Data Editing Overview

CAUTION
When a bar code is scanned, additional information can be sent to the
host computer along with the bar code data. This combination of bar
code data and supplementary user-defined data is called a "message
string." The features in this chapter can be used to build specific
user-defined data into a message string.
There are several types of selectable data characters that can be sent
before and after scanned data. You can specify if they should be sent
with all symbologies, or only with specific symbologies.
the available elements you can add to a message string:
Figure 4-1. Breakdown of a Message String
Label ID Transmission:
Enable this option to
transmit the Label ID you
configure for the scanned
symbology.
Prefix Label ID
Product Reference Guide
Data Editing
It is not recommended to use these features with IBM
or Wand Emulation interfaces.
AIM ID Bar Code Data
AIM ID: This function is used to identify and display the
common label identifier for its symbology. When enabled,
this ID code will be transmitted before the scanned bar
code data.
00 - 20 Characters (ASCII)
Chapter 4
Figure 4-1
OR...
Label ID
shows
Suffix
4-1
