Bionaire EverFresh Air Exchange System BAP336 Instruction Leaflet

BAP33605EM2.qxd 10/14/05 9:27 AM Page 1
TROUBLESHOOTING Routine Maintenance
The Bionaire
Problem Solution
It includes filters that remove dust from air that is circulated through
System will not • Confirm that the unit is plugged into a
the system. These filters will need to be cleaned or replaced with
operate
working electrical outlet.
use. The Service Indicator bar graph on the display (6) shows when
• Confirm that the Damper Switch (1) is
service is needed. The Service Indicator bar graph decreases - and
in the ON position.
when the bars disappear, the filters need to be cleaned. The aver-
• Check to make sure the system is on age duration between cleanings is about three months.
by pressing the Mode Button (2). WARNING: Do not attempt to repair or adjust any electrical or
• Make sure that all bags have been mechanical functions on this unit. Doing so will void the warranty. This
removed from the filters. unit contains no user serviceable parts. Only qualified personnel
should perform servicing—other than what is described in this manual.
Decreased airflow • It should be noted that the air entering
About the Filters
the room is designed to be at a low
There are three black washable filters
flow rate to prevent drafts.
installed in the Air Exchange System.
• Confirm that nothing is blocking the air Each has a single tab that locks
inlet and outlet.
them into the unit. See Figure 18.
• If "SERVICE" is displayed and the per-
There is one two-tab filter installed
formance bars are low, the filters need
in the Air Exchange System. This
to be cleaned. See Routine
will either be a black washable filter
Maintenance Instructions.
or a white disposable Electrostatic
• Check the condition of the filters.
filter. The Electrostatic filter removes
See Routine Maintenance Instructions.
smaller particles from the circulating
air. See Figure 19.
• Check to make sure that the foam seal-
Drafts around
window ing system is correctly installed.
PERFORMING MAINTENANCE
• The leftover foam segments can be
1. Confirm that the Service Indicator
used to seal any remaining openings.
bars (6) no longer illuminate and
the word "SERVICE" displays. This
signals that maintenance is
required.
2. Turn off and unplug the unit.
3. Remove the Air Exchange System
from the Window Sealing Frame: See
Figure 20.
• Grasp each side of the Air
Exchange System and
gently pull it toward you.
• Place the unit on a clean,
level surface.
4. Remove the front grill.
See Figure 21.
5. To remove the rear grill:
See Figure 22.
• Put the unit with the face
down on the surface.
• Place your thumb under
the opening in the rear grill
and pull up. One side of
the grill will lift up and you
will be able to slide the grill
out.
6. Remove the black filters from
openings #2, #3, and #4. Gently
wash these filters with mild soapy
water. Rinse in warm running
water. Shake off excess water
and allow to air dry completely.
See Figure 23.
7. Remove the filter from opening #1.
If it is a white electrostatic filter, dis-
card it and replace with a fresh fil-
ter. Call 1 (800) 253-2764 to order
replacement filters. See Figure 24.
8. If it is a black washable filter,
clean it as described in step 6.
® Air Exchange System is easy to use and maintain.
9. Remove the rubber Vacuum
Plug from opening #5.
See Figure 25.
10. Using a vacuum with a hose
and a crevice tool, GENTLY
vacuum the dust from the core
by accessing openings #2 and
#5. See Figure 26.
CAUTION: Avoid applying
pressure or scraping the surface
of the core with the crevice
Figure 18
tool as this may damage the
core and decrease performance
of the Air Exchange System.
11. Replace the rubber Vacuum
Plug in opening #5. See Figure 25.
12. After the filters are completely dry replace the three black filters
over openings #2, #3, #4.
Figure 19 13. Insert a clean, dry black filter or a new white electrostatic filter
over opening #1.
14. Clean the rear grill with warm soapy water. (Not dish washer
safe). Dry with a soft cloth.
15. Remove dust from the front grill with a small soft brush or cloth.
16. Wipe down the rest of the unit with a clean, damp cloth.
Figure 20
WARNING: DO NOT IMMERSE THE AIR EXCHANGE
SYSTEM IN WATER.
17. Reinstall the rear grill:
See Figure 27.
• Put the unit with the front grill
face down on the surface.
• Place the grill on the rear of the
unit with the thumb opening
toward the bottom (power
Figure 21 cord side) of the unit.
• Gently press down on the
edges of the grill until all edges
are securely latched.
18. Put the unit on the table in the
normal position and replace
the front grill. See Figure 28.
19. Slide the Air Exchange Unit
into the Window Sealing
Figure 22
Frame and push until it locks in
place.
20. Insert the electrical plug into the outlet and turn the unit on.
21. Reset the service indicator by inserting the tip of a paper
clip into the Service Reset Hole (5) and gently pressing the
button inside the hole.
22. The Service Indicator bar graph should reappear.
Opening # 3
Figure 23
Replacement Filters
Opening # 5
Order these filters by calling 1 (800) 253-2764
Opening
Filter Part Q u a n t i t y Description
# 4
Number Required
Opening # 2
1 ea.
APF18 Electrostatic Filter, 2-Tab - Optional
3 ea. Washable Foam Filter
APF19
Figure 24
1 ea.
APF20 Washable Foam Filter
Opening # 1
Service Instructions
Figure 25
If you need to exchange the unit within 30 days of purchase, please
return it in its original carton with the sales receipt to the store from
which it was purchased.
If you need to return the unit beyond 30 days after you purchased
it, review the warranty information provided with the unit and call
1-800-253-2764 for warranty service. You will be given a return
authorization number and instructions returning the unit from the
customer service representative.
Figure 26
WARRANTY
The Manufacturer warrants to the first retail purchaser, for FIVE ( 5 )
YEARS from the date of original purchase, either to repair or replace
at its option, without charge (parts and labor), any supplied or man-
ufactured part of this Air Exchange System which, upon inspection
by an authorized service center, proves to have failed in normal use
due to defects in material or workmanship, or at its option, to
replace the unit. Operation under conditions other than those rec-
ommended or at voltages other than the voltage indicated on the
unit, or any attempts by unauthorized personnel to service the unit
or modify it, will render the guarantee void. The Manufacturer shall
not be liable for any personal injury, property damage or any inci-
dental or consequential damages of any kind (including water dam-
age), resulting from defects, malfunctions, misuse, improper installa-
tion or alteration of the product.
THE MANUFACTURER EXPRESSLY DISCLAIMS ALL
Figure 27 RESPONSIBILITY FOR CONSEQUENTIAL DAMAGES OR
INCIDENTAL LOSSES CAUSED BY USE OF THIS PRODUCT.
The provisions of this Warranty are in addition to, and not a
modification of, or subtraction from the statutory warranties and
other rights and remedies contained in any applicable legislation
and to the extent that any such provision purports to disclaim,
exclude or limit any such statutory warranties or other rights or
remedies, such provisions shall be deemed to be amended to the
extent necessary to comply therewith.
Figure 28
For Warranty Service, please call 1-800-253-2764 in
North America.
KEEP THIS NUMBER FOR FUTURE REFERENCE.
A Bionaire ® consumer service representative will help determine
which is the best procedure for your Air Exchange System to be
repaired.
If you have questions or comments, feel free to write us at:
Consumer Service Department
13120 Jurupa Avenue
Fontana, CA 92337
1-Tab
2-Tab
Bionaire ® , the Bionaire logo ® and EverFresh TM are trademarks of
JCS/THG, LLC.
Bionaire ®
Instruction Leaflet
JCS/THG, LLC
Consumer Service Department
13120 Jurupa Avenue
Fontana, CA 92337
If after having read this leaflet, you have any
call 1-800-253-2764 in North America.
BAP33605EM2/9100040002234 Printed In China
EverFresh TM
Air Exchange
System
BAP336
MODEL
Read instructions before operating.
Retain for future reference.
INFO-LINE
questions or comments on air cleaner,
