4.2. Parameterisation

4.2.1. Module parameters
・
Module parameters for valves
The "16 Valves" has the following module parameters.
Name
Valve Output 0
Valve Output 1
...
Valve Output 15
The "32 Valves" has the following module parameters.
Name
Valve Output 0
Valve Output 1
...
Valve Output 31
Table. 4-4 Module parameters of the "16 Valves"
Range of values
Force to OFF
Force to ON Force to OFF
Hold last state
Force to OFF
Force to ON Force to OFF
Hold last state
... ...
Force to OFF
Force to ON Force to OFF
Hold last state
Table. 4-5 Module parameters of the "32 Valves"
Range of values
Force to OFF
Force to ON Force to OFF
Hold last state
Force to OFF
Force to ON Force to OFF
Hold last state
... ...
Force to OFF
Force to ON Force to OFF
Hold last state
- 24 -
Default
When a bus fault occurs, the output
can be made to react in one of the
following ways:
Force to OFF
Force to ON
Hold last state
Default
When a bus fault occurs, the output
can be made to react in one of the
following ways:
Force to OFF
Force to ON
Hold last state
Meaning
Meaning
