Memory Map
5-5-2 Overview
Contents Memory
map
word
Alarm flags 00
Conversion data 01 to 16
High/low alarm 17 to 21
flags
Peak hold data 22 to 37
Input point active 38
flags
Function active 39 to 45
flags
Pointer word 46
Input point 47
enable bits
BCD/binary 48
select bits
Function enable 49 to 54
bits
High/low alarm 55 to 86
limits
Filter constants 87 to 102 R/W
Averaging 103 to
sample count
118
Scaling limits 119 to
150
EEPROM write 151
count
EEPROM error 152
flags
EEPROM 153
compare word
The following table outlines the contents of the memory map. Refer to the next
section for details.
Read/ Data Valid data
write format range
R Binary 0 or 1
R Binary –32768 to
BCD 32767
–7999 to 7999
R Binary 0 or 1
R Binary –32768 to
BCD 32767
–7999 to 7999
R Binary 0 or 1
R Binary 0 or 1
R/W BCD 00 to 153
R/W Binary 0 or 1
R/W Binary 0 or 1
R/W Binary 0 or 1
R/W Binary –32768 to
BCD 32767
–7999 to 7999
Binary 1 to 32767
BCD 1 to 7999
R/W Binary 1 to 32767
BCD 1 to 7999
R/W Binary –32768 to
BCD 32767
–7999 to 7999
R Binary 0000 to 9999
R Binary 0 or 1
W Binary 0000 to 9999
Factory Save/ Reset
default load on
EEPROM input
point
enable
0 No No
0 No Yes
0
0 No No
0 No Yes
0
All 1 No Yes
0 No No
0 No No
All 1 Yes No
All 1 Yes No
(BCD)
0 Yes No
— Yes No
—
100 Yes No
100 Yes No
— Yes No
—
0 Yes No
0 No No
0 No No
Section 5-5
Reset Conditions
on
function
enable
No Set by Unit.
Reset by
user using
I/O word n.
Yes Set by Unit.
No Set by Unit.
Yes Set by Unit.
No Set by Unit.
Yes Set by Unit.
No Set by
user.
No Set by
user.
No Set by
user.
No Set by
user.
No Set by
user.
No Set by
user.
No Set by
user.
No Set by
user.
No Set by Unit.
No Set by Unit.
No Set by
user.
