USER'S
MANUAL
PA-8225
PA-8225
10.4" POS Terminal
Powered by Intel ® Celeron®
J1900 Quad-Core
M1

Advertisement

Table of Contents
loading

Related Manuals for Protech Systems PA-8225

Summary of Contents for Protech Systems PA-8225

  • Page 1 USER’S MANUAL PA-8225 10.4” POS Terminal Powered by Intel ® Celeron® J1900 Quad-Core PA-8225...
  • Page 2 Contents PA-8225 POS System With SATA/3COM/4USB COPYRIGHT NOTICE & TRADEMARK All trademarks and registered trademarks mentioned herein are the property of their respective owners. This manual is copyrighted in July 2016. You may not reproduce or transmit in any form or by any means, electronic, or mechanical, including photocopying and recording.
  • Page 3 Contents FCC NOTICE This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment.
  • Page 4 CHAPTER INTRODUCTION This chapter gives you the information for the PA-8225. It also outlines the system specifications. Sections included:  About This Manual  POS System Illustration  System Specifications  Safety precautions Experienced users can jump to chapter 2 on page 2-1 for a quick start.

  • Page 5: About This Manual

    Chapter 1 Introduction 1-1. ABOUT THIS MANUAL Thank you for purchasing our PA-8225 Series System. The PA-8225 is an updated system designed to be comparable with the highest performance of IBM AT personal computers. The PA-8225 provides faster processing speed, greater expandability and can handle more tasks than before.
  • Page 6 Chapter 1 Introduction 1-2. POS SYSTEM ILLUSTRATION PA-8225 in normal position Top View Bottom View 295.81 Front View Rear View Quarter View Side View 22.2 12.1 Unit: mm  Page: 1-3 PA-8225 SERIES USER S MANUAL...
  • Page 7 Chapter 1 Introduction PA-8225 in flat position Top View Bottom View Front View Rear View 295.81 Quarter View Side View Unit: mm  Page: 1-4 PA-8225 SERIES USER S MANUAL...
  • Page 8 Chapter 1 Introduction PA-8225 in upright position Top View Rear View Front View Quarter View 286.42 Side View 305.46 50.5 Unit: mm  Page: 1-5 PA-8225 SERIES USER S MANUAL...

  • Page 9: System Specifications

    10.4” TFT XGA LCD Interface Max. Resolution 1024 x 768, 800 x 600 Brightness 400cd/m Viewing Angel 22~48 degrees Touch Panel 10.4” 5-wire analog resistive Environment  Operating: 0~35°C (32 ~ 95°F) Temperature  Page: 1-6 PA-8225 SERIES USER S MANUAL...
  • Page 10 107.2 18.2 3.75 0.55 0.75 6.75  Standard Code CP-437, CP-850, CP-857, CP-865, Katakana  International Characters USA, FRANCE, GERMANY, UK, DENMARK I, SWDEN, ITALY, SPAIN, JAPAN, NORWAY, DENMARK II, RUSSIA, SLAVONIC  Page: 1-7 PA-8225 SERIES USER S MANUAL...
  • Page 11 Paper width 2inch 58 +0/-1 mm; 3inch 80 +0/-1 mm -1 mm (Paper Width) D mm D mm A mm (Printing Width) 2 inch (A:54, C:58, D:2) 3 inch (A:72, C:80, D:4)  Page: 1-8 PA-8225 SERIES USER S MANUAL...
  • Page 12  KANJI JAPANESE (SHIFT-JIS) Code, TRADITIONAL CHINESE Code  International Characters USA, FRANCE, GERMANY, UK, DENMARK I, SWDEN, ITALY, SPAIN I, JAPAN, NORWAY, DENMARK II, SPAIN II, LATIN AMERICA, KOREA, RUSSIA, SLAVONIC  Page: 1-9 PA-8225 SERIES USER S MANUAL...

  • Page 13: Safety Precautions

    Avoid exposure to sunlight for a long period of time (for example, in a closed car in summer time. Also avoid the system from any heating device.). Or do not use the PA-8225 when it has been left outdoors in a cold winter day.
  • Page 14 HDD or Memory or other parts. Step 1: Take screw off Open the front panel Step2 & 3: CAUTION: Take front metal off During Maintenance, Do not place the machine in an upside down position.  Page: 1-11 PA-8225 SERIES USER S MANUAL...
  • Page 15 CHAPTER SYSTEM CONFIGURATION Helpful information that describes the jumper and connector settings, component locations, and pin assignment. Sections included:  System External I/O Port Pin Assignment  How to Set Jumpers  Component Locations & Jumper Settings - Mainboard - Printer Board (peripheral device) - VFD Board (peripheral device) - MSR Board (peripheral device) Page 2-1...
  • Page 16 Chapter 2 System Configuration 2-1. SYSTEM EXTERNAL I/O PORT & PIN ASSIGNMENT Rear I/O Side I/O Power USB4 button ’ Page: 2-2 PA-8225 SERIES USER S MANUAL...
  • Page 17 DC IN: DC Power-In Port (rear IO) ASSIGNMENT ASSIGNMENT +24V +24V DC IN 2-1-3. VGA Port VGA: VGA Port, D-Sub 15-pin (rear IO) ASSIGNMENT ASSIGNMENT GREEN BLUE DDCA DATA HSYNC VSYNC DDCA CLK ’ Page: 2-3 PA-8225 SERIES USER S MANUAL...
  • Page 18 Yellow Color Blinking LAN Message Active No LAN Message Active Left Side LED Green Color On 10/100Mbps LAN Speed Indicator Orange Color on Giga LAN Speed Indicator No LAN switch/ hub connected. ’ Page: 2-4 PA-8225 SERIES USER S MANUAL...
  • Page 19 DRW1 Signal from M/B GPIO (rear I/O). ASSIGNMENT ASSIGNMENT +12V/+24V (Max. current: Drawer Open Drawer Sense DRW1/ DRW2 SIO Address Cash drawer 1 LDN 06, 0x91 bit 1 Cash drawer 2 LDN 06, 0x91 bit 3 ’ Page: 2-5 PA-8225 SERIES USER S MANUAL...
  • Page 20 Chapter 2 System Configuration 2-1-7. USB Ports USB1, USB2, USB3, USB4: USB Type A Ports  USB1~3: Rear I/O  USB4: Side IO USB1/ USB2/ ASSIGNMENT ASSIGNMENT +5V (Max. USB4/ current: 0.5A) USB3 ’ Page: 2-6 PA-8225 SERIES USER S MANUAL...
  • Page 21 Celeron ® J1900 SATA1 JPWR_4P1 Quad-Core DIMM1 SATA2 JPWR_4P2 TOUCH3 USB6 JI_BUTTON1 Battery JP19 JP_VDD1 SPK1 JP32 SLOT1 JP15 SW1_3 JP14 JINV4 USB1 USB7 LED1_3 JINVDRV1 LVDS1 COM4_2 LED1_1 PB-6822 Mainboard Component Locations ’ Page: 2-7 PA-8225 SERIES USER S MANUAL...
  • Page 22 Chapter 2 System Configuration SLOT2 PB-6822 Mainboard Component Locations - Rear ’ Page: 2-8 PA-8225 SERIES USER S MANUAL...
  • Page 23 PIN1 & PIN2 to create one setting and shorting. You can either connect PIN2 & PIN3 to create another setting. The same jumper diagrams are applied all through this manual. The figure below shows what the manual diagrams look and what they represent. ’ Page: 2-9 PA-8225 SERIES USER S MANUAL...
  • Page 24 Chapter 2 System Configuration Jumper diagrams Jumper settings ’ Page: 2-10 PA-8225 SERIES USER S MANUAL...
  • Page 25 2. There is no pin connection for JP_COM2 or JP_COM3 by default. Refer to Voltage Adjust Configuration in chapter 3 for detailed BIOS setting (BIOS default at Disabled). 3. Voltage of COM1 or COM4 is not adjustable on BIOS. ’ Page: 2-11 PA-8225 SERIES USER S MANUAL...
  • Page 26 JP20, JP21, JP22: COM3 / i-Button Function Connectors SELECTION JUMPER SETTING JUMPER ILLUSTRATION COM 3 JP20/JP21/JP22/ i-Button* JP20/JP21/JP22/ Note: Manufacturing Default is COM3. *COM3 & COM3-1 will not function when jumpers JP20, JP21 & JP22 are set as “i-Button.” ’ Page: 2-12 PA-8225 SERIES USER S MANUAL...
  • Page 27 JP37 (Default) Step 3. DRW1, DRW1-1, DRW1-2 shares the same power source. (Default: 12V). SIO Address Cash drawer 1 LDN 06, 0x91 bit 1 Cash drawer 2 LDN 06, 0x91 bit 3 ’ Page: 2-13 PA-8225 SERIES USER S MANUAL...
  • Page 28 To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. ’ Page: 2-14 PA-8225 SERIES USER S MANUAL...
  • Page 29 F7h al, 08h dx, al ;------ Close Cash drawer 2 -------------------------------------------- al, dx al, F7h dx, al ;------ Exit the extended function mode -------------------------------------------------------- mov al, 0aah dx, al ’ Page: 2-15 PA-8225 SERIES USER S MANUAL...
  • Page 30 DRW2 Port ASSIGNMENT ASSIGNMENT +24V Drawer Open Drawer Sense DRW2 Hexadecimal Control Codes Function Codes <DLE EOT> 10 04 Real-time status transmission <DLE DC4> 10 14 Real-time output of the specified pulse ’ Page: 2-16 PA-8225 SERIES USER S MANUAL...
  • Page 31 That is, JP29 will be enabled if DRW1 is disabled on BIOS. 2. There is no pin connection for JP29 by default. Refer to the Voltage Adjustment Configuration in chapter 3 for detailed BIOS setting (BIOS default at 12V). ’ Page: 2-17 PA-8225 SERIES USER S MANUAL...
  • Page 32 5V (Maximum current: 0.5A) USB1/ USB2/ USB7/ Note: USB1 would be used when jumpers JP14 & JP15 are set as 1-2 (short) connected. USB6 2-2-9. LED Connector LED1-1: Power indication LED connector ASSIGNMENT LED1-1 PWR_LED ’ Page: 2-18 PA-8225 SERIES USER S MANUAL...
  • Page 33 DC5V_PWR1: DC 5Voltage Provider Connector ASSIGNMENT DC5V_PWR1 2-2-11. Power for Thermal Printer Connector PRT_PWR1: Power for Thermal Printer Connector ASSIGNMENT VCC24SB PRT_PWR1 VCC24SB 2-2-12. External Speaker Connector SPK1: External speaker connector ASSIGNMENT SPK_GND SPK1 SPK_OUT ’ Page: 2-19 PA-8225 SERIES USER S MANUAL...
  • Page 34 2-2-14. LED Backlight Power Control Selection JP12: LED backlight power control connectors (for LED backlight panel without power driver built-in) SELECTION JUMPER SETTING JUMPER ILLUSTRATION JP12 JP12 Note: Manufacturing Default is LED. ’ Page: 2-20 PA-8225 SERIES USER S MANUAL...
  • Page 35 (24 bit) 10.4” JP8: 3-5, 2-4 1024 x 768 JP9:3-5, 4-6 (18 bit) 10.4” JP8: 3-5, 4-6 800 x 600 JP9: 3-5, 4-6 (18bit) Note: Manufacturing Default is 10.4”, 1024 x 768 (18bit). ’ Page: 2-21 PA-8225 SERIES USER S MANUAL...
  • Page 36 LVDS_A0_D- LVDS_B3_D- LVDS_A3_D+ LVDS_B0_D+ LVDS_A3_D- LVDS_B0_D- LVDS_VCC LVDS_VCC 2-2-18. Touch Panel Connector TOUCH3: Touch panel connectors ASSIGNMENT ASSIGNMENT LR (Low Right) UR (Up Right) LL (Low Left) UL (Up Left) Probe TOUCH3 ’ Page: 2-22 PA-8225 SERIES USER S MANUAL...
  • Page 37 Note: 1. Manufacturing Default is USB. 2. The COM2 & COM2-1 connector will not function when JP38 & JP39 are set as 1-2 connected. 3. USB1 connector when JP14 & JP15 are set as 1-2 connected. ’ Page: 2-23 PA-8225 SERIES USER S MANUAL...
  • Page 38 After five to six seconds, set the jumper back to “Normal” and power-on the computer. 2-2-21. MSR/Card Reader Connector PS/2_2: MSR/Card reader connectors ASSIGNMENT KB_CLK (Output) KB_CLK_C (Input) KB_DATA_C (Input) KB_DATA (Output) PS/2_2 ’ Page: 2-24 PA-8225 SERIES USER S MANUAL...
  • Page 39 SATA1/ SATA2/ Note: SATA1 only supports the optional RAID function on board. JPWR_4P1, JPWR_4P2: Serial ATA power connectors ASSIGNMENT JPWR_4P1/ JPWR_4P2/ VCC12 Note: JPWR_4P1 only supports the optional RAID function on board. ’ Page: 2-25 PA-8225 SERIES USER S MANUAL...
  • Page 40 Chapter 2 System Configuration 2-2-23. Printer Connector LPT1 LPT1: Printer connector ASSIGNMENT ASSIGNMENT STBJ ALFJ PDR0 ERRJ PDR1 PAR_INITJ PDR2 SLCTINJ PDR3 PDR4 PDR5 PDR6 PDR7 ACKJ BUSY SLCTJ ’ Page: 2-26 PA-8225 SERIES USER S MANUAL...
  • Page 41 +1.5V SLOT1 Reserved SMB_CLK Reserved PETn2 +1.5V SMB_DATA CLKREQ# PETp2 Reserved Reserved REFCLK1- Reserved REFCLK1+ +3.3V Reserved +3.3V Reserved Reserved Reserved Reserved Reserved Reserved Reserved PERST# +1.5V PERn2 +3.3SB PERp2 Reserved +3.3V ’ Page: 2-27 PA-8225 SERIES USER S MANUAL...
  • Page 42 SMB_CLK Reserved PETn0/SATA1_TX- +1.5V SMB_DATA CLKREQ# PETp0/SATA1_TX+ Reserved SLOT2 Reserved USB_D- REFCLK0- Reserved USB_D+ REFCLK0+ +3.3V Reserved +3.3V Reserved Reserved Reserved Reserved Reserved Reserved Reserved PERST# +1.5V PERn0/SATA1_RX+ +3.3SB PERp0/SATA1_RX- Reserved +3.3V ’ Page: 2-28 PA-8225 SERIES USER S MANUAL...
  • Page 43 Chapter 2 System Configuration 2-3. PRINTER BOARD COMPONENT LOCATIONS & PIN ASSIGNMENT 2-3-1. Printer Board: PDAC-3100 PDAC-3100 Printer Board Component Locations ’ Page: 2-29 PA-8225 SERIES USER S MANUAL...
  • Page 44 Chapter 2 System Configuration 2-3-1-1. Power Supply Connector CN1: Power supply wafer ASSIGNMENT +24V +24V 2-3-1-2. RS-232 Interface Connector CN7: RS-232 interface connector ASSIGNMENT ASSIGNMENT ’ Page: 2-30 PA-8225 SERIES USER S MANUAL...
  • Page 45 Auto-cutter motor drive signal 1B-1 Auto-cutter motor drive signal 1B-2 Auto-cutter motor drive signal 1A-1 Auto-cutter motor drive signal 1A-2 Auto-cutter motor drive signal 2-3-1-4. USB Connector CN8: USB Connector ASSIGNMENT ASSIGNMENT Vbus ’ Page: 2-31 PA-8225 SERIES USER S MANUAL...
  • Page 46 DST3 Head strobe signal 3.3V Logic Power Thermistor GND Thermistor GND Thermistor signal Unused DST2 Head strobe signal DST1 Head strobe signal Head GND Head GND Head GND Head GND Head GND ’ Page: 2-32 PA-8225 SERIES USER S MANUAL...
  • Page 47 GND of the platen position/ out-of-paper sensor Signal of the platen position sensor Unused Frame GND Frame GND Unused Motor drive signal Motor drive signal Motor drive signal Motor drive signal ’ Page: 2-33 PA-8225 SERIES USER S MANUAL...
  • Page 48 Reset signal Status signal Status signal Status signal Status signal Drawer sensor signal Drawer switch signal Drive terminal for the drawer (Vp side) GNDdu Drive terminal for the drawer (GND side) Unused ’ Page: 2-34 PA-8225 SERIES USER S MANUAL...
  • Page 49 Chapter 2 System Configuration 2-3-2. Printer Board: MB-1030 CUT_CN1 COM1 9 10 USB_CN1 24V_CN1 PRINT_CN1 MB-1030 RB, RC Printer Board Component Locations ’ Page: 2-35 PA-8225 SERIES USER S MANUAL...
  • Page 50 Chapter 2 System Configuration 2-3-2-1. Power Supply Connector 24V_CN1: Power Supply Wafer ASSIGNMENT +24V +24V 24V_CN1 2-3-2-2. RS-232 Interface Connector COM1: RS-232 Interface Connector ASSIGNMENT ASSIGNMENT DSR /CTS 9 10 COM1 DTR /RTS ’ Page: 2-36 PA-8225 SERIES USER S MANUAL...
  • Page 51 DST3 Head strobe signal 3.3V Logic Power Thermistor GND Thermistor GND Thermistor signal Unused DST2 Head strobe signal DST1 Head strobe signal Head GND Head GND Head GND Head GND Head GND ’ Page: 2-37 PA-8225 SERIES USER S MANUAL...
  • Page 52 GND of the platen position/ out-of-paper sensor Signal of the platen position sensor Unused Frame GND Frame GND Unused Motor drive signal Motor drive signal Motor drive signal Motor drive signal ’ Page: 2-38 PA-8225 SERIES USER S MANUAL...
  • Page 53 Autocutter motor drive signal 2-3-2-5. Paper-Near-END Sensor Connector CN2: Paper-near-end sensor connector ASSIGNMENT FUNCTION Power supply of the near end sensor Signal of the near end sensor GND of the near end sensor ’ Page: 2-39 PA-8225 SERIES USER S MANUAL...
  • Page 54 Reset signal Status signal Status signal Status signal Status signal Drawer sensor signal Drawer switch signal Drive terminal for the drawer (Vp side) GNDdu Drive terminal for the drawer (GND side) Unused ’ Page: 2-40 PA-8225 SERIES USER S MANUAL...
  • Page 55 Chapter 2 System Configuration 2-3-3. Printer Board: MB-1011 & MB-1013 MB-1011 & MB-1013 Printer Board Component Locations ’ Page: 2-41 PA-8225 SERIES USER S MANUAL...
  • Page 56 Chapter 2 System Configuration 2-3-3-1. Power Supply Connector CN1: Power supply wafer ASSIGNMENT +24V +24V 2-3-3-2. RS-232 Interface Connector CN7: RS-232 interface connector ASSIGNMENT ASSIGNMENT ’ Page: 2-42 PA-8225 SERIES USER S MANUAL...
  • Page 57 DST3 Head strobe signal 3.3V Logic Power Thermistor GND Thermistor GND Thermistor signal Unused DST2 Head strobe signal DST1 Head strobe signal Head GND Head GND Head GND Head GND Head GND ’ Page: 2-43 PA-8225 SERIES USER S MANUAL...
  • Page 58 GND of the platen position/ out-of-paper sensor Signal of the platen position sensor Unused Frame GND Frame GND Unused Motor drive signal Motor drive signal Motor drive signal Motor drive signal ’ Page: 2-44 PA-8225 SERIES USER S MANUAL...
  • Page 59 Autocutter motor drive signal 1B-1 Autocutter motor drive signal 1B-2 Autocutter motor drive signal 1A-1 Autocutter motor drive signal 1A-2 Autocutter motor drive signal 2-3-3-5. USB Interface Connector CN8: USB interface connector ASSIGNMENT Vbus ’ Page: 2-45 PA-8225 SERIES USER S MANUAL...
  • Page 60 Reset signal Status signal Status signal Status signal Status signal Drawer sensor signal Drawer switch signal Drive terminal for the drawer (Vp side) GNDdu Drive terminal for the drawer (GND side) Unused ’ Page: 2-46 PA-8225 SERIES USER S MANUAL...
  • Page 61 Chapter 2 System Configuration 2-4. VFD BOARD COMPONENT LOCATIONS & PIN ASSIGNMENT 2-4-1. VFD Board: MB-4103, LD720 JP12V MB-4103 & LD720 VFD Board Component Locations ’ Page: 2-47 PA-8225 SERIES USER S MANUAL...
  • Page 62 2-4-1-1. Power Switch Selection JP12V: Power Switch Selection SELECTION JUMPER SETTING JUMPER ILLUSTRATION JP12V JP12V Note: Manufacturing Default is ON. 2-4-1-2. RS-232 Serial Interface Connector CN1: RS-232 serial interface wafer ASSIGNMENT ASSIGNMENT +12V/+5V ’ Page: 2-48 PA-8225 SERIES USER S MANUAL...
  • Page 63 MB-3012 MSR Board Component Locations 2-5-1-1. Information Button Reader I_BUTTON1: Information button reader ASSIGNMENT I_B1 I-BUTTON1 2-5-1-2. Output Connector IO1: Output wafer ASSIGNMENT ASSIGNMENT CLK_KB RX_MSR CLK_PC TX_MSR DATA_KB DATA_PC USB_D+_R USB_D-_R CHASSIS GND ’ Page: 2-49 PA-8225 SERIES USER S MANUAL...
  • Page 64 - Wireless Module Driver (Optional)  Embedded Peripheral Device - Printer - VFD - MSR   BIOS Operation - Setup - Watchdog Timer Configuration - Update Procedure - System Resource Map ’ Page: 3-1 PA-8225 SERIES USER S MANUAL...
  • Page 65 Chapter 3 Software 3-1. DRIVER 3-1-1-1. Introduction Enclosed with the PA-8225 Series package is our driver utilities, which comes in a DVD-ROM format. 3-1-2-1. API Package Folder Refer to the "3-3 API" for the details. +--->\DEMO PROJECT\ +--->\ProxAPI standard\ +--->\Document\ 3-1-2-2.
  • Page 66 OS installation. Please follow the steps below: Connect the USB DVD-ROM device to PA-8225 and insert the driver disk. Enter the “Main Chip” folder where the Chipset driver is located (depending on your OS platform).

  • Page 67: Vga Driver Utility

    Chapter 3 Software 3-1-4. VGA Driver Utility The VGA interface embedded with PA-8225 can support a wide range of display types. You can have dual displays via CRT & LVDS interfaces work simultaneously. 3-1-4-1. Installation of VGA Driver To install the Graphics driver, follow the steps below: Connect the USB-DVD ROM device to PA-8225 and insert the driver disk.

  • Page 68: Sound Driver Utility

    OS platform). Click Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once installation is completed, shut down the system and restart PA-8225 for the changes to take effect. 3-1-7. Touchscreen Driver Utility The touchscreen driver utility can only be installed on Windows POSReady 7 &...
  • Page 69 Click Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once installation is completed, shut down the system and restart PA-8225 for the changes to take effect. 3-1-9. RFID Module Driver Utility (Optional) The RFID driver utility can only be installed on Windows POSReady7 &...
  • Page 70 Enter the “Device\Embedded Wireless Module” folder where the wireless driver is located. Click Setup.exe file for driver installation. Follow the on-screen instructions to complete the installation. Once installation is completed, shut down the system and restart PA-8225 for the changes to take effect. ’ Page: 3-7...

  • Page 71: Peripheral Devices

    Command lists and driver installation guide for peripheral devices of the system - printer board, VFD and MSR – are explicitly included in this section. 3-2-1. Printer Board: MB-1030 3-2-1-1. Command Printer Registry Operation Registry Name Default Data Notes BaudRate 115200 BitLength Parity Stop ’ Page: 3-8 PA-8225 SERIES USER S MANUAL...
  • Page 72 Kanji Control Commands Other Command Command MB-1030 MB-1030 Command MB-1030 MB-1030 FS ! ESC i FS & ESC m DC2 ; FS . GS p 1 FS 2 FS C FS S FS W ’ Page: 3-9 PA-8225 SERIES USER S MANUAL...
  • Page 73 Set printing area in page mode <ESC \> 1B 5C Set relative print position ▲ ◎ <ESC a> 1B 61 Select justification <ESC c 3> 1B 63 33 Select paper sensor(s) to output paper-end ’ Page: 3-10 PA-8225 SERIES USER S MANUAL...
  • Page 74 <GS k> 1D 6B Print bar code <GS r> 1D 72 Transmit status ● <GS v 0> 1D 76 30 Print raster bit image Disabled <GS w> 1D 77 Set bar code width ’ Page: 3-11 PA-8225 SERIES USER S MANUAL...
  • Page 75 ●: Enabled only when data is not present in the printer buffer. ▲: Only value setting is possible. Disabled: Parameters are processed as printable data. Ignored: All command codes including parameters are ignored and nothing is executed. ’ Page: 3-12 PA-8225 SERIES USER S MANUAL...
  • Page 76 [Name] Print and recover to standard mode (in page mode) ASCII [Format] Hex. Decimal [Range] Prints all buffered data to the print region collectively, and then recovers to the [Description] standard mode. ’ Page: 3-13 PA-8225 SERIES USER S MANUAL...
  • Page 77 [Description] n = 1 : Transmit printer status. n = 2 : Transmit off-line status. n = 3 : Transmit error status. n = 4 : Transmit paper roll sensor status. ’ Page: 3-14 PA-8225 SERIES USER S MANUAL...
  • Page 78 Not used. Fixed to On. Not used. Fixed to Off. Not used. Fixed to Off. Not used. Fixed to On. Not used. Fixed to Off. Not used. Fixed to Off. Not used. Fixed to Off. ’ Page: 3-15 PA-8225 SERIES USER S MANUAL...
  • Page 79 DLE DC4 n m t [Name] Real-time output of specified pulse. ASCII DLE DC4 n m t [Format] Hex. n m t Decimal n m t n = 1 [Range] m = 0,1 ’ Page: 3-16 PA-8225 SERIES USER S MANUAL...
  • Page 80 This command sets the size of space to right of character. [Description] Right space = n × [horizontal motion units]. ESC ! n [Name] Select print mode(s). ASCII [Format] Hex. Decimal 0 ≤ n ≤ 255 [Range] Initial Value n = 0 ’ Page: 3-17 PA-8225 SERIES USER S MANUAL...
  • Page 81 1B 2A m nL nH d1...dk Decimal 27 42 m nL nH d1...dk m = 0,1,32,33 0 ≤ nL ≤ 255 [Range] 0 ≤ nH ≤ 3 0 ≤ d ≤ 255 ’ Page: 3-18 PA-8225 SERIES USER S MANUAL...
  • Page 82 [Name] Select default line spacing. ASCII [Format] Hex. Decimal [Range] This command sets the default line spacing The default line spacing is [Description] approximately 4.25 mm, which is equivalent to 34 dots. ’ Page: 3-19 PA-8225 SERIES USER S MANUAL...
  • Page 83 Undefined Undefined Printer Invalid Valid ESC @ [Name] Initialize printer. ASCII ESC @ [Format] Hex. Decimal [Range] [Description] Clears data from the print buffer and sets the printer to its default settings. ’ Page: 3-20 PA-8225 SERIES USER S MANUAL...
  • Page 84  n is effective only when it is the lowest bit. [Description]  This printer is not capable of double printing, so the print is the same as when using emphasized printing.  This command is enabled for ANK characters ’ Page: 3-21 PA-8225 SERIES USER S MANUAL...
  • Page 85 Set space amount: ESC SP, FS S b. Set line feed amount: ESC 2, ESC 3  The following commands are enabled only when in page mode. ’ Page: 3-22 PA-8225 SERIES USER S MANUAL...
  • Page 86 Character font A selected Character font B selected ESC R n [Name] Select an international character set. ASCII ESC R [Format] Hex. Decimal 0 ≤ n ≤ 16 [Range] Initial Value n = 0 ’ Page: 3-23 PA-8225 SERIES USER S MANUAL...
  • Page 87 ESC SP :Set character right space amount b. FS S :Set Chinese character space amount ’ Page: 3-24 PA-8225 SERIES USER S MANUAL...
  • Page 88 Lower Left (B in the figure below) 2, 50 Right to Left Lower Right (C in the figure below) 3, 51 Top to Bottom Upper Right (D in the figure below) [Description] ’ Page: 3-25 PA-8225 SERIES USER S MANUAL...
  • Page 89  (Y+Dy-1)<768 (basic calculated pitch=1);  If (horizontal starting position + printing area width) exceeds the printable area, the printing area width is automatically set to (horizontal printable area - horizontal starting position). ’ Page: 3-26 PA-8225 SERIES USER S MANUAL...
  • Page 90 This command specifies position alignment for all data in one line in the standard mode, using n as follows: Alignment Left alignment [Description] Center alignment Right alignment This command has no effect in page mode. ’ Page: 3-27 PA-8225 SERIES USER S MANUAL...
  • Page 91 Selects the paper out detector to stop printing when paper has run out. 〝 0 〞 〝 1 〞 Function Undefined Undefined Undefined [Description] Undefined Undefined Undefined Paper roll near end detector Invalid Valid Paper roll near end detector Invalid Valid ’ Page: 3-28 PA-8225 SERIES USER S MANUAL...
  • Page 92 This command executes a full cut of the paper in standard mode ESC m [Name] Partial cut. ASCII [Format] Hex. Decimal [Range] This command executes a partial cut of the paper with one point uncut in [Description] standard mode. ’ Page: 3-29 PA-8225 SERIES USER S MANUAL...
  • Page 93 0 ≤ n ≤ 8 [Range] Initial Value n = 0 Select page n of the character code table. Character set CP-437 Katakana CP-850 CP-852 [Description] CP-860 CP-863 CP-865 CP-1252 User Define ’ Page: 3-30 PA-8225 SERIES USER S MANUAL...
  • Page 94  NV bit image is a bit image defined in non-volatile memory by FS q and printed by this command.  This command is ignored when the specified NV bit image n is undefined. ’ Page: 3-31 PA-8225 SERIES USER S MANUAL...
  • Page 95  xL and xH specify the horizontal direction for one NV bit image (xL + xH x 256) x 8 dots.  yL and yH specify the vertical direction for one NV bit image (yL + yH x 256) x 8 dots. [Description] ’ Page: 3-32 PA-8225 SERIES USER S MANUAL...
  • Page 96 5 times 6 times 7 times 8 times Table 2 [Enlarged in vertical direction] Decimal Enlargement 1 time(standard) 2 times 3 times 4 times 5 times 6 times 7 times 8 times ’ Page: 3-33 PA-8225 SERIES USER S MANUAL...
  • Page 97 [d1…d(X x Y x 8)] Decimal 1 ≤ X ≤ 54 (for 2 inch) 1 ≤ X ≤ 72 (for 3 inch) [Range] 1 ≤ Y ≤ 96 0 ≤ d ≤ 255 ’ Page: 3-34 PA-8225 SERIES USER S MANUAL...
  • Page 98 {pL+ (pH×256) } = 2 (pL = 2,pH = 0) 0 ≤ n ≤ 2 , 48 ≤ n ≤ 50 [Range] 2 ≤ m ≤ 3 , 50 ≤ m ≤ 51 ’ Page: 3-35 PA-8225 SERIES USER S MANUAL...
  • Page 99 {pL+ (pH×256) } = 2 (pL = 2,pH = 0) n = 49 250 ≤ m ≤ 255, 0 ≤ m ≤ 6 Initial Value m = 0 [Description] Sets print density.. Print Density ’ Page: 3-36 PA-8225 SERIES USER S MANUAL...
  • Page 100  This command is effective for ANK and Chinese characters. GS H n [Name] Select printing position of HRI characters. ASCII [Format] Hex. Decimal 0 ≤ n ≤ 3, 48 ≤ n ≤ 51 [Range] Initial Value n = 0 ’ Page: 3-37 PA-8225 SERIES USER S MANUAL...
  • Page 101 [Range] Initial Value (nL + nH x 256)=0 (nL=0, nH=0) nL and nH set the specified left margin. [Description] The left margin is [(nL + nH x 256) x basic calculated pitch]. ’ Page: 3-38 PA-8225 SERIES USER S MANUAL...
  • Page 102 Feeds paper to (cutting position + [n x basic calculated pitch]) and performs a partial cut (one point uncut) GS W nL nH [Name] Set printing area width. ASCII nL nH [Format] Hex. nL nH Decimal nL nH ’ Page: 3-39 PA-8225 SERIES USER S MANUAL...
  • Page 103 Selects the statuses that are targeted for transmission with the automatic status function (ASB: Automatic Status Back). “0” “1” Bits Statuses Targeted for ASB Undefined [Description] Undefined Undefined Undefined Continuous Paper Detector Invalid Valid Error Invalid Valid ’ Page: 3-40 PA-8225 SERIES USER S MANUAL...
  • Page 104 Function Not used. Fixed to Off Not used. Fixed to Off Not used. Fixed to Off Not used. Fixed to Off Paper end sensor: paper present Paper end sensor: no paper present ’ Page: 3-41 PA-8225 SERIES USER S MANUAL...
  • Page 105 GS h n [Name] Set bar code height. [Format] ASCII Hex. Decimal 104 n 1 ≤ n ≤ 255 [Range] Initial Value n = 162 [Description] Sets bar code height to n dots. ’ Page: 3-42 PA-8225 SERIES USER S MANUAL...
  • Page 106 48 ≤ d ≤ 57, 65 ≤ d ≤ 68, CODABAR 36, 43, 45, 46, 47, 58 1 ≤ n ≤ 255 0 ≤ d ≤ 127 CODE93 2 ≤ n ≤ 255 0 ≤ d ≤ 127 CODE128 ’ Page: 3-43 PA-8225 SERIES USER S MANUAL...
  • Page 107 = 0, m = 48 0 ≤ xL ≤ 54(for 2 inch) 0 ≤ xL ≤ 72(for 3 inch) [Range] 0 ≤ xH ≤ 0 0 ≤ yL ≤ 255 0 ≤ yH ≤ 3 ’ Page: 3-44 PA-8225 SERIES USER S MANUAL...
  • Page 108 Binary Level Bar Code Multi-level Bar Code Fine Element Thick Element Module Width [mm] Width[mm] Width[mm] 0.141 0.141 0.423 [Description] 0.282 0.282 0.706 0.423 0.423 1.129 0.564 0.564 1.411 0.706 0.706 1.834 0.847 0.847 2.258 ’ Page: 3-45 PA-8225 SERIES USER S MANUAL...
  • Page 109 Numerical mode Alphanumeric mode 8-bit byte mode Kanji mode Mixed mode nl, nh: Specifies the number of data. Data: Kanji data of the QRCode data should be set by Shift JIS code. ’ Page: 3-46 PA-8225 SERIES USER S MANUAL...
  • Page 110 [Range] [Description] Specifies Kanji character mode. FS - n [Name] Turn underline mode on/off for Kanji characters ASCII [Format] Hex. Decimal 0 ≤ n ≤ 2, 48 ≤ n ≤ 50 [Range] ’ Page: 3-47 PA-8225 SERIES USER S MANUAL...
  • Page 111 Kanji character underlines. 2,50 Sets to two-dot width Kanji character underline and cancels Kanji character underlines. FS . [Name] Cancel Kanji character mode. ASCII [Format] Hex. Decimal [Range] [Description] Cancels Kanji character mode. ’ Page: 3-48 PA-8225 SERIES USER S MANUAL...
  • Page 112 Specifies or cancels quadruple size Kanji character.  Cancels quadruple size when n = <*******0>B. [Description]  Specifies quadruple size when n = <*******1>B.  n is effective only when it is the lowest bit. ’ Page: 3-49 PA-8225 SERIES USER S MANUAL...
  • Page 113  Follow the wizard instructions to complete the installation. Launching Program Below steps guide you to load the MB1030 program.  Click POSPrinter folder from the path Start\Programs\Protech OPOS.  Click MB1030 to launch the program. ’ Page: 3-50 PA-8225 SERIES USER S MANUAL...
  • Page 114 OPOS Control Object of MB1030 Program a.) Print tab buttons: Button/Item Description Printer Normal Print the string. b.) Bitmap tab buttons/items: Button/Item Description Load Load bitmap file. Print Bitmap Print bitmap file. Normal or Rotate 108˚. Type ’ Page: 3-51 PA-8225 SERIES USER S MANUAL...
  • Page 115 Note BaudRate String 115200 UART Baud Rate (default) BitLength String UART Data Bit (default) Parity String UART Parity Bit (default) Port String COM4 UART Port (default) Stop String UART Stop Bit (default) ’ Page: 3-52 PA-8225 SERIES USER S MANUAL...
  • Page 116 Properties specific long CapJrnCartridgeSensor Read only Not Applicable Properties specific long CapJrnColor Read only Not Applicable Properties specific long CapJrnDhigh Read only Not Applicable Properties specific long CapJrnDwide Read only Not Applicable ’ Page: 3-53 PA-8225 SERIES USER S MANUAL...
  • Page 117 Properties specific bool CapSlpDwide Read only Not Applicable Properties specific bool CapSlpDwideDhigh Read only Not Applicable Properties specific bool CapSlpEmptySensor Read only Not Applicable Properties specific bool CapSlpItalic Read only Not Applicable ’ Page: 3-54 PA-8225 SERIES USER S MANUAL...
  • Page 118 Properties specific long RecSidewaysMaxChars Read only Not Applicable Properties specific long RecLinesToPaperCut Read only Not Applicable Properties specific string RecBarCodeRotationList Read only Not Applicable Properties specific long RecCartridgeState Read only Not Applicable ’ Page: 3-55 PA-8225 SERIES USER S MANUAL...
  • Page 119 EndInsertion Not Applicable Methods specific BeginRemoval Not Applicable Methods specific EndRemoval Not Applicable Methods specific CutPaper Supported Methods specific RotatePrint Supported (only 180) Methods specific PrintBarCode Supported Methods specific PrintBitmap Supported ’ Page: 3-56 PA-8225 SERIES USER S MANUAL...
  • Page 120 Methods specific MarkFeed Not Applicable Events common DataEvent Not Applicable Events common DirectIOEvent Not Applicable Events common ErrorEvent Not Applicable Events common OutputComplete Not Applicable Event Events common StatusUpdate Not Applicable Event ’ Page: 3-57 PA-8225 SERIES USER S MANUAL...
  • Page 121 COM1 Stop OPOS VFD Service Object and Method Relations Method Status of support Notes ○ Open ○ Close ○ ClaimDevice ○ ReleaseDevice ○ Enable ○ Disable ○ DisplayText ○ DisplayTextAt ○ ClearText ’ Page: 3-58 PA-8225 SERIES USER S MANUAL...
  • Page 122  Follow the wizard instructions to complete the installation. Launching Program Below steps guide you to load the Prox-PMP4000 program.  Click LineDisplay folder from the path Start/Programs/Protech OPOS.  Click Prox-PMP4000 to launch the program. ’ Page: 3-59 PA-8225 SERIES USER S MANUAL...
  • Page 123 Note BaudRate String 9600 UART Baud Rate (default) BitLength String UART Data Bit (default) Parity String UART Parity Bit (default) Port String COM1 UART Port (default) Stop String UART Stop Bit (default) ’ Page: 3-60 PA-8225 SERIES USER S MANUAL...
  • Page 124 Properties specific bool CapICharWait Read only Not Applicable Properties specific long CapReadBack Read only Not Applicable Properties specific long CapReverse Read only Not Applicable Properties specific bool CapVMarquee Read only Not Applicable ’ Page: 3-61 PA-8225 SERIES USER S MANUAL...
  • Page 125 Methods common DirectIO Not Applicable Methods specific DisplayText Supported Methods specific DisplayTextAt Supported Methods specific ClearText Supported Methods specific ScrollText Not Applicable Methods specific SetDescriptor Not Applicable Methods specific ClearDescriptors Not Applicable ’ Page: 3-62 PA-8225 SERIES USER S MANUAL...
  • Page 126 Methods specific DefineGlyph Not Applicable Events common DataEvent Not Applicable Events common DirectIOEvent Not Applicable Events common ErrorEvent Not Applicable Events common OutputComplete Not Applicable Event Events common StatusUpdate Not Applicable Event ’ Page: 3-63 PA-8225 SERIES USER S MANUAL...
  • Page 127  Follow the wizard instructions to complete the installation. Launching Program Below steps guide you load the Prox-PMP3000 program.  Click MSR folder from the path Start/Programs/Protech OPOS.  Click Prox-PMP3000 to launch the program. ’ Page: 3-64 PA-8225 SERIES USER S MANUAL...
  • Page 128 Configuration of Prox-PMP3000 program a.) Main screen & Control tab items: Button/Item Description (dropdown list) To set COM port number (only for USRT/USB interface). AutoDisable (check box) Set auto-disable FreeseEvents (check box) Set freeze events ’ Page: 3-65 PA-8225 SERIES USER S MANUAL...
  • Page 129 Set parse decode data properties TransmitSentinels Set transmit-sentinels properties ErrorReporting Type Card, track TracksToRead Track1, track2, track3, tracks12, tracks13, tracks14, tracks23, tracks24, tracks34, tracks123, tracks124, tracks134, tracks234, tracks1234 (Tracks4 is not applicable). ’ Page: 3-66 PA-8225 SERIES USER S MANUAL...
  • Page 130 Chapter 3 Software d.) Track Data tab items Button/Item Description TracksData (Row) Display data of all tracks (Track4 is not applicable). e.) Parsed Data tab items Button/Item Description Parsed Data Display special properties. ’ Page: 3-67 PA-8225 SERIES USER S MANUAL...
  • Page 131 Read only Supported Properties specific bool CapJISTwo Read only Supported Properties specific bool CapTransmitSentinels Read only Supported Properties specific long TracksToRead Supported Properties specific bool DecodeData Not Applicable Properties specific bool ParseDecodeData Supported ’ Page: 3-68 PA-8225 SERIES USER S MANUAL...
  • Page 132 Supported Events common DirectIOEvent Not Applicable Events common ErrorEvent Not Applicable Events common OutputCompleteEvent Not Applicable Events common StatusUpdateEvent Not Applicable 3-2-4. MSR: GIGA-TMS MJR243R (RS-232) 3-2-4-1. Command List MSR Registry Operation ’ Page: 3-69 PA-8225 SERIES USER S MANUAL...
  • Page 133 Devive Name for CO open FileName (NULL) (reserved) HardwareProvider (reserved) Model MJR243 Device model name Parity for the communication Parity None port Port COM4 Comport Protocol Hardware Communication Control Baudrate 19200 RS232 baudrate ’ Page: 3-70 PA-8225 SERIES USER S MANUAL...
  • Page 134 ○ AccountNumber Read only ○ DecodeData ○ ExpirationDate Read only ○ FirstName Read only ○ MiddleInitial Read Only ○ ParseDecodeData ○ ServiceCode Read Only ○ Suffix Read Only ○ Surname Read Only ’ Page: 3-71 PA-8225 SERIES USER S MANUAL...
  • Page 135 Status of support by Notes the driver ○ Title Read Only ○ Track1Data Read Only ○ Track1DiscretionaryData Read Only ○ Track2Data Read Only ○ Track2DiscretionaryData Read Only ○ Track3Data Read Only ○ TracksToRead ○ TransmitSentinels ’ Page: 3-72 PA-8225 SERIES USER S MANUAL...
  • Page 136  Follow the wizard instructions to complete the installation. Launching Program Below steps guide you to load the OPOS MSR Register program.  Click OPOS folder from the path Start/Programs/GIGA‐TMS.  Click OPOS MSR Register to launch the program. ’ Page: 3-73 PA-8225 SERIES USER S MANUAL...
  • Page 137 Step 1: Select an item in Service Object List box (left pane). Make sure the correct item is selected. Step 2: Click Reg button Step 3: In the OPOS MSR Setting screen, enter the device name and click OK. ’ Page: 3-74 PA-8225 SERIES USER S MANUAL...
  • Page 138 Chapter 3 Software c.) Example 1. MAGTEK USB HID d.) Example 2. PROMAG MSR/MJR PART‐ NO, Keyboard mode. ’ Page: 3-75 PA-8225 SERIES USER S MANUAL...
  • Page 139 Description for SO driver MSR POS DeviceName string MJR243 Devive Name for CO open FileName string (NULL) (reserved) HardwareProvider string (reserved) Model string MJR243 Device model name Parity string None Parity for the communication ’ Page: 3-76 PA-8225 SERIES USER S MANUAL...
  • Page 140 Read only Supported Properties common ServiceObject Read only Supported string Description Properties common long ServiceObjectVersion Read only Supported Properties common DeviceDescription Read only Supported string Properties common DeviceName Read only Supported string ’ Page: 3-77 PA-8225 SERIES USER S MANUAL...
  • Page 141 Properties specific bool TransmitSentinels Supported Methods common Open Supported Methods common Close Supported Methods common Claim Supported Methods common ClaimDevice Supported Methods common Release Supported Methods common ReleaseDevice Supported Methods common CheckHealth Not Applicable ’ Page: 3-78 PA-8225 SERIES USER S MANUAL...
  • Page 142 UpdateFirmware Not Applicable Methods common UpdateStatistics Not Applicable Events common DataEvent Supported Events common DirectIOEvent Not Applicable Events common ErrorEvent Not Applicable Events common OutputCompleteEvent Not Applicable Events common StatusUpdateEvent Not Applicable ’ Page: 3-79 PA-8225 SERIES USER S MANUAL...
  • Page 143 Launching Program Below steps guide you to load the OPOS MSR Tester program.  Click OPOS folder from the path Start\Programs\GIGA ‐ TMS.  Click OPOS MSR Tester to launch the program. ’ Page: 3-80 PA-8225 SERIES USER S MANUAL...
  • Page 144 To start using OPOS driver to get track data, follow the steps below. Step 1: Entering the Device Name. Step 2: Clicking Open button. Step 3: Swiping card to get track data. ’ Page: 3-81 PA-8225 SERIES USER S MANUAL...
  • Page 145 Chapter 3 Software c.) Example 1. MAGTEK USB HID. d.) Example 2. PROMAG MSR/MJR PART‐ NO, Keyboard mode ’ Page: 3-82 PA-8225 SERIES USER S MANUAL...
  • Page 146 Chapter 3 Software e.) Example 3. PROMAG MSR PART‐ NO, HID mode ’ Page: 3-83 PA-8225 SERIES USER S MANUAL...
  • Page 147 Name*\Initial.xml Version.ini Version information Sample Program Directory Contents / File Name Description DEMO DEMO PROJECT\GPIO Sample C# VB6 VB.net Source Code Code PROJECT\ DEMO PROJECT\Digital C# VB6 VB.net Source Code Sample Code ’ Page: 3-84 PA-8225 SERIES USER S MANUAL...
  • Page 148 Text1.text = “cash drawer1 open” ‘enter text into textbox. Else Text1.text = “cash drawer1 close” ‘enter text into textbox. End if ‘========================================= Receive_Status2 = CashDrawerOpen(&H2) If Receive_Status2 = true then Text2.text = “cash drawer2 open” ‘enter text into textbox. ’ Page: 3-85 PA-8225 SERIES USER S MANUAL...
  • Page 149 Chapter 3 Software Else Text2.text = “cash drawer2 close” ‘enter text into textbox. End if ‘========================================= End sub ’ Page: 3-86 PA-8225 SERIES USER S MANUAL...
  • Page 150 Open cash drawer: CashDrawerOpen(1) Open cash drawer1 CashDrawerOpen(2) Open cash drawer2 Check cash drawer status: Dim receive_status as Boolean Check cash drawer1 status Receive_Status = CashDrawerOpen(&H1) Check cash drawer2 status Receive_Status = CashDrawerOpen(&H2) ’ Page: 3-87 PA-8225 SERIES USER S MANUAL...
  • Page 151 PortAccess.CashDrawerOpen(0x01); //check cash drawer1 status Open cash drawer2 PortAccess.CashDrawerOpen(0x02); //check cash drawer2 status Bool bstatus; bstatus = PortAccess.GetCashDrawerStatus(0x01); bstatus = PortAccess.GetCashDrawerStatus(0x02); //Before get cash drawer status, need to initial cash drawer first ’ Page: 3-88 PA-8225 SERIES USER S MANUAL...
  • Page 152 VB 6 extern function: Declare Function CashDrawerOpen Lib "CashDrawer.dll" (ByVal num_drawer As Integer) As Boolean Declare Function GetCashDrawerStatus Lib "CashDrawer.dll" (ByVal num_drawer As Integer) As Boolean Note: VB.net short = integer VB6 ’ Page: 3-89 PA-8225 SERIES USER S MANUAL...

  • Page 153: Cash Drawer

    OPEN (button) Tap to open the cash drawer. Cash Drawer Status Cash drawer status will be displayed after OPEN is tapped.  Drawer is closed as shown:  Drawer is open as shown: ’ Page: 3-90 PA-8225 SERIES USER S MANUAL...
  • Page 154 The API program-related sample programs, developed in VB.Net and C#, are provided for easy use of the API Package. Refer to the main API functions listed as below. API Function Cash Drawer CashDrawerOpen multilangXML.dll CashDrawer.dll GetCashDrawerStatus ’ Page: 3-91 PA-8225 SERIES USER S MANUAL...
  • Page 155 True (1) on success, False (0) on failure Example: Short data; data= GetCashDrawerStatus(0x01); // Get the Cash Drawer1 status if (data) MsgBox(“open1”); // Cash Drawer1 status “Open” Else MsgBox(“close1”); // Cash Drawer1 status “Close” Endif ’ Page: 3-92 PA-8225 SERIES USER S MANUAL...
  • Page 156 3-4. BIOS Operation 3-4-1. Introduction The board PA-8225 uses an AMI Aptio BIOS that is stored in the Serial Peripheral Interface Flash Memory (SPI Flash) and can be updated. The SPI Flash contains the BIOS Setup program, Power-on Self-Test (POST), the PCI auto-configuration utility, LAN EEPROM information, and Plug and Play support.
  • Page 157 The BIOS Setup program is accessed by pressing the <Del> or <ESC> key after the POST memory test begins and before the operating system boot begins. The settings are shown below. ’ Page: 3-94 PA-8225 SERIES USER S MANUAL...

  • Page 158: Entering Setup

    Setup program. In a moment, the main menu of the Aptio Setup Utility will appear on the screen: ’ Page: 3-95 PA-8225 SERIES USER S MANUAL...
  • Page 159 You may move the cursor by up/down keys to highlight the individual menu items. As you highlight each item, a brief description of the highlighted selection will appear at the bottom of the screen. ’ Page: 3-96 PA-8225 SERIES USER S MANUAL...
  • Page 160 Displays the date of current BIOS Time version. Sec RC No changeable options Displays the current Sec RC version. Version TXE FW No changeable options Displays the current TXE Version Version System English BIOS Setup language. Language ’ Page: 3-97 PA-8225 SERIES USER S MANUAL...
  • Page 161 Chapter 3 Software BIOS Setting Options Description/Purpose System Date month, day, year Specifies the current date. System Time hour, minute, second Specifies the current time. ’ Page: 3-98 PA-8225 SERIES USER S MANUAL...
  • Page 162 Voltage/RI Adjust Sub-Menu Voltage/RI Adjust settings. Configuration CSM Configuration Sub-Menu Configure Option ROM execution, boot options filters, etc.. USB Configuration Sub-Menu USB Configuration Parameters. SIO Configuration Sub-Menu System Super IO Chip Configuration. ’ Page: 3-99 PA-8225 SERIES USER S MANUAL...
  • Page 163 Enables or Disables System ability to Hibernate (OS/S4 Sleep State). This Hibernation - Enabled option may be not effective with some Lock Legacy - Disabled Enables or Disables Lock of Legacy Resources. - Enabled Resources. ’ Page: 3-100 PA-8225 SERIES USER S MANUAL...
  • Page 164 Displays voltage level of the +VSB5 in supply. VCC5 No changeable options Displays voltage level of the + VCC5 in supply. VCC12 No changeable options Displays voltage level of the + VCC12 in supply. ’ Page: 3-101 PA-8225 SERIES USER S MANUAL...
  • Page 165 Enable/Disable Watch dog timer. WatchDog -Disable Watchdog Select seconds or minutes timer unit -60s Count for Multiple options Sets the desired value (seconds) for Timer ranging from 1 to 255 watchdog timer. (Seconds) ’ Page: 3-102 PA-8225 SERIES USER S MANUAL...
  • Page 166 - Enabled CPUID functions. Set disable for Win Intel - Disabled When enabled, a VMM can utilize the Virtualization additional hardware capabilities - Enabled provided by Vanderpool Technology Technology (VT). ’ Page: 3-103 PA-8225 SERIES USER S MANUAL...
  • Page 167 Reports if Intel VT-x Technology is Technology supported by processor. L1 Data Cache No changeable options Displays size of L1 Data Cache L1 Code Cache No changeable options Displays size of L1 Code Cache ’ Page: 3-104 PA-8225 SERIES USER S MANUAL...
  • Page 168 Chapter 3 Software BIOS Setting Options Description/Purpose L2 Cache No changeable options Displays size of L2 Cache. L3 Cache No changeable options Displays size of L3 Cache. ’ Page: 3-105 PA-8225 SERIES USER S MANUAL...
  • Page 169 Host Controller Interface) mode for getting better performance. SATA Port - Disabled Enable or disable SATA port 0 Device. 0(Note*1) - Enabled SATA Port 0 - Disabled Enable or disable SATA port 0 Device HotPlug ’ Page: 3-106 PA-8225 SERIES USER S MANUAL...
  • Page 170 0. Shows [Empty] if no drive is installed. If mother board support RAID that will show ASMT109x- Conf (0.1GB) SATA Port 1 [drive] Displays the drive installed on this SATA port 1. Shows [Empty] if no drive is installed. ’ Page: 3-107 PA-8225 SERIES USER S MANUAL...
  • Page 171 Chapter 3 Software 3-4-4-6. OS Selection OS Selection Screen BIOS Setting Options Description/Purpose OS Selection - Windows 8.x Operating System Selection - Windows 7 ’ Page: 3-108 PA-8225 SERIES USER S MANUAL...
  • Page 172 -12V Select COM2 Port voltage. - 5V - Disabled COM3 Select -12V Select COM3 Port voltage. - 5V - Cash drawer 12V Cash drawer Select Cash drawer voltage. - Cash drawer 24V ’ Page: 3-109 PA-8225 SERIES USER S MANUAL...
  • Page 173  Always: do not allow disabling GA20; this option is useful when any RT code is executed above 1MB. Option ROM - Force BIOS Set display mode for Option ROM Messages messages. - Keep Current ’ Page: 3-110 PA-8225 SERIES USER S MANUAL...
  • Page 174 Legacy Video. - UEFI only - Legacy only Other PCI - UEFI first Select launch method for other PCI devices, such as NIC, mass storage or devices - Legacy only video card. ’ Page: 3-111 PA-8225 SERIES USER S MANUAL...
  • Page 175 Enables/Disables USB mass storage Storage Driver driver support. - Enabled Support USB transfer 1/5/10/20 sec The time-out value for Control, Bulk, time-out and Interrupt transfers. Device reset 10/20/30/40 sec USB mass storage device Start Unit ’ Page: 3-112 PA-8225 SERIES USER S MANUAL...
  • Page 176 0 to 40 second increments in seconds Mass Storage - Auto Display the device name and choose Devices: the device emulation type. - Floppy - Force FDD - Hard Disk - CD-ROM ’ Page: 3-113 PA-8225 SERIES USER S MANUAL...
  • Page 177 Set Parameters for COM3 Serial Port 3 [*Active*] Sub-menu Set Parameters for COM4 Serial Port 4 [*Active*] Sub-menu Set Parameters for LPT port. Parallel Port [*Active*] Sub-menu Set Parameters for PS/2. PS/2 Controller (KB&MS) ’ Page: 3-114 PA-8225 SERIES USER S MANUAL...
  • Page 178 1. Possible: -Use Automatic Settings Select IRQ and I/O resource -IO=3F8h; IRQ=4 DMA for the serial -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA port 1. -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA ’ Page: 3-115 PA-8225 SERIES USER S MANUAL...
  • Page 179 2. Possible: -Use Automatic Settings Select IRQ and I/O resource -IO=2F8h; IRQ=3 DMA for the serial -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA port 2 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2E8h; IRQ=3,4,5,6,7,10,11,12 DMA ’ Page: 3-116 PA-8225 SERIES USER S MANUAL...
  • Page 180 -Use Automatic Settings Select IRQ and -IO=3E8h; IRQ=7 DMA I/O resource for the serial -IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA port 3 -IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12 DMA -IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12 DMA ’ Page: 3-117 PA-8225 SERIES USER S MANUAL...
  • Page 181 - IO=2E8h; IRQ=7 DMA the serial port 4 - IO=3F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2F8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=3E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E8h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2F0h; IRQ=3,4,5,6,7,9,10,11,12 DMA - IO=2E0h; IRQ=3,4,5,6,7,9,10,11,12 DMA ’ Page: 3-118 PA-8225 SERIES USER S MANUAL...
  • Page 182 No changeable options Displays current settings of setting the printer port. Possible: -Use Automatic Settings Select IRQ and I/O resource for the printer port. -IO=378h; IRQ=5 -IO=378h; IRQ=5,6,7,9,10,11,12 -IO=278h; IRQ=5,6,7,9,10,11,12 -IO=3BCh; IRQ=5,6,7,9,10,11,12 ’ Page: 3-119 PA-8225 SERIES USER S MANUAL...
  • Page 183  EPP is Enhanced Parallel -ECP and EPP 1.7 Mode Port mode, a high-speed bi-directional mode for non-printer peripherals.  ECP is Enhanced Capability Port mode, a high-speed bi-directional mode for printers and scanners. ’ Page: 3-120 PA-8225 SERIES USER S MANUAL...
  • Page 184 -Enabled Logical device No changeable options Displays current settings of setting Current the printer port. Possible: - Use Automatic Settings Select IRQ and I/O resource for the printer port. -IO=60h; IO=60h; IRQ=1 ’ Page: 3-121 PA-8225 SERIES USER S MANUAL...
  • Page 185 Chapter 3 Software 3-4-6. Chipset Chipset Screen BIOS Setting Options Description/Purpose North Bridge Sub-menu Sets Parameter for (North Bridge) configuration. South Bridge Sub-menu Sets Parameter for (South Bridge) configuration. ’ Page: 3-122 PA-8225 SERIES USER S MANUAL...
  • Page 186 North Bridge Screen BIOS Setting Options Description/Purpose Intel IGD Sub-menu Configure Graphic Settings. Configuration Memory No changeable options Displays the DRAM information on Information platform. Total Memory No changeable options Displays the DRAM size ’ Page: 3-123 PA-8225 SERIES USER S MANUAL...
  • Page 187 Adaptor.  Disable: Always disable IGD" IGD Turbo - Disabled Enable or disable IGD Turbo Enable - Enabled GFX Boost - Disabled Enable or disable GFX Boost accelerated graphics processing - Enabled ’ Page: 3-124 PA-8225 SERIES USER S MANUAL...
  • Page 188 BIOS Setting Options Description/Purpose DVMT - 32M Select DVMT 5.0 Pre-Allocated Pre-Allocated (Fixed) Graphics Memory size used - 64M by the Internal Graphics Device. - 96M - 128M - 256M - 512M ’ Page: 3-125 PA-8225 SERIES USER S MANUAL...
  • Page 189  Power On makes system power on after restores AC power to the board.  Last State brings system back to the last power state before AC ’ Page: 3-126 PA-8225 SERIES USER S MANUAL...
  • Page 190 Chapter 3 Software BIOS Setting Options Description/Purpose remove. ’ Page: 3-127 PA-8225 SERIES USER S MANUAL...
  • Page 191 Enabled or Disabled USB port 1 - Enabled USB Port 2 - Disabled Enabled or Disabled USB port 2 - Enabled USB Port 3 - Disabled Enabled or Disabled USB port 3 - Enabled ’ Page: 3-128 PA-8225 SERIES USER S MANUAL...
  • Page 192 - Gen2 PCI Express - Disabled Enables or Disables PCI Express port 3. Port 3 (For - Enabled RTL8111) Speed - Auto Selects PCI Express port 3 speed. - Gen1 - Gen2 ’ Page: 3-129 PA-8225 SERIES USER S MANUAL...
  • Page 193 Description/Purpose Administrator Password can be 3-20 Specifies the administrator password. alphanumeric Password characters. User Password Password can be 3-20 Specifies the user password. alphanumeric characters. HDD Security Sub-menu Set HDD password. Configuration: ’ Page: 3-130 PA-8225 SERIES USER S MANUAL...
  • Page 194 - Enabled Boot Option - [Drive(s)] Allows setting boot option listed in #1~#n Hard Drive BBS Priorities. - Disabled Hard Drive Sub-Menu Allow user to select boot order of BBS Priorities available drive(s) ’ Page: 3-131 PA-8225 SERIES USER S MANUAL...
  • Page 195 Chapter 3 Software 3-4-7-1. Hard Drive BBS Priorities Hard Drive BBS Priorities Screen BIOS Setting Options Description/Purpose Boot Option #1 - [Drive(s)] Change the boot order of available - #n drive(s). - Disabled ’ Page: 3-132 PA-8225 SERIES USER S MANUAL...
  • Page 196 Resets without saving any changes Changes and made in BIOS settings. Reset Restore No changeable options Loads the optimized defaults for BIOS Defaults settings. Boot Override - [Drive(s)] Forces to boot from selected [drive(s)]. ’ Page: 3-133 PA-8225 SERIES USER S MANUAL...

  • Page 197: Watchdog Timer Configuration

    To exit the Extended Function Mode, writing 0xAA to the EFER is required. Once the chip exits the Extended Function Mode, it is in the normal running mode and is ready to enter the configuration mode. ’ Page: 3-134 PA-8225 SERIES USER S MANUAL...
  • Page 198 ;------ Select Logical Device 7 of watchdog timer -------------------------------------------- ;------ Enable Watch dog feature -------------------------------------------- 030h ;------ Enable Watch PME-------------------------------------------- 0FAh ;------ Set second as counting unit -------------------------------------------------------------- 0f5h ;------ Set timeout interval as 30seconds and start counting --------------------------------- ’ Page: 3-135 PA-8225 SERIES USER S MANUAL...
  • Page 199 Chapter 3 Software 0f6h ;------ Exit the extended function mode -------------------------------------------------------- 0aah ’ Page: 3-136 PA-8225 SERIES USER S MANUAL...
  • Page 200 Select [Boot] menu as the picture shows below. Select [Hard Drive BBS Priorities], set the USB bootable device as the 1 boot device. Press <F4> key to save configuration and exit the BIOS setup menu. ’ Page: 3-137 PA-8225 SERIES USER S MANUAL...
  • Page 201 The recommended options for BIOS ROM update consist of the following parameters: program main BIOS image /B: program Boot Block /N: program NVRAM /X: don’t check ROM ID ’ Page: 3-138 PA-8225 SERIES USER S MANUAL...
  • Page 202 Restart the system and boot up with the new BIOS configurations. The BIO Update is completed after the system is restarted. Verify during the following boot that BIOS version displayed at the initialization screen has changed. ’ Page: 3-139 PA-8225 SERIES USER S MANUAL...
  • Page 203 Chapter 3 Software ’ Page: 3-140 PA-8225 SERIES USER S MANUAL...

  • Page 204: Interrupt Map

    Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-141 PA-8225 SERIES USER S MANUAL...
  • Page 205 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-142 PA-8225 SERIES USER S MANUAL...
  • Page 206 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-143 PA-8225 SERIES USER S MANUAL...
  • Page 207 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-144 PA-8225 SERIES USER S MANUAL...
  • Page 208 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-145 PA-8225 SERIES USER S MANUAL...
  • Page 209 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-146 PA-8225 SERIES USER S MANUAL...
  • Page 210 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-147 PA-8225 SERIES USER S MANUAL...
  • Page 211 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-148 PA-8225 SERIES USER S MANUAL...
  • Page 212 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-149 PA-8225 SERIES USER S MANUAL...
  • Page 213 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-150 PA-8225 SERIES USER S MANUAL...
  • Page 214 Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System Microsoft ACPI-Compliant System ’ Page: 3-151 PA-8225 SERIES USER S MANUAL...
  • Page 215 USB 3.0 eXtensible Host Controller - 0100 (Microsoft) ® 4294967293 Intel Trusted Execution Engine Interface 4294967294 Realtek PCIe GBE Family Controller 3-7-2. DMA Channels Map TIMER CHANNEL ASSIGNMENT Channel 4 Direct memory access controller ’ Page: 3-152 PA-8225 SERIES USER S MANUAL...
  • Page 216 Programmable interrupt controller 0x000000A4-0x000000A5 Programmable interrupt controller 0x000000A8-0x000000A9 Programmable interrupt controller 0x000000AC-0x000000AD Programmable interrupt controller 0x000000B0-0x000000B1 Programmable interrupt controller 0x000000B2-0x000000B3 Motherboard resources 0x000000B4-0x000000B5 Programmable interrupt controller 0x000000B8-0x000000B9 Programmable interrupt controller 0x000000BC-0x000000BD Programmable interrupt controller ’ Page: 3-153 PA-8225 SERIES USER S MANUAL...
  • Page 217 N- and J-series AHCI - 0F23 ® ® ® 0x0000F070-0x0000F077 Intel Pentium processor N- and J-series / Intel ® Celeron processor N- and J-series AHCI - 0F23 ® 0x0000F080-0x0000F087 Intel HD Graphics ’ Page: 3-154 PA-8225 SERIES USER S MANUAL...

  • Page 218: Memory Map

    ® Celeron processor N- and J-series AHCI - 0F23 ® 0xE00000D0-0xE00000DB Intel Sideband Fabric Device ® 0xFF000000-0xFFFFFFFF Intel 82802 Firmware Hub Device 0xA0000-0xBFFFF PCI Express Root Complex ® 0xA0000-0xBFFFF Intel HD Graphics ’ Page: 3-155 PA-8225 SERIES USER S MANUAL...
  • Page 219 Chapter 3 Software MEMORY MAP ASSIGNMENT 0xC0000-0xDFFFF PCI Express Root Complex 0xE0000-0xFFFFF PCI Express Root Complex ’ Page: 3-156 PA-8225 SERIES USER S MANUAL...
  • Page 220 CHAPTER SYSTEM DIAGRAMS This appendix contains exploded diagrams and part numbers of the PA- 8225 system. Sections included:  Exploded Diagrams for PA-8225 Page: 4-1...
  • Page 221 Chapter 4 System Assembly Exploded Diagram for PA-8225 N / A N / A N / A N / A  Page: 4-2 PA-8225 SERIES USER S MANUAL...
  • Page 222 Chapter 4 System Assembly Exploded Diagram for PA-8225 With 1024X768 Panel  Page: 4-3 PA-8225 SERIES USER S MANUAL...
  • Page 223 Chapter 4 System Assembly 52-380-01 51 0401 52-351 -01 01 041 9 Φ M S R 27-01 8-34205071 C ab le  Page: 4-4 PA-8225 SERIES USER S MANUAL...
  • Page 224 Chapter 4 System Assembly Exploded Diagram for PA-8225 With 800X600 Panel  Page: 4-5 PA-8225 SERIES USER S MANUAL...
  • Page 225 Chapter 4 System Assembly 52-380-01 51 0401 52-351 -01 01 041 9 Φ M S R 27-01 8-34205071 C ab le  Page: 4-6 PA-8225 SERIES USER S MANUAL...
  • Page 226 Chapter 4 System Assembly Exploded Diagram for PA-8225 ID Tech With MSR  Page: 4-7 PA-8225 SERIES USER S MANUAL...
  • Page 227 Chapter 4 System Assembly 52-380-01 51 0401 52-351 -01 01 041 9 Φ N / A C ab le 27-01 8-34205071 M S R  Page: 4-8 PA-8225 SERIES USER S MANUAL...
  • Page 228 Chapter 4 System Assembly Exploded Diagram for PA-8225 With Protech MSR  Page: 4-9 PA-8225 SERIES USER S MANUAL...
  • Page 229 Chapter 4 System Assembly 52-380-01 51 0401 52-351 -01 01 041 9 Φ N / A 27-01 8-34205071 C ab le N / A M S R  Page: 4-10 PA-8225 SERIES USER S MANUAL...
  • Page 230 Chapter 4 System Assembly Exploded Diagram for PA-8225 MSR Module  Page: 4-11 PA-8225 SERIES USER S MANUAL...
  • Page 231 Chapter 4 System Assembly Exploded Diagram for PA-8225 MSR Module  Page: 4-12 PA-8225 SERIES USER S MANUAL...
  • Page 232 Chapter 4 System Assembly Exploded Diagram for PA-8225 With Finger Printer Module & RFID Module  Page: 4-13 PA-8225 SERIES USER S MANUAL...
  • Page 233 Chapter 4 System Assembly Exploded Diagram for PA-8225 With I-Button & RFID Module  Page: 4-14 PA-8225 SERIES USER S MANUAL...
  • Page 234 Chapter 4 System Assembly Exploded Diagram for PA-8225 With Finger Printer Module & RFID & VFD Module  Page: 4-15 PA-8225 SERIES USER S MANUAL...
  • Page 235 Chapter 4 System Assembly Exploded Diagram for PA-8225 With I-Button& RFID Module & VFD Module  Page: 4-16 PA-8225 SERIES USER S MANUAL...
  • Page 236 Chapter 4 System Assembly 1 3-500-0828031 8  Page: 4-17 PA-8225 SERIES USER S MANUAL...
  • Page 237 Chapter 4 System Assembly P B -6822 21 -002-1 9090005 N / A  Page: 4-18 PA-8225 SERIES USER S MANUAL...
  • Page 238 Chapter 4 System Assembly Exploded Diagram for PA-8225 With VFD Module  Page: 4-19 PA-8225 SERIES USER S MANUAL...
  • Page 239 Chapter 4 System Assembly Exploded Diagram for PA-8225 With 2” Printer Module  Page: 4-20 PA-8225 SERIES USER S MANUAL...
  • Page 240 Chapter 4 System Assembly ψ ψ  Page: 4-21 PA-8225 SERIES USER S MANUAL...
  • Page 241 Chapter 4 System Assembly Exploded Diagram for PA-8225 With 3” Printer  Page: 4-22 PA-8225 SERIES USER S MANUAL...
  • Page 242 Chapter 4 System Assembly ψ ψ  Page: 4-23 PA-8225 SERIES USER S MANUAL...
  • Page 243 Chapter 4 System Assembly  Page: 4-24 PA-8225 SERIES USER S MANUAL...
  • Page 244 Chapter 4 System Assembly Exploded Diagram for PA-8225 With Stand Module  Page: 4-25 PA-8225 SERIES USER S MANUAL...
  • Page 245 Chapter 4 System Assembly Exploded Diagram for PA-8225 With Stand Module φ  Page: 4-26 PA-8225 SERIES USER S MANUAL...
  • Page 246 Chapter 4 System Assembly  Page: 4-27 PA-8225 SERIES USER S MANUAL...
  • Page 247 Chapter 4 System Assembly Exploded Diagram For Pa-8225 With 2 Display  Page: 4-28 PA-8225 SERIES USER S MANUAL...

Table of Contents
