Call channel programming
■
Call channel is used to access the Call Channel 9 (default),
however, you can program the call channel with your most
often-used channels in each channel group for quick recall.
Select the desired channel group (U.S.A, International or
q
Canada) to be programmed. (p. )
[16/C] for 1 second to select the call channel of
Hold down
w
the selected channel group.
• "CALLING" and call channel number appear.
Hold down [16/C] again until long beep stops with two
e
short beeps. The channel programming mode screen is
displayed.
r Push [Y]/[Z] to select the desired channel.
t Push [ENTER] to program the selected channel as the call
channel.
• The display automatically returns to the main menu screen.
Adjusting the volume level
■
The volume level can be adjusted with [VOL/SQL] and [Y]/
[Z] keys.
[VOL/SQL] once to enter the volume adjustment
Push
q
mode, then adjust the volume level with [Y]/[Z].
• The transceiver has 20 volume levels and OFF.
• With no key operation is performed for 5 seconds, it returns to
the main menu.
Push [VOL/SQL] twice to exit the volume adjustment
w
mode.
Adjusting the squelch level
■
The squelch level can be adjusted with [VOL/SQL] and [Y]/
[Z] keys.
In order to receive signals properly, as well as for the scan
to function effectively, the squelch must be adjusted to its
proper level.
[VOL/SQL] twice to enter the squelch adjustment
Push
q
mode, then adjust the squelch level with [Y]/[Z].
• The transceiver has 11 squelch levels: OP is completely open;
10 is tight squelch; 1 is loose squelch.
• With no key operation is performed for 5 seconds, the trans-
ceiver returns to the main screen.
[VOL/SQL] again to exit the adjustment mode and
Push
w
return to the main menu screen.
