Alarm & Warning Messages
MESSAGES
EXPLANATION
OR CONDITIONS
(X) CUP OUT AT STATION (Y)
The cup tube for size (X) is empty at
station (Y).
CLEAR SYRUP SOLD OUT
The clear syrup (SPRITE) is sold out
(EMPTY B.I.B.).
LOW ICE - REFILL SOON
Ice level in the ice bin is too low.
CLEAR CUP JAM
Cup(s) jammed in the conveyor at the cup
extraction position and the conveyor and
turret are unable to operate.
Cup Tubes.
Loose or Missing Hardware.
Cups.
NO CUP EXTRACTED
The gripper did not or could not extract a
cup from the cup tube.
Grabber Pads.
C02
Cup Tubes.
Cups
TURRET STALLED
Turret unable to rotate clockwise or
counter-clockwise.
CONVEYOR STALLED
Cup(s) jammed in the conveyor at the cup
extraction position and the conveyor and
turret are unable to operate. Does the
conveyor rotate?
CONVEYOR NOISE
Audible noise as conveyor turns.
CUP HOLDERS
Loose on conveyor belt.
AIR OR C02 LOW OR OUT
C02 supply is low or empty or air
compressor not operating.
© 2008 IMI CORNELIUS
To order job aid cards contact Coca-Cola Parts: 1-800-638-2653 Part #111099
WWW.CORNELIUS.COM
620807805D Revision: B
ABS Alarms and Troubleshooting
®
SOLUTION
Refill the empty cup tube with the correct cup size and then press ENTER to continue dispensing.
Connect a new syrup supply and the ABS unit will continue. If the ENTER button is pressed
before the syrup supply is replenished, automatic operation will resume but only the cup and ice
will be dispensed for this flavor.
Refill the ice bin with ice. Press ENTER. Alarms may continue for up to 15 minutes.
Remove all cups from the conveyor cup holders at the EXTRACT POSITION before pressing the
ENTER button. Another cup will be extracted and dispensing will continue.
Over stacking of cups in cup tubes. Do not fill above the top of the cup tube.
Cup tube fingers are damaged (bent), replace all four fingers.
Cup tubes not properly mounted. Remove and remount cup tubes.
Check each cup tube to insure all hardware is present on the cup tube. Replace any missing
hardware.
Cups are packed together and will not separate.
Check cup supply at the extract station and make sure the cups are not stuck. Make sure the
gripper pads are not damaged.
Wet, dry off. If damaged, replace.
Check bulk C02 tank, if empty go to back up C02 and turn on.
Cup tube fingers are damaged (bent), replace all four fingers.
Cups are packed together and will not separate.
Clear obstruction (lid holder, cup tube or cups). Press ENTER
Remove all cups from the conveyor cup holders at the EXTRACT POSITION before pressing the
ENTER button. Another cup will be extracted and dispensing will continue. Make sure conveyor
is installed correctly. Repair or Replace.
Remove conveyor and clean.
Three screws hold the cup holder firm to the conveyor belt. Tighten screws till firm
(DO NOT OVERTIGHTEN). Use kit 14461.
Change C02 cylinder or have bulk tank refilled. Check cause not operating and repair.
When an alarm occurs, press the SILENCE/ALARM button to silence the alarm. Read the display to determine the problem so that the
appropriate corrective action can be taken. LEFT and RIGHT arrows are used to scroll the alarm list and the number of unresolved warnings
and alarms are displayed with direction cues to scroll. Listed below are the Alarm and Warning messages that may appear on the display screen.
-or-
www.3Wire.com
3Wire Part #1039561
FLOAT
COKE SMALL PARTS 1-800-241-2653
Ask for Small Parts Department. Part orders less than
$15/order are FREE. Prices subject to change.
Listed below are the most common parts needed.
14461
Conveyor Backing Plate Kit
16586
Nozzle Brush
19136
Valve Nozzle
20297
Deflector, Syrup (Diffuser)
20482
Small Nut, Cup Tube
20483
Acorn Nut 6x32
20484
Large Nut, Cup Tube
20582
Plastic Spacer for Cup Tube
20652
Cup Locator Spring
20669
Water Deflector
20763
Screw for Front Panel
20881
Clinch Stud, Cup Tube
20882
Lock Nut for Cup Tube
28074
Cup Fingers 16, 21, 42 oz.
28075
Cup Fingers 12, 32 oz.
28076
Ice Chute Brush
$1.16
$0.50
$2.63
$6.10
$3.42
$0.43
$3.27
$0.79
$7.71
$0.97
$0.41
$0.29
$0.03
$4.75
$4.93
$8.79
