Summary of Contents for Acura Integra 1987

  • Page 2: Emergency Service

    Contents Features & Safety W h at you should know before driving your car. Starting & Driving W h at gas to use, how to change gears, etc. Maintenance The Required Maintenance Schedule and some items you can service. Emergency Service Changing a flat, jump starting, towing.
  • Page 3 During the first 200 miles (300 km), try to avoid severe braking. Brake misuse during this period will reduce future braking efficiency. Remember, your Acura Automobile dealer knows your car best, and should be consulted for service assistance and advice.

  • Page 4: Keys And Locks

    Keys and Locks Keys Your is supplied with master key that fits the ignition and all locks, and a basic key that fits the ignition and doors but not the hatch or glove box. The basic key is provided for times when you must leave the key with a parking attendant or repair person, but still want to...
  • Page 5 Keys and Locks (cont'd) Power Door Locks (5 Door Hatchback LS) All doors can be simultaneously locked and unlocked by ope­ rating master door lock switch. Hatch The hatch can be opened by pulling up the lever at the left side of the driver's seat.
  • Page 6 Seats Front Seat Adjust the seat position by pulling up on the adjustment lever under the front edge of the seat cushion, and sliding the seat to the desired position. Then release the lever and make sure the seat is locked in position by moving it slightly back and forth. The angle of the seat-back can be changed by pulling up on the lever at the outside edge of the seat and leaning forward or back.
  • Page 7 Seats (cont'd) Head Restraints The head restraints are designed to help reduce injuries due to whiplash. They are located at the top of each front seat-back and have four height positions. They can be adjusted by pulling up to the position you want. To lower them, slide the button next to the restraint's height bar, while pushing the restraint down.
  • Page 8 Luggage Cover If you need more luggage height with the seat back upright, fold the rear section of the cover forward, or pull the latches on both sides to the rear and lift the cover out. L U G G A G E C O V E R L A T C H * Make sure the seat-back latches engage securely when the seat-back is returned to its normal position.
  • Page 9 S eat Belts Your Acura automobile is provided with seat belts to minimize the chance of injury to yourself and your passengers in a sudden stop or accident. W e urge you and your passengers to use them. These belts are designed to be worn by adults and children over 140 cm (4 ft 7 in) tall.
  • Page 10 4. To release the seat belt, push the " P R E S S " button in the buckle; the belt should retract automatically when released. If the belt does not fully retract, pull it out and check for kinks or twists.
  • Page 11 Seat Belts (cont'd) Rear Center Seat Belt Adjust the center lap belt length to fit snugly but com fortably when buckled. A slack belt will greatly reduce the protection afforded to the wearer. Hold the tongue plate perpendicular to the belt as shown. * To shorten, pull the end of the belt away from the tongue plate.
  • Page 12 Follow all the in­ structions that come with the system. American Honda Motor Co., Inc. distributes through the Acura Automobile Division, both infant and child safety seats that meet the F M V S S and are designed to fit properly in your Acura car.
  • Page 13 Seat Belts (cont'd) Rear Center Seat Belt Adjust the center lap belt length to fit snugly but comfortably when buckled. A slack belt will greatly reduc,e the protection afforded to the wearer. Hold the tongue plate perpendicular to the belt as shown. * To shorten, pull the end of the belt away from the tongue plate.
  • Page 14 Follow all the in­ structions that come with the system. American Honda Motor Co., Inc. distributes through the Acura Automobile Division, both infant and child safety seats that meet the F M V S S and are designed to fit properly in your Acura car.
  • Page 15 When the child restraint system is not in use, remove it from the car or secure it with the seat belt to keep it from becoming a projectile in the event of an accident. NOTE: See your Acura dealer for installation of the child restraint system. Pregnant Women A pregnant woman should use one of the front seat lap/shoulder belts to help lessen the chance of injury and/or the amount of in­...
  • Page 16 Inspection All parts of the seat belts, including the belt fabric, should be regularly inspected for fraying, loosening, wear and other damage. Keep the belts in good condition at all times to reduce the chance of being injured in an accident, and to minimize any injuries that do occur.

  • Page 17: Instrument Panel

    Instrument Panel H E A D L I G H T M O T O R S W I T C H C R U IS E H E A T I N G / C O N T R O L C O O L IN G M A S T E R C O N T R O L...
  • Page 18 Gauges Speedometer The speed is indicated in miles per hour (outside scale) and kilo­ meters per hour (inside). Odometer The numbers on the odometer indicate miles. The odometer registers total distance traveled, and serves as your guide for determining when periodic maintenance is due. Federal law makes it illegal to alter the odometer of any motor vehicle with the intent to change the number of miles indicated.

  • Page 19: Warning And Indicator Lights

    (See page 61). Even if the oil level is correct, the engine should be checked by an Acura dealer before the car is driven again. CAUTION: Running the engine while the oil pressure warning light is on constantly may cause immediate and severe engine damage.
  • Page 20 If the light comes on while driving, avoid driving at high speed, and have the system checked by an Acura dealer as soon as possible. Headlight Motor Warning Light The headlight motor warning light will come on if either headlight...

  • Page 21: Tilt Steering

    Tilt Steering Tilt Steering The steering wheel position can be adjusted to suit driver pre- ference. 1. Pull the lever located under the dash, on the left side of the steering column, toward you, then push it all the way down and adjust the steering wheel to the desired position.
  • Page 22 Windshield W ip e rs /W a s h e r/D e fo g g e r Windshield Wipers Switch the wipers to I NT for intermittent operation; LO for low speed operation; and HI for high speed operation. In fog or very light rain, push the lever down to the M IST position for temporary high speed opera­...
  • Page 23 Windshield W ip e rs /W a s h e r/D e fo g g e r (cont'd) Rear Window Wiper/Washer Sw itch to " O N ” to activate the rear wiper. Sw itch to " [ £ ] " to activate the washer.
  • Page 24 Parking Brake and Mirrors Parking Brake To apply the parking brake, pull on the lever. To release it, pull slightly, push the button, and lower lever; when fully released, B R A K E warning light will go out. Rear View Mirrors Keep the inside and outside mirrors clean and adjusted for best visibility.
  • Page 25 Lights Turn Signals Push the turn signal lever down R I G H T to signal a left turn, and up for a T U R N right turn. The indicator and appropriate signal lights will blink. The lever will return auto­ matically to its original position when the steering wheel is re­...
  • Page 26 NOTE: • If the headlight motor switch is pushed in, the headlights will not retract when the light switch is turned off. • If the headlights neither rise nor retract they can be operated manually —see page 96. • If you're driving in w et snow or freezing rain, keep the headlights in the raised position by using the headlight motor switch;...
  • Page 27 Lights (cont'd) Headlight Motor Switch Push the headlight motor switch to raise and/or retract the head­ lights while they are off. The headlights should be raised in this manner whenever you intend to use them as a passing signal, or if there is a possibility of the headlight motors freezing.
  • Page 28 Interior Light The interior light has a three position switch. The light is off all the time in the O F F position. In the middle position, it goes on only when a door is opened. In the ON position, it is on all the time.
  • Page 29 Cruise Control (LS) Cruise Control The Cruise Control system allows you to set and automatically maintain any speed above 30 mph (45 km/h) without keeping your foot on the accelerator. As its name implies, it is meant for cruising on straight, uncongested highways or freeways. It is not recom­ mended to be used in traffic, on winding roads or in bad weather conditions where the driver should have total control.
  • Page 30 Change the Set Speed: a faster speed — For gradual acceleration with your foot off accelerator, push and hold the R E S U M E switch until you reach the desired speed; release the switch and the system's me­ mory will be re-programmed to the new speed.
  • Page 31 Hood To open, pull back on the handle 'W_ _ under the left side of the dash. The hood latch is spring-loaded, so the hood will pop up slightly. Release the safety catch under the front center of the hood by pushing the rubber-tipped handle to your left.
  • Page 32 Power W indows (5 Door Hatchback LS) Power Windows M AIN SW ITCH DRIVER'S p o w e r w i n d o w s c a n s w i t c h o p e r a t e d o n l y w h e n t h e i g n i t i o n switch is in the "...
  • Page 33 Glove Box and Clock Glove Box Open by pushing the knob. Close with a firm push. The glove box can be locked by using the master key. The glove box light will go on when the glove box is opened and the light switch is on.
  • Page 34 C ig a re tte L ig h te r and A s h tra y s Cigarette Lighter Push in to heat up. It will auto­ matically release when the ele­ ment is hot. DO NOT hold it in while it is heating up.
  • Page 35 H ea tin g and C ooling The vents, heater and optional air conditioner are combined in one system; adjusting four basic controls to different settings can pro­ vide a full range of interior temperatures for safe and comfortable driving. Ventilation The flow-through ventilation system can provide fresh air to the interior when the car is moving or stopped, even with the win­...
  • Page 36 What the Controls Do: FUNCTION BUTTONS RECIRCULATION FRESH AIR BUTTON LEVER BUTTON Fan Switch Push the lever to the right for low (LO), medium (•), medium high (•) or high (HI) speed, and the fan will circulate warm, cool, or out­ side air, depending on where the temperature lever and function buttons are set.
  • Page 37 Heating and Cooling (cont'd) How to Use the Controls To Ventilate Move the temperature lever to the left, push the FRESH and VENT buttons. Turn the fan switch on and outside air will flow through the side and center vents. To change air distribution, select the HI-LO position and outside air will also flow from the heater ducts at the floor level.
  • Page 38 To Heat Turn the fan switch on, slide the temperature lever to the right, select the HEAT position and warmed air will begin flowing from the floor outlet. To warm up the interior quickly, push in the REC button so inside air will recirculate to the heater.
  • Page 39 Heating and Cooling (cont'd) To Defrost To defrost or defog the windshield and door windows, slide the temperature lever to the right, select the (defrost) function, and switch the fan on. Warmed (outside) air will then flow from the windshield and side defroster vents. To Turn Everything OFF Slide the temperature lever to the left, turn the fan switch off and push the recirculation button on.
  • Page 40 Sunroof (3 Door Hatchback LS) To open the sunroof, first pull down on the lock lever, then push it up until it locks in the open position. To close, pull the handle for­ ward to let the back of the sunroof drop into position then push the handle backward to lock it.
  • Page 41 Sunroof (cont'd) Sunroof Removal/lnstallation ^ W A R N IN G • Do not attempt to remove or install the sunroof unless the car is parked safely and well out of the flow of traffic. • Do not allow any part of your body to extend through the sunroof while the car is in motion.
  • Page 42 Sunroof/Sunshade Storage Use the bag provided in your car when storing the sunroof, sun­ shade and deflector. To prevent damage, store them in the lug­ gage area as shown. Use the belt to secure the bag. CAUTION: Do not place any luggage on the Sunroof/Sunshade bag.
  • Page 43 Stereo Sound System (LS) Memory Button ® ON/OFF Switch and Volume Control Turn clockwise to switch radio/tape player on, and to increase volume. Turn counterclockwise to lower volume and to switch radio/tape player off. (2) AM/FM Band Selector Push to select AM or FM band. The corresponding band indicator will light.
  • Page 44 ;6) Balance Control Balances sound between left and right speakers. (7) Fader Control Balances sound between front and rear speakers. (D Program Selector Push to change the direction of tape play. The left indicator ( -4 will light when the bottom side of the cassette is being played. The right indicator ( ►...
  • Page 45 Stereo Sound System (cont'd) Memory Button Eject Push this button firmly to stop and eject the tape. The cassette being played will be automati­ Ignition Key-OFF Eject: cally ejected when the ignition or the unit is turned off. Stereo Indicator This lights up when an FM broadcast in stereo is being received.
  • Page 46 Graphic Equalizer BAND CONTROL LEVERS DEFEAT BUTTON The equalizer divides the stereo system's sound into seven frequency bands, from lowest bass (far left control lever) to highest treble (far right control lever). Set the levers to boost (above middle position) or reduce (below middle) in each band, according to your preference.
  • Page 47 C A U TIO N : If you notice steady spark knock while holding a steady speed on a level road, try changing brands of gasoline. If the spark knock persists, consult your Acura dealer. Failure to do so is considered misuse, and misuse is not covered under the New Car Warranty.
  • Page 48 These fuels may not be available in other countries. If you intend taking your car outside the U.S. or Canada, write to the Acura Automobile Division (stating the year and model of your car) at the address below for information regarding modifications you may need to have done.
  • Page 49 You can only get maximum fuel economy if your car is -in top running condition. Have all required maintenance done at the proper intervals. Check tire pressures and tire wear frequently. If tire wear is uneven, have the alignment checked by your Acura dealer. Proper alignment saves gasoline and prolongs tire life.
  • Page 50 Ignition S w itch The combined ignition switch/anti-theft lock is located on the right side of the steering column and has four positions: The key can be removed or inserted in this • O-LOCK position: position. To remove the key, push it in at position I, then turn it to 0 and pull it out.

  • Page 51: Starting The Engine

    Starting the Engine Before Starting Manual Transmission: 1. Apply the parking brake. 2. Push the clutch pedal all the way in and hold it. 3. Shift the transmission to neutral. Automatic Transmission: 1. Apply the parking brake and the foot brake. 2.
  • Page 52 S afe ty Item s Before driving away, check that: • The doors are closed properly. • The mirrors are properly adjusted, and the windows clean. • The driver and passengers are wearing properly adjusted seat belts. • The front seat head restraints are properly adjusted. •...
  • Page 53 Engine Exhaust Gas Warning A properly maintained car is your best protection against exhaust gas entering the passenger compartment. The exhaust system should be thoroughly inspected by a com­ petent mechanic whenever: • The car is raised for oil change. •...
  • Page 54 Clutch pedal free travel must be adjusted periodically to compen­ sate for lining wear. If the clutch seems to slip or you have dif­ ficulty shifting, have an Acura dealer check its adjustment. CAU TIO N : • Do not drive with your foot on the clutch pedal as this will cause premature wear of clutch components.
  • Page 55 Shifting the 5 Speed (cont'd) Recommended Shift Speeds For best fuel economy, and effective emission control, shift at the speeds shown: Shift up Normal Acceleration 1st to 2nd 14 mph (23 km/h) 2nd to 3rd 25 mph (40 km/h) 3rd to 4th 40 mph (64 km/h) 4th to 5th 49 mph (79 km/h)
  • Page 56 Shifting the Autom atic The automatic transmission shift lever has a locking mechanism to prevent accidental shifting into Reverse (R), Park (P) or 2nd (2). Push in the button on the left side of the shift handle to unlock the mechanism before shifting into 2nd, Reverse or Park, or out of Park.
  • Page 57 Shifting the Automatic (cont'd) Driving Technique D4-4th Use the D range for normal in-town and highway driving. The car will start off in 1st and shift automatically to 2nd, 3rd, and 4th. The further down you push the accelerator, the later the transmis­ sion will shift and the faster the car will accelerate.
  • Page 58 The Required Maintenance Schedule* specifies all maintenance required to keep your car in peak operating condition. Work should be done by an Acura dealer but may be done by any qualified service facility that regularly does this type of work.
  • Page 59 Maintenance Schedule (cont'd) Check the following items periodically: 1. Engine oil level. 2. Radiator coolant level. 3. Brakes: for braking efficiency, brake pedal travel and hydraulic fluid level. 4. Lights: for operation of headlights, taillights, side marker lights, stoplights, turn signals and back-up lights. 5.
  • Page 60 T e n s io n a d ju s tm e n t o n ly R - R e p la c e T h e re a fte r, re p la ce e v e ry C —...
  • Page 61 Maintenance Schedule (cont'd) C A U TIO N : The following items must be serviced more frequently on cars normally used under severe driving conditions. Refer to the chart below for the appropriate maintenance intervals. Severe driving conditions include: A : Repeated short distance driving B: Driving in dusty conditions C: Driving in severe cold weather D: Driving in areas using road salt or other corrosive materials...
  • Page 62 M aintenance Record REMEMBER • Keep all receipts for any work done on your car. • Have maintenance on previous pages done and record it here. Ml. (KM) D A T E or Months Serviced by: 15,000 miles (24,000 km) or 12 months Serviced by: Serviced by: 30,000 miles (48,000 km) or 24 months...

  • Page 63: Fluid Locations

    Fluid Locations AUTOMATIC TRANSMISSION FLUID DIPSTICK...

  • Page 64: Engine Oil And Filter

    Engine Oil and Filter Checking Check the engine oil a couple of minutes after shutting the engine off, with the car parked on level ground. Remove the dipstick and wipe it clean. Re-insert it all the way down, then pull it out and read the level.
  • Page 65 Engine Oil and Filter (cont'd) Fuel Efficient Oil For the best fuel economy from your car, it is recommended that you use a fuel efficient SF oil. These oils are usually identified by words such as: "Gas Saving," "Energy Conserving" "Fuel Sav­ ing"...
  • Page 66 NOTE: Please dispose of used motor oil in a manner that is com­ patible with the environment. We suggest you take it in a sealed container to your local service station for reclamation. Do not throw it in the trash or pour it on the ground. C A U TIO N : Used motor oil may cause skin cancer if repeatedly left in contact with the skin for prolonged periods.
  • Page 67 Transm ission Oil/Fluid Check Transmission oil/fluid must be checked with the engine off and the car on level ground. WARNING • When checking the transmission oil/fluid level, remember that if the engine has been running, the transmission, engine, radiator, hoses and dipstick are hot. •...
  • Page 68 Use the proper viscosity oil for climate which you drive: - 20 100°F - 3 0 - 2 0 - 1 0 40°C Ambient Temperature Automatic The automatic transmission fluid level is checked (with the engine off and the car on level ground) using the dipstick in the right end of the transmission housing.

  • Page 69: Cooling System

    Cooling System The engine in your Acura contains a number of aluminum parts. Therefore, it requires an anti-freeze/coolant specifically for­ mulated to protect the aluminum parts from corrosion. Failure to use a suitable anti-freeze/coolant may seriously shorten the life of the engine as the result of rapid corrosion damage.
  • Page 70 Thermostat The thermostat in the cooling system does not need to be changed for summer or winter operation. However, for extremely cold climates, an optional thermostat is available from your Acura dealer. Replacing Coolant Replace coolant at 36 months or 45,000 miles (72,000 km), whichever comes first.
  • Page 71 Cooling System (cont'd) 1. Set the heater temperature lever to maximum heat. 2. Remove the radiator cap and loosen the drain plug when the radiator is cool, and drain the radiator. 3. Remove the drain bolt from the front side of the cylinder block, and drain the engine and heater.
  • Page 72 Brakes Brake System Design diagonally-separated dual service brake system is designed so half the system will still provide braking action if the other half fails. Stopping the car after losing the brake fluid from half the system will require more pedal pressure and pedal travel than normal. Also, the distance required to stop will be longer using only half the brake system.
  • Page 73 Brakes (cont'd) Brake Wear Indicators Your car is equipped with audible brake wear indicators. When the brake pads wear to the point that they should be replaced, they will make a "screeching" sound while the brakes are applied. NOTE: Due to some driving habits or climates, brakes may "squeal"...
  • Page 74 P o w e r Ste e rin g The power steering on your INTEGRA provides easy handling while parking and maneuvering in traffic, without loss of road "feel” at highway speeds. An engine-driven hydraulic pump pro­ vides full power assist at low speeds and decreasing assist as the car goes faster.
  • Page 75 It should be replaced at 60,000 miles (96,000 km) or 48 months whichever comes first, or any time you suspect contaminated gas may have clogged it. CAUTION: Because the fuel system is under pressure, the filter should be replaced only by a qualified Acura technician.

  • Page 76: Spark Plugs

    Spark Plugs Spark plugs should be replaced every 24 months or 30,000 miles (48,000 km), whichever comes first. Recommended spark plugs: BCPR6EY-11 (NGK), BCPR6EY-N11 (NGK), Q20PR-U11 (ND) (for all normal driving) BCPR7EY-11 (NGK), BCPR7EY-N11 (NGK), Q22PR-U11 (ND) (for hot climates or continuous high speed driving) BCPR5EY-11 (NGK), BCPR5EY-N11 (NGK), Q16PR-U11 (ND) (for cold climates) CAUTION: Never use spark plugs with an improper heat range;...

  • Page 77: Wiper Blades

    Wiper Blades For maximum visibility, replace worn or cracked wiper blades when you notice they do not wipe the windshield cleanly or smoothly. To Replace Worn-out Blades: 1. Detach the blade assembly from the arm by pressing the lock tab in, then pushing the blade toward the base of the arm.
  • Page 78 B a ttery Your car is equipped with a maintenance-free battery. You never have to add water. The condition of the battery can be determined by checking the test indicator. Service as required according to the label on the battery. Any corrosion around the positive and negative terminals should be washed off with a solution of baking soda and warm water.

  • Page 79: Fuse Replacement

    Fuse Replacement The fuse box is located under the dashboard on the driver's side. The circuits protected by each fuse are listed inside the fuse box cover. NOTE: The fuse for the Hazard Warning System is located at the battery positive terminal. If any of your car's lights, accessories, or controls don't work, check their fuses.
  • Page 80 CAU TIO N: A blown fuse may be just a symptom of some other problem. If a new fuse blows right away, the cause should be diagnosed and corrected by a qualified Acura technician. Never replace a fuse with anything but another fuse of the same or lower rating.

  • Page 81: Bulb Replacement

    Bulb Replacement See page 99 for bulb specifications. Front turn signal lights Front side marker/turn signal lights...
  • Page 83 Tires The factory-installed tires on your car were selected to provide the best performance fo r normal driving. Inflation Pressures The tire label on the left side of the instrument panel shows re­ commended tire pressures for carrying loads up to the limit shown.
  • Page 84 Tire Chains When required, tire chains should be installed on the front wheels. Be sure to install chains designated SAE Class " S , " and follow the chain manufacturer's directions for installation. CAUTION: When you have installed tire chains, drive at less than 19 mph (30 km/h) on roads covered with snow or ice.
  • Page 85 When replacing tires, use only the recommended tire size. Wheel rim widths and offsets must meet those recommended by the Acura Automobile Division. Contact the Acura Automobile Divi­ sion Customer Relations Office at the address shown on the War­ ranty Service page.
  • Page 86 A ir C o n d itio n e r C are Condenser and Radiator Check the engine radiator and the air conditioner condenser (in fro n t of the radiator) for accumulated dirt, insects or leaves. Carefully brush or hose them o ff to assure maximum cooling performance.
  • Page 87 Acura dealer. CAUTION: Prolonged use of an under-charged system may dam­ age the compressor. Lubrication During the off-season, run your air conditioner for at least 10 minutes once a week to lubricate the seals and the inside of the compressor.
  • Page 88 During wiping, inspect the surface for stone chips and scratches; paint them w ith touch-up paint so they w on't rust (touch-up paint is available through your Acura dealer). For further instructions on corrosion protection, refer to the Rust Prevention section on the next pages.
  • Page 89 CAUTIO N: • Wash the wheels after driving on snowy or icy roads where salt has been applied. • The aluminum alloy wheels on your Acura are treated with a protective finish. Wash them with a low-phosphate detergent and sponge. Do not use abrasive cleaners or stiff brushes.
  • Page 90 • Salt used for road de-icing will coat the bottom of the car and hasten rusting. • Localities with high humidity have greater potential for rust problems, especially where salt is also present on the road or in moist sea air. •...

  • Page 91: Spare Tire

    Spare Tire COM PACT spare tire Your car is supplied with a COM PACT spare tire and wheel for temporary use only in the event of a flat tire. Use the COMPACT spare only when you have to, and only to go as far as the next garage or dealer to have the regular tire repaired and reinstalled.
  • Page 92 • The CO M PACT spare tire has a much shorter tread life than regular tires. Replace the tire as soon as tread wear indica­ tors appear as solid bands across the tread. Replace with a tire of exactly the same size and construction.

  • Page 93: Changing A Flat Tire

    Changing a Flat Tire Do not attempt to change a tire unless the car is on warning firm, level ground and well out of the flow of traffic. Park the car on a firm, level surface, apply the parking brake, turn on the hazard warning switch and put the transmission in gear, (Park for automatic).
  • Page 94 Follow tire changing preparations and procedures carefully to reduce the possibility of injury. The jack is designed for changing tires only. STAND CLEAR, DO NOT get under the car and DO NOT run the engine when the car is supported only by the jack.
  • Page 95 Towing If possible, always tow the car with the front wheels off the ground. The tow truck driver should position wood spacer blocks between your car's frame and the chains and lift straps, to avoid damaging the bumper and the body. Do not use the bumpers to lift the car or to support the car's weight while towing.
  • Page 96 If Your Car Gets Stuck With Manual Transmission: If your car gets stuck in sand, mud, or snow, you may free it by alternating between reverse and second to rock the car back and forth. Do not spin the wheels; the tires will just dig deeper, making it more difficult to free the car.
  • Page 97 Headlight Motors Proceed as follows if either headlight motor fails to operate: 1. Remove the cover from the fuse box. Use the label on the fuse box cover to locate the fuse for the headlight motor that doesn't work and remove the fuse with the fuse remover located inside the fuse box cover.
  • Page 98 NOTE: If foreign matter is the cause of the motor malfunction, it can usually be dislodged by turning the knob in the direction op­ posite that indicated by the arrow. 4. Replace the cap properly. 5. Reinstall the fuse and fuse box cover and have the headlight motor inspected at the earliest opportunity.

  • Page 99: Identification Numbers

    Identification Numbers The Vehicle Identification Num­ is stamped on a plate ber (V.I.N.) attached to the top left side of the dashboard. It also appears on the Certifica­ tion plate attached to the door jamb, as well as under the hood on the body, directly behind the air cleaner.
  • Page 100 Stopping Distance These figures indicate braking performance that can be met or exceeded by the vehicles to which they apply, under different conditions of loading and with partial failures of the braking system. The information presented represents results obtainable by skilled drivers under controlled road and vehicle conditions; it may not be correct under other conditions.
  • Page 101 DOT Tire Quality Grades The tires on all Acura cars meet Federal Safety Requirements. All tires on the INTEGRA are also "graded" according to Department of Transportation (DOT) standards for tread wear, traction and temperature. Tread wear The tread wear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course.
  • Page 102 Temperature The temperature grades are A (the highest), B, and C representing the tire's resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel. Sustained high temperature can cause the material of the tire to degenerate and reduce tire life, and excessive temperature can lead to sudden tire failure.

  • Page 103: Emission Controls

    Maintenance instructions are included on pages 55 — 58;. the operation of each system is explained on the following. Replacement Parts The emission control systems on your new Acura were designed, built and certified to conform with the Federal regulations implementing the Clean Air Act. The Acura Automobile Division recommends only the use of new, genuine Honda parts or their equivalent.
  • Page 104 Engine Exhaust Controls The engine exhaust emission control systems are designed to control combustion during idle, acceleration, cruise, and decelera­ tion. These systems are entirely separate from the crankcase and evaporative emission control systems described previously. • PGM-FI System The PGM-FI system consists of three independent sub­ systems;...
  • Page 105 — Don't change the ignition timing, or remove any emission control parts. — Use only the spark plugs specified in this manual. — Don't keep driving your car if it isn't running properly, or if its CHARGE warning light comes on; have it checked by your Acura dealer.

  • Page 106: Warranty Service

    After following these steps, if you wish to have the matter review­ ed by the Acura Automobile Division you should contact: The Acura Automobile Division, Customer Relations Office, American Honda Motor Co., Inc., 100 W. Alondra Blvd., Gardena, CA., 90247-0805;...
  • Page 107 Electrical Troubleshooting Manual ACURA A n e le c tric a l tro u b les h o o tin g manual is available for your car. This m anual com plem ents the Service Manual by providing in- depth troubleshooting information for each electrical circuit in your car.
  • Page 108 Index Bulb R e p la ce m e n t ......A ir C o n d itio n e r S p e c ific a tio n ......Care ......... B uzzer ..See "B e e p e r S y s te m " O p e ra tio n .......
  • Page 109 Index (cont'd) Emission Controls..... 104 Engine Hatch ......Coolant ...... Hatch-open Indicator Light ..Coolant Temperature Hazard Warning System ..Gauge ....Headlights Identification Num ber..100 Flasher ....... Oil and Filter....Headlight Motor Switch ... 24 Oil Pressure Warning High Beam Indicator..
  • Page 110 Meters, Gauges .. See "G a u ge s" Mirrors Keys Rear View M irrors..Door L o c k s....Glove Box ....Hatch L o c k ....Ignition....... Numbers, Identification..100 Key Reminder Beeper..Keys ......Octane Rating, Gasoline .......
  • Page 111 Index (cont'd) Replacement Spark Plugs......Air F ilter......Specifications ....... Bulbs ........ Speedometer......Engine O il......Starting the Engine....Fuel F ilte r......Steering Fuses ........ Anti-theft Column Lock ..Oil Filter ......Power Steering ....Radiator C oolant....Tilt Steering...... Spark Plugs.......
  • Page 112 Tread W ear......1 °2 Trip M e te r......Turn Signals......Vehicle Identification Number Ventilation ......Warning L ig h ts...... J ® Warranty Service....1 ° ' Washer Rear Window W asher..Reservoir Capacity... Windshield W asher... Washing ........ ®®...

  • Page 113: Gas Station Information

    Gas Station Information Gasoline: UNLEADED only Antiknock index of 86 or higher: Cost of Living Council Formula Gas Tank-Capacity: 50 liters (13.2 gallons) Tire Pressure (measured cold): Front/Rear 3 Door Hatchback 180/180 kPa (26/26 psi) 5 Door Hatchback 195/180 kPa (28/26 psi) COMPACT spare tire, 415 kPa (60 psi).
