Page 8 of 136 Chapter 1 — Provisioning
Figure 2
Card slot assignments in Expansion Cabinet
Expansion Cabinet
NTMW11
Power Supply
553-3121-100 Standard 2.0
NTMW10
Empty
Fiber
Slot
Receiver
September 1998
NTMW05, NTMW06, NTMW07
11&12 13&14
PE PE
Card Card
17 18
PE PE
Card Card
NTMW05, NTMW06
15&16
PE
Card
19
PE
Card
