Genie GS-1530 Maintenance Manual

Scissor lifts
Hide thumbs Also See for GS-1530:
Table of Contents

Advertisement

Quick Links

See also: Service & Repair Manual , Service Manual
Maintenance Manual -
Scissor Lifts
Slab Scissor Lifts
Rough Terrain
Scissor Lifts
Refer to the inside cover for a list of models
included in this manual.
This manual includes detailed
procedures for each
maintenance inspection.
For Repair procedures, Fault
Codes, Electrical and Hydraulic
Schematics, refer to the
appropriate Service and Repair
Manual for your machine.
Part No. 1272215
Rev B2
September 2016
