Mounting and connection

4.3 Installing the docking station

Procedure- with a metallic installation location
Proceed as follows:
1. Position the spacer on the installation location.
2. Mark the fastening holes with a marking-off tool.
3. Drill two through-holes or two threaded holes, M4.
4. Mount the spacer.
5. Bend the tabs on the fixing pocket to the rear at right angles.
6. Slide the RFID tag into the fixing pocket.
7. Slide the tabs of the fixing pocket into the spacer.
The tabs snap into place and are secured by studs.
Procedure – with a non-metallic installation location
Proceed as follows:
1. Position the fixing pocket on the installation location.
2. Mark the fastening holes with a marking-off tool.
3. Drill two through-holes or two threaded holes, M4.
4. Fasten the fixing pocket.
5. Slide the RFID tag into the fixing pocket.
4.3 Installing the docking station
Requirement
● 2 M5 cylinder head screws with nuts, if required
Read the section "Planning the installation location and clearance of the docking station
(Page 56)".
Procedure
Proceed as follows:
1. Place the docking station on the mounting surface.
2. Mark the fastening holes with a marking-off tool.
3. Drill two through holes or two threaded holes M5.
4. Mount the docking station.
