Chapter 1
Introduction
Rated for Reliability in Harsh Environments
• Immunity to EMI and heavy electrical surges
• Zero-Packet-Loss™ technology
• -40 to 85 °C (-40 to 185 °F) operating temperature (no fans)
• Conformal coated printed circuit boards (optional)
• 18 AWG galvanized steel enclosure
Universal Power Supply Options
• Fully integrated power supplies
• Device power supply: 24 VDC (10-36 VDC), 48 VDC (36-59 VDC), 88-300 VDC or 85-264 VAC
• Screw or pluggable terminal blocks for reliable, maintenance-free connections
• CSA/UL 60950-1 safety approved to 85 °C (185 °F)
• PoE power supply: 48 VDC
Section 1.2

Description

The RUGGEDCOM RSG2300P features various ports, controls and indicator LEDs on the display panel for
connecting, configuring and troubleshooting the device. The display panel can be located on the rear, front or top
of the device, depending on the mounting configuration.
Figure 1: RUGGEDCOM RSG2300P
1. Fiber or Copper Ethernet Ports    2. Copper Ethernet Port    3. Port Status Indicator LEDs    4. Mode Button    5. RS-232 Serial Console Port
(RJ45)    6. Display Mode Indicator LEDs    7. Alarm Indicator LED    8. Power Module Indicator LEDs
Communication Ports
Port Status Indicator LEDs
2
1
Ports for communicating with other devices or accessing the RUGGEDCOM ROS operating
system are described in
Port status indicator LEDs indicate the operational status of each port, dependent on the
currently selected mode.
Mode
Status
2
Chapter 3, Communication
Ports.
Color/State
Green (Solid)
Green (Blinking)
Off
RUGGEDCOM RSG2300P
Installation Guide
6
7
8
3
4
5
Description
Link detected
Link activity
No link detected
Description
