Functions and User Programs
Output
condition
25505 (>)
25505 (>)
06400
Program for Binary Data:
CMP(20)
Compares the content of
DM 0100 with 0FFF.
DM 0100
#0FFF
If the data is not greater
MOV(21)
than 0FFF, the data is
DM 0100
transferred to the Unit.
010
If the data is not
06400
convertible,
IR 06400 is turned
ON.
Section 7-3
125
