Tascam CD-01U User Manual

Tascam cd player - compact disk player user manual.


TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications
TASCAM CD-01U/CD-01UPRO
CONTROL I/O Terminals
RS-232C Protocol Specifications
Ver. 1.02
July 2005
TEAC
1
TEAC Corporation

Summary of Contents

  • Page 1

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications TASCAM CD-01U/CD-01UPRO CONTROL I/O Terminals RS-232C Protocol Specifications Ver. 1.02 July 2005 TEAC TEAC Corporation...

  • Page 2

    1. Overview The CD-01U/CD-01U PRO (here referred to as “controlled device”) functions can be controlled using a serial RS-232C connection from an external device, such as a computer. Such a device is referred to here as the “external controller”. 2. Specifications 2.1.

  • Page 3

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications CD-01U/CD-01U PRO External controller TEAC Corporation...

  • Page 4

    (1), the “units” digit (2), the “thousands” digit (0), and the “hundreds” digit (0). 3.2. Machine ID Machine ID of this device is fixed to [0]. A command with other Machine ID than [0] is ignored. TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications Byte 5 Byte 6...

  • Page 5

    CURRENT TRACK INFORMATION SENSE CURRENT TRACK TIME SENSE TOTAL TRACK No./TOTAL TIME SENSE PGM TOTAL TRACK No./TOTAL TIME SENSE ERROR SENSE TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications Return Command TIME DATA INFORMATION RETURN AUTO CUE LEVEL RETURN PITCH CONTROL DATA RETURN...

  • Page 6

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications Version up history Ver. 1.00: Released version. Ver. 1.02: Following commands to be added. PITCH CONTROL DATA PRESET [25] FADE IN/OUT TIME PRESET [2E] EOM TRACK TIME PRESET [32] TIMER RESUME PLAY SELECT [34]...

  • Page 7

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 3.4. Command Sequence The CD-01U/CD-01U PRO does not have the “ACK” command for the each transport control command and data preset command. When a request command is transmitted from external controller to the controlled device, the controlled device sends an appropriate return command.

  • Page 8

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4. Command Detail Commands, data, and machine IDs which are described here are represented in characters (ASCII). A command is a 2-byte character, a Machine ID is a 1-byte character, and each data is a 1-byte character.

  • Page 9

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-6. SHUTTLE Performs the search function in SHUTTLE mode. SHUTTLE mode is maintained until the other command such as STOP, PLAY, or READY is received. Command Data 2 bytes Return None Data 1 Data 2...

  • Page 10

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-10. AUTO CUE LEVEL PRESET Sets the Auto Cue level of the controlled device. When this command is transmitted with request data ([FF]), the controlled device returns the AUTO CUE LEVEL RETURN command [A0].

  • Page 11

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-12. PITCH CONTROL DATA PRESET Sets the Pitch Control value from –12.5% to +12.5% in 0.1% steps. When this command is transmitted with request data ([FF]), the controlled device returns the PITCH CONTROL DATA RETURN command [A5].

  • Page 12

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-14. FADE IN/OUT TIME PRESET Sets the fade in and out time from 1 to 10 seconds in 1 second steps. When this command is transmitted with request data ([00FF] or [01FF]), the controlled device returns the FADE IN/OUT TIME RETURN command [AE].

  • Page 13

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-17. TIMER/RESUME PLAY SELECT Turns the Power-on-play mode and Resume Play mode on and off. When this command is transmitted with request data ([FF]), the controlled device sends the RESUME PLAY SELECT RETURN command [B4].

  • Page 14

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-20. REPEAT SELECT Sets the Repeat mode. When this command is transmitted with request data [FF], the controlled device returns the REPEAT SELECT RETURN command [B7]. Command Data 2 bytes Return REPEAT SELECT RETURN [B7]...

  • Page 15

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-23. TIME DATA SEND SELECT Sets the Time mode of the time data that is sent out from the controlled device automatically (without any request command). When this command is transmitted with request data [FF], the controlled device returns the TIME DATA SEND SELECT RETURN command [BF].

  • Page 16

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-27. ISRC SENSE Requests the output of the ISRC code of the current track (ready mode) or the catalog (stop mode). This data can only be output when a playback-only disc is loaded. Command...

  • Page 17

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 4-34. ERROR SENSE Should be transmitted by the external controller on receipt of an ERROR SENSE REQUEST [F0] from the controlled device, to determine the exact error. The contents of the reply are described in the ERROR SENSE RETURN command.

  • Page 18

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5. Return Command Detail 5-1. TIME DATA When the Time mode is set to other than “OFF” with TIME DATA SEND SELECT command [3F], controlled device outputs the time data in specified form by TIME DATA SEND SELECT command [3F].

  • Page 19

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-4. PITCH CONTROL DATA RETURN Transmitted in response to a PITCH CONTROL DATA PRESET command [25] with the request data ([FF]) to show the currently set Pitch Control value. Command Data 4 bytes Request command PITCH CONTROL DATA PRESET [25]...

  • Page 20

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-8. TIMER/RESUME PLAY SELECT RETURN Transmitted in response to a TIMER/RESUME PLAY SELECT command [34] with the request data ([FF]) to show the currently set the Power-on-play/Resume function status . Command Data 2 bytes...

  • Page 21

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-12. INCR PLAY SELECT RETURN Transmitted in response to an INCR PLAY SELECT command [3A] with the request data ([FF]) to show the currently set the Incremental Play function status . Command Data 2 bytes...

  • Page 22

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-16. MECHA STATUS RETURN Transmitted in response to a MECHA STATUS SENSE command [50] and gives the current mechanism status of the controlled device. Command Data 2 bytes Request command MECHA STATUS SENSE [50]...

  • Page 23

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-19. DISC STATUS RETURN Transmitted in response to a DISC STATUS SENSE command [56], giving the status of the loaded disc. Command Data 4 bytes Request command DISC STATUS SENSE [56] Data 1 Disc Status...

  • Page 24

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-21. CURRENT TRACK TIME RETURN Transmitted in response to a CURRENT TRACK TIME SENSE command [58], giving the specified form of the time data of the current track. Command Data 10 bytes Request command CURRENT TRACK TIME SENSE [58]...

  • Page 25

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-23. PGM TOTAL TRACK No./TOTAL TIME RETURN Transmitted in response to a PGM TOTAL TRACK No./TOTAL TIME SENSE command [5E], giving the total number of the programmed tracks and the running time of the programmed tracks.

  • Page 26

    TASCAM CD-01U/CD-01U PRO RS-232C Protocol Specifications 5-28. ERROR SENSE RETURN Transmitted in response to an ERROR SENSE command [78], giving the specific error that has occurred. Command Data 4 bytes Request command ERROR SENSE [78] Data 1 Data 2 Data 3 Data 4 *** Your unit must be version V1.02 for these commands to be supported.
