Software Pipelining the Outer Loop
Example 6–71. Final Assembly Code for FIR Filter With Redundant Load Elimination and
No Memory Hits With Outer Loop Software-Pipelined (Continued)
ADD
|| MPY
|| MPY
|| LDH
|| LDH
LOOP:
ADD
|| ADD
|| MPY
|| MPY
|| LDH
|| LDH
ADD
|| ADD
|| MPY
|| MPY
|| LDH
|| LDH
ADD
|| ADD
||[B2] B
|| MPY
|| MPY
|| LDH
|| LDH
||[B2] SUB
ADD
|| ADD
|| MPY
|| MPY
|| LDH
|| LDH
; inner loop branch occurs here
ADD
|| ADD
|| MPY
|| MPY
|| SUB
|| SUB
||[A2] B
6-134
.L1 A0,A9,A9
.M2X A5,B8,B8
.M1X B0,A7,A5
.D2 *B1++[2],B0
.D1 *A4++[2],A0
.L2X A1,B9,B9
.L1X B6,A9,A9
.M2 B5,B8,B7
.M1 A5,A7,A7
.D1 *A8++[2],B6
.D2 *B4++[2],A1
.L2 B7,B9,B9
.L1 A5,A9,A9
.M1X B5,A1,A0
.M2X A0,B6,B6
.D1 *A4++[2],A5
.D2 *B1++[2],B5
.L2X A7,B9,B9
.L1X B8,A9,A9
.S1 LOOP
.M2 B0,B6,B7
.M1 A0,A1,A1
.D2 *B4++[2],A7
.D1 *A8++[2],B8
.S2 B2,1,B2
.L2 B7,B9,B9
.L1 A0,A9,A9
.M2X A5,B8,B8
.M1X B0,A7,A5
.D2 *B1++[2],B0
.D1 *A4++[2],A0
.L2X A1,B9,B9
.L1X B6,A9,A9
.M2 B5,B8,B7
.M1 A5,A7,A7
.D1 A4,A3,A4
.D2 B4,B10,B4
.S1 OUTLOOP
; sum0 += x0 * h0
; x3 * h3
; x2 * h2
;** x2 = x[j+i+2]
;** x1 = x[j+i+1]
; sum1 += x1 * h0
; sum0 += x1 * h1
; x0 * h3
; x3 * h2
;** h1 = h[i+1]
;** h0 = h[i]
; sum1 += x2 * h1
; sum0 += x2 * h2
;* x0 * h0
;* x1 * h1
;** x3 = x[j+i+3]
;** x0 = x[j+i+4]
; sum1 += x3 * h2
; sum0 += x3 * h3
;* branch to loop
;* x2 * h1
;* x1 * h0
;** h2 = h[i+2]
;** h3 = h[i+3]
;** decrement loop counter
; sum1 += x0 * h3
;* sum0 += x0 * h0
;* x3 * h3
;* x2 * h2
;*** x2 = x[j+i+2]
;*** x1 = x[j+i+1]
;e sum1 += x1 * h0
;e sum0 += x1 * h1
;e x0 * h3
;e x3 * h2
;o reset x pointer to x[j]
;o reset h pointer to h[0]
;o branch to outer loop
