1.
To make assembly easier, read the
information on page 5 before you begin
assembling the elliptical.
Remove the shipping bracket (not shown)
inserted into the underside of the Frame (1).
Then, remove the two M10 x 120mm Screws
(58) and the shipping bracket (not shown)
attached to the front of the Frame. Discard the
shipping brackets. Do not discard the two M10
x 120mm Screws.
Orient the Stabilizer (49) with the Wheels (8) in
the position shown. While a second person tips
the Frame (1) backward, attach the Stabilizer to
the Frame with the two M10 x 120mm Screws
(58).
2. Identify the Right Handlebar (36), which is
marked with an "R" sticker, and orient it as
shown. Attach the Right Handlebar to the Frame
(1) with the Upper Body Cap (34) and three M6
x 18mm Screws (57).
Repeat this step to attach the Left Handlebar
(22).
All manuals and user guides at all-guides.com
6
1
1
2
22
1
8
58
8
49
36
34
57
