TI01009D/06/EN/19.15
71289171
The flowmeter with genuine two-wire technology for minimized total cost of
operation
Application
• Measuring principle operates independently of physical fluid
properties such as viscosity or density
• Highly accurate measurement of liquids and gases for a wide
range of standard applications
Device properties
• Compact dual-tube system
• Medium temperature up to +140 °C (+284 °F)
• Process pressure up to 100 bar (1 450 psi)
• Loop-powered technology
• Robust two-chamber housing
• Plant safety: worldwide approvals (SIL, Haz. area)
Products
Technical Information
Proline Promass E 200
Coriolis flowmeter
Solutions
Your benefits
• Cost-effective – multi-purpose device; an alternative to
conventional volumetric flowmeters
• Fewer process measuring points – multivariable
measurement (flow, density, temperature)
• Space‐saving installation – no in/outlet run needs
• Convenient device wiring – separate connection
compartment
• Safe operation – no need to open the device thanks to
display with touch control, background lighting
• Integrated verification – Heartbeat Technology™
Services

Advertisement

Table of Contents
loading

Related Manuals for Endress+Hauser Proline Promass E 200

Summary of Contents for Endress+Hauser Proline Promass E 200

  • Page 1 Products Solutions Services TI01009D/06/EN/19.15 71289171 Technical Information Proline Promass E 200 Coriolis flowmeter The flowmeter with genuine two-wire technology for minimized total cost of operation Application Your benefits • Measuring principle operates independently of physical fluid • Cost-effective – multi-purpose device; an alternative to...

  • Page 2: Table Of Contents

    Proline Promass E 200 Table of contents Document information ..... . . 4 Degree of protection ......

  • Page 3: Endress+Hauser

    Proline Promass E 200 Documentation ......67 Standard documentation ......67 Supplementary device-dependent documentation .

  • Page 4: Document Information

    Proline Promass E 200 Document information Symbols used Electrical symbols Symbol Meaning Symbol Meaning Direct current Alternating current Direct current and alternating current Ground connection A grounded terminal which, as far as the operator is concerned, is grounded via a grounding system.

  • Page 5: Function And System Design

    Proline Promass E 200 Function and system design Measuring principle The measuring principle is based on the controlled generation of Coriolis forces. These forces are always present in a system when both translational and rotational movements are superimposed. = 2 · ∆m (ν · ω) = Coriolis force ∆m = moving mass...

  • Page 6: Safety

    Proline Promass E 200 Transmitter Promass 200 Device versions and materials: • Compact, aluminum coated: Aluminum, AlSi10Mg, coated • Compact, hygienic, stainless: Hygienic version, for maximum corrosion resistance: stainless steel CF-3M (316L, 1.4404) Configuration: A0013471 • External operation via four-line, illuminated local display with touch control and guided menus ("Make-it-run"...

  • Page 7: Operable Flow Range

    To increase the accuracy of certain measured variables or to calculate the corrected volume flow for gases, the automation system can continuously write the operating pressure to the measuring device. Endress+Hauser recommends the use of a pressure measuring device for absolute pressure, e.g. Cerabar M or Cerabar S.

  • Page 8: Output

    Proline Promass E 200 Fieldbuses The measured values can be written from the automation system to the measuring via: • FOUNDATION Fieldbus • PROFIBUS PA Output Output signal Current output Current output 1 4-20 mA HART (passive) Current output 2...

  • Page 9: Signal On Alarm

    Proline Promass E 200 Switching delay Adjustable: 0 to 100 s Number of switching Unlimited cycles Assignable functions • Off • On • Diagnostic behavior • Limit value – Mass flow – Volume flow – Corrected volume flow – Density –...

  • Page 10: Load

    Proline Promass E 200 Switch output Failure mode Choose from: • Current status • Open • Closed FOUNDATION Fieldbus Status and alarm Diagnostics in accordance with FF-912 messages Error current FDE (Fault 0 mA Disconnection Electronic) PROFIBUS PA Status and alarm Diagnostics in accordance with PROFIBUS PA Profile 3.02...

  • Page 11: Ex Connection Data

    Proline Promass E 200 R [ ] U [V] A0013563 Operating range 1.1 For order code for "Output", option A "4-20 mA HART"/option B "4-20 mA HART, pulse/frequency/switch output" with Ex i and option C "4-20 mA HART + 4-20 mA analog"...
  • Page 12 Proline Promass E 200 Ex nA type of protection Order code for "Output" Output type Safety-related values Option A 4-20mA HART = DC 35 V = 250 V Option B 4-20mA HART = DC 35 V = 250 V Pulse/frequency/switch output...
  • Page 13 Proline Promass E 200 Intrinsically safe values Type of protection Ex ia Order code for "Output" Output type Intrinsically safe values Option A 4-20mA HART = DC 30 V = 300 mA = 1 W = 0 μH = 5 nF...
  • Page 14 Proline Promass E 200 Order code for "Output" Output type Intrinsically safe values Pulse/frequency/switch output = DC 35 V = n.a. = 1 W = 0 μH = 6 nF Option C 4-20mA HART = DC 30 V = n.a.

  • Page 15: Low Flow Cut Off

    Proline Promass E 200 Order code for "Output" Output type Intrinsically safe values Option E FOUNDATION Fieldbus STANDARD FISCO = 30 V = 17.5 V = 300 mA = 550 mA = 1.2 W = 5.5 W = 10 µH = 10 µH...
  • Page 16 Proline Promass E 200 Dynamic variables Read out the dynamic variables: HART command 3 The measured variables can be freely assigned to the dynamic variables. Measured variables for PV (primary dynamic variable) • Mass flow • Volume flow • Corrected volume flow •...
  • Page 17 Proline Promass E 200 Server VCRs Source VCRs Sink VCRs Subscriber VCRs Publisher VCRs Device Link Capabilities Slot time Min. delay between PDU Max. response delay Min. 5 Transducer Blocks Block Contents Output values Setup Transducer Block All parameters for standard commissioning.
  • Page 18 Proline Promass E 200 Block Contents Output values Heartbeat Results 2 Information about the results of the verification. No output values Transducer Block (TRDHBTR2) Heartbeat Results 3 Information about the results of the verification. No output values Transducer Block (TRDHBTR3) Heartbeat Results 4 Information about the results of the verification.
  • Page 19 Proline Promass E 200 Block Number Contents Process variables (Channel) blocks Multiple Digital This Block (standard functionality) receives Channel_DO (122) Output Block several discrete values and makes them • Value 1: Reset totalizer 1 (MDO) available for other blocks at the output.

  • Page 20: Power Supply

    Proline Promass E 200 Input values Analog output (from automation system to External pressure measuring device) Digital output 1 to 4 (fixed assignment) • Digital output 1: switch positive zero return on/off • Digital output 2: switch zero point adjustment on/off •...

  • Page 21: Pin Assignment, Device Plug

    Proline Promass E 200 Order code for "Output" Terminal numbers Output 1 Output 2 1 (+) 2 (-) 3 (+) 4 (-) Pulse/frequency/switch output 1) 2) Option E FOUNDATION Fieldbus (passive) Pulse/frequency/switch output 1) 3) Option G PROFIBUS PA (passive) Output 1 must always be used;...

  • Page 22: Power Consumption

    For device version with SD03 local display: The terminal voltage must be increased by DC 0.5 V if backlighting is used. For information about the load see →  10 Various power supply units can be ordered from Endress+Hauser: see "Accessories" section →  66 For information on the Ex connection values →  11...

  • Page 23: Electrical Connection

    Proline Promass E 200 Electrical connection Connecting the transmitter A0015510 Cable entry for output 1 Cable entry for output 2 Connection examples Current output 4-20 mA HART 4...20 mA A0015511  1 Connection example for 4-20 mA HART current output (passive) Automation system with current input (e.g.
  • Page 24 Proline Promass E 200 Switch output A0016802  3 Connection example for switch output (passive) Automation system with switch input (e.g. PLC) Power supply Transmitter: observe input values PROFIBUS-PA A0019004  4 Connection example for PROFIBUS-PA Control system (e.g. PLC)
  • Page 25 Proline Promass E 200 FOUNDATION Fieldbus A0019004  5 Connection example for FOUNDATION Fieldbus Control system (e.g. PLC) Power Conditioner (FOUNDATION Fieldbus) Cable shield T-box Measuring device Local grounding Bus terminator Potential matching line HART input 4...20 mA – –...

  • Page 26: Potential Equalization

    Proline Promass E 200 Potential equalization Requirements No special measures for potential equalization are required. For devices intended for use in hazardous locations, please observe the guidelines in the Ex documentation (XA). Terminals • For device version without integrated overvoltage protection: plug-in spring terminals for wire cross-sections 0.5 to 2.5 mm...

  • Page 27: Performance Characteristics

    Proline Promass E 200 Nominal discharge current 10 kA (8/20 μs) Temperature range –40 to +85 °C (–40 to +185 °F) The voltage is reduced by the amount of the internal resistance I ⋅ R Depending on the temperature class, restrictions apply to the ambient temperature for device...

  • Page 28: Repeatability

    Proline Promass E 200 SI units 1:10 1:20 1:50 1:100 1:500 [mm] [kg/h] [kg/h] [kg/h] [kg/h] [kg/h] [kg/h] 2 000 6 500 18 000 1 800 45 000 4 500 2 250 70 000 7 000 3 500 1 400...

  • Page 29: Influence Of Ambient Temperature

    Proline Promass E 200 Influence of ambient o.r. = of reading temperature Current output Additional error, in relation to the span of 16 mA: Temperature coefficient at 0.02 %/10 K zero point (4 mA) Temperature coefficient 0.05 %/10 K with span (20 mA)

  • Page 30: Installation

    Proline Promass E 200 BaseAccu = base accuracy in % o.r., BaseRepeat = base repeatability in % o.r. MeasValue = measured value; ZeroPoint = zero point stability Calculation of the maximum measured error as a function of the flow rate Flow rate Maximum measured error in % o.r.

  • Page 31: Orientation

    Proline Promass E 200 A0023344 Installation in down pipes However, the following installation suggestion allows for installation in an open vertical pipeline. Pipe restrictions or the use of an orifice with a smaller cross-section than the nominal diameter prevent the sensor running empty while measurement is in progress.

  • Page 32: Inlet And Outlet Runs

    Proline Promass E 200 Orientation Recommendation Vertical orientation A0015591 Horizontal orientation, transmitter head up Exception:→  10,  A0015589 Horizontal orientation, transmitter head down Exception: →  10,  32 A0015590 Horizontal orientation, transmitter head at side A0015592 Applications with low process temperatures may reduce the ambient temperature. To maintain the minimum ambient temperature for the transmitter, this orientation is recommended.

  • Page 33: Environment

    ‣ If operating outdoors: Avoid direct sunlight, particularly in warm climatic regions. Weather protection covers can be ordered from Endress+Hauser: see "Accessories" section →  64 Temperature tables In the following tables, the following interdependencies between the maximum medium...
  • Page 34 Proline Promass E 200 SI units Nominal diameter [mm] [°C] [85 °C] [100 °C] [135 °C] [200 °C] [300 °C] [450 °C] 1) 2) DN 08 to 50 3) 2) DN 08 to 50 – DN 08 to 50 –...
  • Page 35 Proline Promass E 200 SI units Nominal diameter [mm] [°C] [85 °C] [100 °C] [135 °C] [200 °C] [300 °C] [450 °C] DN 08 to 50 DN 08 to 50 – DN 08 to 50 – – The following applies for installations with overvoltage protection in conjunction with temperature class T5, T6: T - 2 °C...
  • Page 36 Proline Promass E 200 SI units Nominal diameter [mm] [°C] [85 °C] [100 °C] [135 °C] [200 °C] [300 °C] [450 °C] 1) 3) DN 08 to 50 2) 3) DN 08 to 50 – DN 08 to 50 –...

  • Page 37: Storage Temperature

    Proline Promass E 200 Explosion hazards arising from gas and dust Determining the temperature class and surface temperature with the temperature table • In the case of gas: Determine the temperature class as a function of the ambient temperature T and the medium temperature T •...

  • Page 38: Interior Cleaning

    Proline Promass E 200 Interior cleaning • Sterilization in place (SIP) • Cleaning in place (CIP) Electromagnetic As per IEC/EN 61326 and NAMUR Recommendation 21 (NE 21) compatibility (EMC) For details, refer to the Declaration of Conformity. Process Medium temperature range Sensor –40 to +140 °C (–40 to +284 °F)
  • Page 39 Proline Promass E 200 Flange according to ASME B16.5 [psi] [bar] 1400 Class 600 1200 1000 Class 300 Class 150 [°C] [°F] A0020973-EN  14 With flange material 1.4404 (F316/F316L) Flange JIS B2220 [psi] [bar] 1000 [°C] [°F] A0020974-EN  15 With flange material 1.4404 (F316/F316L)
  • Page 40 Proline Promass E 200 Thread DIN 11851 [psi] [bar] DN 8…40 DN 50 [°C] [°F] A0021007-EN  17 With connection material 1.4404 (316/316L) DIN 11851 allows for applications up to +140 °C (+284 °F) if suitable sealing materials are used.

  • Page 41: Secondary Containment Pressure Rating

    Proline Promass E 200 Thread SMS 1145 [psi] [bar] [°C] [°F] A0020986-EN  20 With connection material 1.4404 (316/316L) SMS 1145 allows for applications up to 6 bar (87 psi) if suitable sealing materials are used. Please take this into account when selecting seals and counterparts, as these components can limit the pressure and temperature range.

  • Page 42: Pressure Loss

    • Electrical heating, e.g. with electric band heaters • Via pipes carrying hot water or steam • Via heating jackets Heating jackets for the sensor can be ordered as accessories from Endress+Hauser →  64. NOTICE Danger of overheating when heating ‣...

  • Page 43: Mechanical Construction

    Proline Promass E 200 Mechanical construction Dimensions in SI units Compact version Order code for "Housing", options B "GT18 two-chamber, 316L", C "GT20 two-chamber aluminum coated" A0013552 Dimensions for version without overvoltage protection [mm] [mm] [mm] [mm] [mm] [mm] [mm]...
  • Page 44 Proline Promass E 200 Flange according to EN 1092-1 (DIN 2501 / DIN 2512N), PN 40 1.4404 (F316/F316L): order code for "Process connection", option D2S Flange with groove according to EN 1092-1 Form D (DIN 2512N), PN 40 1.4404 (F316/F316L): order code for "Process connection", option D6S...
  • Page 45 Proline Promass E 200 Flange according to ASME B16.5, Cl 150 1.4404 (F316/F316L): order code for "Process connection", option AAS [mm] [mm] [mm] [mm] [mm] [mm] [mm] 60.3 4 × Ø15.7 11.2 15.7 60.3 4 × Ø15.7 11.2 15.7 79.4 4 ×...
  • Page 46 Proline Promass E 200 Flange JIS B2220, 20K 1.4404 (F316/F316L): order code for "Process connection", option NES [mm] [mm] [mm] [mm] [mm] [mm] [mm] 4 × Ø15 4 × Ø15 4 × Ø19 4 × Ø19 8 × Ø19 Surface roughness (flange): Ra 3.2 to 6.3 µm...
  • Page 47 Proline Promass E 200 Fixed flange connections DIN 11864-2 +1,5 (+0.06) -2,0 (-0.08) A0015627  23 Detail X: Asymmetrical process connection; the part shown in gray is provided by the supplier. Engineering unit mm (in). Flange DIN11864-2 Form A , for pipe according to DIN11866 series A, flat flange 1.4404 (316/316L): order code for "Process connection", option KCS...
  • Page 48 Proline Promass E 200 Tri-Clamp ( ≥ 1") 1.4404 (316/316L): order code for "Process connection", option FTS Clamp [mm] [in] [mm] [mm] [mm] 50.4 22.1 50.4 22.1 50.4 22.1 1½ 50.4 34.8 63.9 47.5 Threaded connections DIN 11851, DIN11864-1, SMS 1145 +1,5 (+0.06)
  • Page 49 Proline Promass E 200 Thread SMS 1145 1.4404 (316/316L): order code for "Process connection", option FSW [mm] [in] [mm] [mm] Rd 40 × ¹⁄₆ 22.5 Rd 40 × ¹⁄₆ 22.5 Rd 40 × ¹⁄₆ 22.5 Rd 60 × ¹⁄₆ 35.5 Rd 70 ×...
  • Page 50 Proline Promass E 200 VCO connections +1,5 (+0.06) -2,0 (-0.08) A0015624  27 Engineering unit mm (in) 8-VCO-4 (½") 1.4404 (316/316L): order code for "Process connection", option CVS [mm] [in] [mm] [mm] SW 1 10.2 12-VCO-4 (¾") 1.4404 (316/316L): order code for "Process connection", option CWS...

  • Page 51: Dimensions In Us Units

    Proline Promass E 200 Dimensions in US units Compact version Order code for "Housing", options B "GT18 two-chamber, 316L", C "GT20 two-chamber aluminum coated" A0013552 [in] [in] [in] [in] [in] [in] [in] [in] [in] [in] [in] [in] ³⁄₈ 6.38 4.02 2.36...
  • Page 52 Proline Promass E 200 Flange according to ASME B16.5; Cl 150 1.4404 (F316/F316L): order code for "Process connection", option AAS [in] [in] [in] [in] [in] [in] [in] ³⁄₈ 3.54 2.37 4 × Ø0.62 0.44 0.62 9.13 ½ 3.54 2.37 4 × Ø0.62 0.44...
  • Page 53 Proline Promass E 200 Tri-Clamp connections +1,5 (+0.06) -2,0 (-0.08) A0015625  29 Engineering unit mm (in) Tri-Clamp (½") 1.4404 (316/316L): order code for "Process connection", option FUW Clamp [in] [in] [in] [in] [in] ³⁄₈ ½ 0.98 0.37 9.02 ½...

  • Page 54: Weight

    Proline Promass E 200 Thread SMS 1145: 1.4404 (316/316L): order code for "Process connection", option FSW [in] [in] [in] [in] ³⁄₈ Rd 40 × 1/6 0.89 9.02 ¹⁄₂ Rd 40 × 1/6 0.89 10.75 Rd 40 × 1/6 0.89 12.76 1½...

  • Page 55: Materials

    Proline Promass E 200 Weight [kg] [mm] Order code for "Housing", option C Order code for "Housing", option B Aluminum coated 1.4404 (316L) 15.5 24.5 Weight in US units All values (weight) refer to devices with EN/DIN PN 40 flanges. Weight information in [lbs].
  • Page 56 Proline Promass E 200 Order code for "Housing", option C "GT20 two-chamber, aluminum coated" Cable entry/cable gland Type of protection Material Cable gland M20 × 1.5 • Non-Ex Plastic • Ex ia • Ex ic Adapter for cable entry with Nickel-plated brass internal thread G ½"...

  • Page 57: Process Connections

    Proline Promass E 200 Process connections • Fixed flange connections: – EN 1092-1 (DIN 2501) flange – EN 1092-1 (DIN 2512N) flange – Namur lengths in accordance with NE 132 – ASME B16.5 flange – JIS B2220 flange – DIN 11864-2 Form A flange, DIN11866 line A, flange with notch •...

  • Page 58: Local Operation

    Proline Promass E 200 Local operation Via display module Order code for "Display; Operation", option C "SD02" Order code for "Display; Operation", option E "SD03" A0015546 A0015544 Operation with pushbuttons Operation with touch control Display elements • 4-line display • With order code for "Display; operation", option E: White background lighting;...
  • Page 59 Proline Promass E 200 A0013764  34 Options for remote operation via HART protocol Control system (e.g. PLC) Transmitter power supply unit, e.g. RN221N (with communication resistor) Connection for Commubox FXA195 and Field Communicator 475 Field Communicator 475 Computer with operating tool (e.g. FieldCare, AMS Device Manager, SIMATIC PDM)

  • Page 60: Service Interface

    Power supply FF-H1 network T-box Measuring device Service interface Via service interface (CDI) A0014019 Service interface (CDI = Endress+Hauser Common Data Interface) of the measuring device Commubox FXA291 Computer with "FieldCare" operating tool with COM DTM "CDI Communication FXA291" Endress+Hauser...

  • Page 61: Certificates And Approvals

    Directives. These are listed in the corresponding EC Declaration of Conformity along with the standards applied. Endress+Hauser confirms successful testing of the device by affixing to it the CE mark. C-Tick symbol The measuring system meets the EMC requirements of the "Australian Communications and Media Authority (ACMA)".

  • Page 62: Hygienic Compatibility

    Directive equal to DN 25 (1"), this is neither possible nor necessary. • With the PED/G1/x (x = category) marking on the sensor nameplate, Endress+Hauser confirms compliance with the "Essential Safety Requirements" specified in Annex I of the Pressure Equipment Directive 97/23/EC.

  • Page 63: Ordering Information

    The application packages can be ordered with the device or subsequently from Endress+Hauser. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.

  • Page 64: Accessories

    Accessories Various accessories, which can be ordered with the device or subsequently from Endress+Hauser, are available for the device. Detailed information on the order code in question is available from your local Endress+Hauser sales center or on the product page of the Endress+Hauser website: www.endress.com.

  • Page 65: Communication-Specific Accessories

    Is used to stabilize the temperature of the fluids in the sensor. Water, water vapor and other non-corrosive liquids are permitted for use as fluids. If using oil as a heating medium, please consult with Endress+Hauser. Heating jackets cannot be used with sensors fitted with a rupture disk.

  • Page 66: Service-Specific Accessories

    The application already contains the data of your Endress+Hauser device. Endress +Hauser also takes care of maintaining and updating the data records.

  • Page 67: Documentation

    • The W@M Device Viewer : Enter the serial number from the nameplate (www.endress.com/deviceviewer) • The Endress+Hauser Operations App: Enter the serial number from the nameplate or scan the 2-D matrix code (QR code) on the nameplate. Standard documentation...

  • Page 68: Registered Trademarks

    Registration-pending trademark of the Fieldbus Foundation, Austin, Texas, USA TRI-CLAMP ® Registered trademark of Ladish & Co., Inc., Kenosha, USA Applicator ® , FieldCare ® , Field Xpert , HistoROM ® , Heartbeat Technology Registered or registration-pending trademarks of the Endress+Hauser Group www.addresses.endress.com...
