Power Supply Installation

WARNING: AC power wiring must be installed and connected by quali ed personnel. All electrical components and installation
procedures must comply with all applicable local and national electrical codes. Some codes may require a means of disconnecting from the
AC power source installed in the xed wiring and having a contact separation of at least 0.120" (3mm) in the line and neutral poles. Make
sure the power source is OFF prior to connecting the controller. If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or a similarly quali ed person in order to avoid a hazard.
WARNING: is appliance is not intended for use by persons (including children) with reduced physical sensory, or mental capabilities,
or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person
responsible for their safety. Children should be supervised to ensure that they do not play with the appliance.
110 VAC Outdoor Models (US and Canada)
– Route power and ground wires from a power source through a conduit
Step 1
and into the EVOLUTION
Step 2 – Open the EVOLUTION
components.
Step 3 – Remove the power compartment cover to access the transformer wiring.
Remove 1/2" (12.7mm) of insulation from the wire ends.
Step 4 – Using the provided wire nuts, secure the transformer Line (black) wire
to the black power source wire, Neutral (white) to the white power source
wire and Equipment Ground wire (green) to the green power source wire.
Step 5 – Install and secure the power compartment cover.
Step 6 – Apply power to the controller.

Valve Expansion Module Installation

®
e EVOLUTION AG controller can be expanded using the optional 4-valve (A-EMOD-4) or 12-valve (A-EMOD-12) modules to add
more valves to the system.
Module Installation
Figure 9
Step 1 – Open the EVOLUTION
Step 2 – Locate the module slot
tab towards the cabinet until a positive click is achieved.
Once installed, the EVOLUTION
scheduling.
Note: If installing only one, four-station module (A-EMOD-4), it must be installed in the valve 5-8 module slot.
4
®
AG cabinet.
®
AG controller and access the internal
®
AG controller door and control panel to access the internal components.
and . Install the module by placing the bottom hooked stando s into slot
A B
®
AG controller will be able to read the additional valves and will make them available for
Figure 7
Figure 10
B
A
e click indicates that the module's retaining tab is fully engaged.
Black White Green
110 VAC Outdoor Models
B
A
and push the module
A
