2. General Specifications

Item
Rated voltage
Allowable instantaneous
electrical stop
Protection class
Applicable standard
Withstand voltage
Insulation resistance
Ambient temperature
Ambient humidity
Vibration resistance
Impact resistance
Operating environment
Table. 2-1 EX245 series general specifications
24 V DC
1 msec maximum
IP65 rating (when fully installed or fitted with protective cover)
(complies with IEC 60529)
CE Marked
RoHS directive EN50581:2012
500 VAC 1 min. (between FE and all accessible terminals)
10 M ohm or more
(500 V DC is given between FE and all accessible terminals)
Operation: -10 °C to 50 °C
Storage: -20 °C to 60 °C
35% to 85% RH (non-condensing)
10 Hz to 57 Hz (constant amplitude) 0.75 mm
57 Hz to 150 Hz (constant acceleration) 49 m/s
2 hours for each direction X, Y and Z
2
147 m/s is given 3 times for each direction X, Y and Z
No corrosive gas
