Home Screen Messages

A
Title Bar
HOME
B
Main Display
01:09PM TUES
01/08
SCHEDULE A/B/C OR AUX
NEXT START 06:00AM
SCHEDULE A LOOPING
NOT WATERING TODAY
NOT ACTIVE TODAY
VALVE1 00:05
WATERING COMPLETE
SCHEDULE COMPLETE
NEXT START 06:00AM
DELAY 00:05
PULSE DELAY 00:05
RAIN HOLD
RAIN HOLD 02 DAYS
C
Message Bar
ALERT: PRESS HELP
WATER OFF 04 DAYS
SYSTEM OK
e battery icon indicates that the controller's VAC power is o and
the timer is running under battery power.
Note: e 9-VDC battery is used to allow programming, but
will not activate any valves when the VAC power supply is o .
Displays the current time, day of the week and date.
Indicates which schedule (A, B or C) or auxiliary is associated with the displayed status. If only Schedule
®
A is active, EVOLUTION AG will not display the Schedule "A", "B" and "C" or AUX. If an
displayed to the left of the schedule name, then additional schedules are active and can be viewed by
pressing the Down arrow.
e scroll down arrow
Note:
Use the Down arrow to reveal the additional message(s).
e displayed schedule type is set to Looping.
e displayed schedule will not water that day.
e displayed auxiliary schedule (AUX) will not activate that day.
Valve 1 is active with a 5 minute remaining runtime. Pressing the Right
running valve and activate the next valve (if additional valves are scheduled) in the schedule regardless of
the remaining runtime.
e displayed schedule completed its watering cycle.
e displayed auxiliary schedule (AUX) completed its cycle.
e next start time of the displayed watering schedule.
e controller is performing a valve delay before the next valve in the schedule is activated.
delay is set in the Schedule Details under the Advanced menu.
e active valve is performing a Pulse Delay (soak) before continuing operation.
in the Valve Details under the Advanced menu.
e rain sensor is activated and the schedule is delayed until the rain sensor dries out.
If Dryout Days is set, the controller will indicate Rain Hold until the number of Dryout Days are
completed. Pressing the Right
continue normal operation.
e controller detected a condition that needs user attention. Check the alert messages in the Alerts
menu under the Help/Setup function. For a list of the Alert messages and descriptions, please refer to
the Alerts section.
Scheduled watering has been suspended for the indicated days. Watering can be turned o from: 1–14
days, Remains O , or operate at the Next Scheduled Start.
e system is functioning as expected.
indicates that additional information is available.
e Looping option is set in SCHEDULES/TYPE.
arrow will deactivate the Dryout Days and the Schedule(s) will
A
HOME
01:09PM
WED
B
01/08
NEXT START 06:00AM
C
ALERT: PRESS HELP
is
arrow will deactivate the
e valve
e Pulse Delay is set
