Interrupt Subroutines
Example 7–8. Hand-Coded Assembly ISR Allowing Nesting of Interrupts
* Assume Register B0–B5 & A0 are the only registers used by the
* ISR and no other functions are called
STW B0,*B15––
|| MVC IRP, B0
STW A0,*B15––
|| MVC IER, B1
|| MVK mask,A0
STW B1,*B15––
|| MVC A0, IER
STW B2,*B15––
|| MVC CSR,A0
STW B3,*B15––
|| OR 1,A0,A0
STW B4,*B15––
STW B5,*B15––
|| MVC A0,CSR
STW B0,*B15––
STW B1,*B15––
STW A0,*B15––
* Beginning of ISR code
...
* End of ISR code
B restore
MVKL 0FFFEh,A0
MVKLH 0FFFFh,A0
MVC CSR,B5
AND A0,B5,B5
MVC B5,CSR
restore
LDW *++B15,A0
LDW *++B15,B1
LDW *++B15,B0
LDW *++B15,B4
LDW *++B15,B3
LDW *++B15,B5
LDW *++B15,B2
|| MVC B0,IRP
B IRP
LDW *++B15,B1
MVC B1,IER
LDW *++B15,A0
LDW *++B15,B0
MVC A0,CSR
7-14
; store B0 to stack
; save IRP
; store A0 to stack
; save IER
; setup a new IER (if desirable)
; store B1 to stack
; setup a new IER (if desirable)
; store B2 to stack
; read current CSR
; store B3 to stack
; set GIE bit field in CSR
; store B4 to stack
; store B5 to stack
; write new CSR with GIE enabled
; store B0 to stack (contains IRP)
; store B1 to stack (contains IER)
; store A0 to stack (original CSR)
; Branch to restore routine
; disable CSR in delay slots of branch
; create mask to disable GIE bit
; read current CSR
; AND B5 with mask
; write new CSR with GIE disabled
; restore routine begins at next line
; restore A0 (original CSR)
; restore B1 (contains IER)
; restore B0 (contains IRP)
; restore B4
; restore B3
; restore B5
; restore B2
; restore original IRP
; return from interrupt
; restore B1
; restore original IER
; restore A0
; restore B0
; restore original CSR
; to complete before branch is taken
