5.2 ENGINE AND CONTROLS

A Honda engine is used with this unit. Always
®
read the engine Operator's Manual supplied with
the seed tender for the detailed engine operating
procedures.
1. Engine Key Switch
Turn the key switch to the START position to
start the engine. When the engine starts, then
release the key and allow it to return to the ON
position.
2. Starting Rope
This retracting rope and T-bar is an optional
method used to start the engine. Grasp the
T‑barfirmlyandpulltheropesharplytostart
the engine. The key on master control must be
ON for the engine to start.
3. Fuel Shut-Off Valve
Each engine is equipped with a valve between
the fuel tank and the carburetor. Slide the fuel
valve toward the engine to turn ON and away
for OFF. Turn the fuel OFF when not in use or
before transporting.
4. Choke Lever
The choke lever controls the fuel/air mixture to
the engine. Close the choke when starting if the
engine is cold. Open the choke as the engine
warms. Always open the choke fully during
operation.
22
5. Throttle Lever
This lever controls the engine RPM. Move the
lever to increase or decrease the RPM. Always
run at maximum throttle when operating the
auger.
6. Engine Circuit Protection
The circuit protector protects the battery
charging circuit. A short circuit, or a battery
connected with reverse polarity, will trip the
circuit breaker. The green indicator inside the
circuit protector will pop out to show that the
circuit protector has switched off.
7. Battery (12 Volt)
A 12 Volt battery supplies the power to start
the gasoline engine. The battery must be
periodically recharged from an external source
to keep it fully charged.
