Intel® Server System R2000WF Product Family Technical Product Specification
10. OCP* Compatible Intel® Ethernet Network Adapter Support
To broaden the standard on-board feature set, the server board provides support for one of several
available Intel® Ethernet Network Adapters compatible with the Open Compute Project* (OCP*) specification.
The OCP compatible modules are mounted to a high density 120-pin connector on the server board labeled
OCP_IO_Module.
Quad Port, 1GB, RJ45
Quad Port, SFP+
Dual Port, SFP+ (WFT Boards Only)
Dual Port, 10Gb RJ45 (WFT Boards Only)
Note: Only dual port SFP+ and dual port 10GB RJ45 OCP modules are supported on Intel® Server Board
S2600WFT.
116

Figure 87. OCP module placement

Table 73. OCP* Compatible Intel® Ethernet Network Adapters
Description iPC
I357T4OCPG1P5
X527DA4OCPG1P5
X527DA2OCPG1P5
X557T2OCPG1P5
