Chapter 7 — Meridian Modular Telephones
553-3121-100
Standard 2.0
The Power Supply Board comes factory installed with any configuration of
the M2016S and M2216ACD-2. The M2006 and M2008 require the Power
Supply Board with the addition of any option. The M2616 requires the Power
Supply Board with any option except the Display Module.
Local plug-in transformer
A single winding transformer equipped with a 10 ft. (3 m) cord of 22 AWG
two-conductor stranded and twisted wire with a modular RJ-11 duplex
adapter (Refer to
Figure 13
needed to operate the telephone and its options.
Do not plug any equipment (computer, modem, LAN card) other than
the Meridian Modular Telephone into the RJ-11 transformer adapter,
as damage to equipment may result.
120 V transformer (AO367335 or equivalent)
The following minimum specifications must be met by this transformer:
•
Input voltage
120 V AC / 60 Hz
•
No load output voltage
29 V AC maximum
•
Voltage at rated current
26.7 V AC minimum
•
Rated load current
700 mA
240 V transformer (AO367914 or equivalent)
The following minimum specifications have to be met by this transformer:
•
Input voltage
240 V AC / 50 Hz
•
No load output voltage
29 V AC maximum
September 1998
on
page
74) can provide the additional power
CAUTION
