Page 80 of 136
Chapter 8 — M2250 Attendant Console
553-3121-100
Standard 2.0
•
An optional Busy Lamp Field/Console Graphics Module (BLF/CGM),
which displays the status of up to 150 consecutive extensions (SBLF) or
any group of 100 extensions within the system (EBLF), and has many
text and graphics capabilities.
•
The M2250 provides for transmission level adjustment to meet
international requirements by accepting and processing downloaded
information from the system (when this messaging is supported in
software). The transmission level can be adjusted to one of 16 different
levels.
•
Angle adjustment of the display screen, which can be tilted through 90°
from horizontal to fully vertical
•
Scrolling control of lines 2 and 3 of the display screen
•
Multi-language selection
•
Menus for local console features (options menu) and diagnostics
(diagnostics menu)
•
Code-blue or emergency relay (associated with ICI 0)
•
Time and date system download
•
Alert tone volume and frequency selection
•
Electret or carbon transmitter support
•
Power Fail Transfer switch
•
Keyclick
Figure 15
on
page 82
console with the user-accessible components labeled using a row/column grid
arrangement.
Figure 16
on
page 88
console. These illustrations show where to find the various components as
you read this chapter.
September 1998
shows the top view of the layout of the attendant
shows rear, left-hand side, and bottom views of the
