Q u i c k
LED Indications
The lit LED indicates the selected scan pattern for hand-held and
counter-top mode. In hand-held mode, pressing the Scan Pattern
Mode Selector button selects the next pattern, and lights the
corresponding LED. (The counter-top laser pattern is selectable
only via programming bar codes.) When a bar code is successfully
decoded, all three LEDs light momentarily.
Beeper Indications
The beeper indicates the scanner's status as follows:
Beeper
3 Beeps
1 Beep
4 Beeps
Fast warble
R e f e r e n c e
Power up (or reset) has occurred.
A bar code is successfully decoded.
Transmission error. Bar code data was not
received by the host.
A programming parameter was
entered successfully.
7
Indication
