INSTALLATION INSTRUCTIONS
1
1. To install Seal Trap Primer,
remove set plug with standard
Allen Key (3/16", not included) by
rotating tool counter clockwise
approximately 8 turns.
Prior to inserting adapter, put thread
seal tape on tapered thread for sealing
valve body against leakage.
9
4
10
4. From under the sink, thread
mounting nut/washer (10)
(large side up) onto faucet
shanks (9).
Check faucet
position
and
alignment
on
sink
top,
HAND-TIGHTEN. Connect
supplies to faucet shanks
(hot - left, cold - right).
7
STEM
®
STEM
®
KEY
KEY
®
NOTCH
NOTCH
2
2. Be sure mounting surface is
clean and dry. Holding faucet
assembly upside down, place
a
plumber's putty in the groove
of the deck plate (8).
CAUTION: Always turn water OFF before removing or disassembling
the valve. Open valve handles to relieve water pressure to insure that
complete water shut-off has been achieved.
5
5. To connect supply lines
(not included), thread
onto
faucet
finger tight. Then tighten
with a wrench by rotating
then
one half turn.
7. Loosen and unscrew the cartridge nut (4) with adjustable wrench.
cartridge stem with pliers, pulling cartridge (5) straight up and out.
To reassemble, reverse the steps above.
CAUTION: Be careful not to damage the rubber seals on the cartridge when re-
!
installing cartridge. During installation be sure of the following.
• Turn stem to ON position
• Waterway holes in cartridge are lined up
• Key in cartridge fits into notch on body
• Start cartridge nut by hand
• Do not cross thread, tighten firmly
1/4"
(6mm)
bead
of
6
Disassembly
supplies
6. Carefully remove handle cap (1) with a flatbladed
screwdriver. Remove handle screw (2) and handle (3).
3
3. Place faucet in position on
the sink, being careful not to
disturb the putty bead.
HANDLE
CAP
HANDLE
SCREW
HANDLE
KNOB
Then grasp
2
