The IP settings in the measuring device and computer must match before a connection can be established successfully. In particular this concerns the IP addressing and Web browser settings. -
Page 20: Setting The Ip Address
Commissioning Proline Promass 300 PROFIBUS DP Setting the IP address The IP address of the measuring device is required to establish communication between the measuring device (Web server) and a computer (client). Assign or specify the IP address via: Description The use of the standard IP address •... - Page 21 Proline Promass 300 PROFIBUS DP Commissioning Subnet mask (7211) → 21 Default gateway (7210) → 21 Web server functionality (7222) → 22 Login page (7273) → 22 Parameter overview with brief description Parameter Description Selection / User interface / ...
- Page 22 Commissioning Proline Promass 300 PROFIBUS DP Parameter Description Selection / User interface / Factory setting User entry Web server functionality Switch the Web server on and off. • Off • HTML Off • On Login page • Without header With header • With header...
-
Page 23: Operation Options
Proline Promass 300 PROFIBUS DP Operation options Operation options A0031139 2 Example of a Proline flowmeter with an integrated Web server Mobile end device with Web browser (e.g. Internet Explorer) and WLAN interface Computer with Web browser (e.g. Internet Explorer), connection via cable or WLAN interface... -
Page 24: User Interface
Operation options Proline Promass 300 PROFIBUS DP Access code 0000 (factory setting); can be changed by customer If no action is performed for 10 minutes, the Web browser automatically returns to the login page. User interface A0029418 Function row Local display language Navigation area 5.2.1... -
Page 25: Logging Out
Proline Promass 300 PROFIBUS DP Operation options Functions Meaning Configuration and checking of all the parameters required for establishing the connection to Network the measuring device: configuration • Network settings (e.g. IP address, MAC address) • Device information (e.g. serial number, firmware version) -
Page 26: Diagnostics And Troubleshooting
Diagnostics and troubleshooting Proline Promass 300 PROFIBUS DP Diagnostics and troubleshooting For details on the diagnostic information, see the Operating Instructions for the device → 4. General Web server troubleshooting For access Error Possible causes Solution Not connecting to Web server Web server disabled Using the "FieldCare"... -
Page 27: Diagnostic Information In The Web Browser
Proline Promass 300 PROFIBUS DP Diagnostics and troubleshooting Diagnostic information in the Web browser 6.2.1 Diagnostic options Any faults detected by the measuring device are displayed in the Web browser on the home page once the user has logged on. -
Page 28: Diagnostic Information In The Measuring Device
Diagnostics and troubleshooting Proline Promass 300 PROFIBUS DP Diagnostic information in the measuring device 6.3.1 Overview of Web server information events Unlike a diagnostic event, an information event is displayed in the event logbook only and not in the diagnostic list. -
Page 29: Technical Data
Proline Promass 300 PROFIBUS DP Technical data Technical data Web server Stack: standard TCP stack with IPv4 functionality Connection and session management • Fixed IP address, i.e. no access possible from outside the network • Open ports: – 80 (HTTP for Web server) –... - Page 32 www.addresses.endress.com...
