Protech Systems POS-6510-MIT Quick Reference Manual

POS-6510-MIT/PPC
Quick
Reference
Guide
Specifications
System
CPU Support
Intel ® Atom
Core Logic
Intel ® ICH8M
Memory
1 x DDRIII SO-DIMM slot, up to 4GB
HDD
1 x 2.5" serial ATA Hard Disk
CF
1 x Compact Flash slot for CF type I/II storage
Network 1 x Giga LAN Base-T Fast Ethernet
Power Supply 120W power adapter
Speaker 1 x 2W
System Weight
POS-6510-MIT : 8.4kg
-
POS-6510-PPC: 6.5kg
Dimension (WxHxD)
POS-6510-MIT : 365 x 421 x 75.7 mm
POS-6510-PPC: 365 x 318.5 x 77 mm
I/O Ports
4 on rear I/O port, 1 on the left side of back cover
USB
2 x DB-9 (COM 2&3), 1 x RJ-45 (COM1)
Serial Ports
1 x PS/2 ports
Keyboard/Mouse
Audio Line-out
VGA 1 x DB-15 VGA Interfacer
Cash Drawer 1 x RJ-11 port, 12/24V selectable
Display
LCD 15" TFT LCD, 250nits, 1024 x 768 resolution
Resistive or Capacitive
Touch Screen
0 ~ 60 degree
Viewing Angle
Environment
0 °C ~ 35 °C
Operating Temp.
Storage Temp. -20 °C ~ 60 °C
Humidity 20% ~ 90%
All Rights Reserved. Copyright 2014
POS-6510-MIT/PPC
® D525 (1.8 GHz)
Packing Checklist
If you discover any item below is damaged or
lost, please contact your vendor.
POS-6510-MIT/PPC
This Quick Reference Guide
AC Power Cord (Optional)
Driver CD
MSR Card Reader (Optional)
i-Button + MSR Card Reader (Optional)
Wireless LAN module (Optional)
Laser Scanner (Optional)
Vertical RFID module (Optional)
Vertical Fingerprint module (Optional)
Ver. Q2
System View
POS-6510-MIT
I/O View
POS-6510-PPC
POS-6510-MIT
POS-6510-PPC
POS-6510-MIT/PPC
POS-6510-MIT/PPC
PIP1230
Unit: mm
