- Page 1 M i n i S c a n F a m i l y S c a n n e r s...
- Page 2 Symbol reserves the right to make changes to any product to improve reliability, function, or design. Symbol does not assume any product liability arising out of, or in connection with, the application or use of any product, circuit, or application described herein.
- Page 3 Q u i c k R e f e r e n c e Introduction The new MiniScan family is the next generation of industrial fixed scanners. The scanners provide the quickest, easiest and most flexible integration of bar code scanning into all types of OEM devices.
- Page 4 M i n i S c a n F a m i l y S c a n n e r s rectional scan pattern that reads bar codes quickly and accurately-minimizing the need for precise positioning of linear 1-D bar codes.
- Page 5 Q u i c k R e f e r e n c e Accessories • for power connection 110V power supply, US, p/n 50-14000-008 220V power supply, Europe, p/n 50-14000-009 100V power supply, Asia, p/n 50-14000-010 • for data connection Push button trigger and cable, p/n 25-04950-01 Female DB9 in straight connector to...
-
Page 6: Connecting The Miniscan
M i n i S c a n F a m i l y S c a n n e r s Female DB9 in straight connector to Synapse Adapter Cable (6 ft. straight), p/n 25-58921-01 Photo sensor trigger and cable, p/n 25-13176-01 •... - Page 7 Q u i c k R e f e r e n c e 3. Plug the output cable from the power supply into the receptacle on the end of connector near the host end of cable (USB and Syn- apse cables do not require a power supply).
-
Page 8: Aiming Tips
M i n i S c a n F a m i l y S c a n n e r s Aiming Tips Scan the Entire Symbol 1. The scan beam must cross every bar and space on the symbol. RIGHT... - Page 9 Q u i c k R e f e r e n c e will not occur until the trigger line is released and then reactivated. Level Pulse Trigger The laser is enabled and decode processing begins when the trigger line is activated. Laser remains on and decode processing continues regardless of trigger line until a good decode occurs, or until the Laser-On time expires.
- Page 10 M i n i S c a n F a m i l y S c a n n e r s Between Same Bar Code) and not decode ANY bar code for a period of time (Time Between Different Bar Codes). Consult the MiniScan Integration Guide for these bar codes.
-
Page 11: Beeper Indications
Q u i c k R e f e r e n c e Beeper Indications The beeper indicates the scanner’s status as follows: Beeper Indication 3 Beeps Power up (or reset) has occurred (MS-220x and MS-320x models only). 1 Beep A bar code is successfully decoded. -
Page 12: Led Indicators
M i n i S c a n F a m i l y S c a n n e r s LED Indicators Indication Scanner is on. Green A bar code is successfully decoded. Laser Patterns Depending on the configuration, the MiniScan scanner can emit one of five laser patterns: •... - Page 13 Q u i c k R e f e r e n c e • Semi-omnidirectional Scan Pattern (MS-220x, MS-320x) The semi-omnidirectional pattern is an alter- native to the full omni-directional pattern, that scans highly truncated 1-D and RSS bar codes. The bar code must be presented horizontally with no more than a 20 tilt.
- Page 14 M i n i S c a n F a m i l y S c a n n e r s formance on 1-D, PDF417, RSS, and Composite codes. Stage 1: Stage 2: • High Density Single Scan Line (MS-220x, MS-320x, MS-90xHS) The single scan line appears as a "mini"...
-
Page 15: Bar Codes
Q u i c k R e f e r e n c e • True Single Scan Line The MS-120x, MS-90x, and MS-80x are 1-D scanners, and as such emit a single scan line. Bar Codes Following are some frequently used bar codes for some of the MiniScan scanners. - Page 16 M i n i S c a n F a m i l y S c a n n e r s Always Raster Semi-omnidirectional Pattern...
-
Page 17: Troubleshooting
Q u i c k R e f e r e n c e Slab Pattern Troubleshooting Problem Possible Cause Possible Solutions No red LED No power to the Check the system power. or nothing scanner. Confirm that the correct host happens interface cable is used. - Page 18 Check that the communication communication parameters (baud rate, parity, parameters. stop bits, etc.) are set properly. Bar code symbol Check the symbol to make sure is unreadable. it is not defaced. Try scanning similar symbols of the same code type. Inappropriately Remove the scanner from the hot environment.
-
Page 19: Regulatory Information
R e f e r e n c e Regulatory Information All Symbol devices are designed to be compliant with rules and regulations in locations they are sold and will be labeled as required. Any changes or modifications to Symbol Technologies equipment, not expressly approved by Symbol Technologies, could void the user's authority to operate the equipment. -
Page 20: Power Supply
S c a n n e r s Scanner Labeling Power Supply Note: Use only a Symbol-approved power supply 50-14000- 008, 50-14000-009, 50-14000-010 output rated 5.2Vdc and minimum 0.650A. The power supply is certified to EN60950 with SELV outputs. Hinweis: Benutzen Sie nur eine Symbol Technologies genehmigt Stromversorgung 50-14000-008, 50-14000- 009, 50-14000-010 in den Ausgabe: 5.2Vdc und... -
Page 21: Radio Frequency Interference Requirements
Q u i c k R e f e r e n c e In accordance with Clause 5, IEC 825 and EN60825, the following information is provided to the user: ENGLISH HEBREW CLASS 1 CLASS 1 LASER PRODUCT CLASS 2 LASER LIGHT DO NOT STARE INTO BEAM CLASS 2 LASER PRODUCT... -
Page 22: Radio Frequency Interference Requirements - Canada
Cet appareil numérique de la classe B est conforme à la norme NMB-003 du Canada. Marking and European Economic Area (EEA) Statement of Compliance Symbol Technologies, Inc., hereby declares that this device is in compliance with all the applicable Directives, 89/336/ EEC, 73/23/EEC. A Declaration of Conformity may be obtained from http://www2.symbol.com/doc/. -
Page 23: Warranty
Product result from normal wear and tear, misuse, negligence, improper storage, water or other liquids, battery leakage, use of parts or accessories not approved or supplied by Symbol, or failure to perform operator handling and scheduled maintenance instructions supplied by Seller; (iii) which has been subjected to unusual physical or electrical stress, abuse, or accident, or forces or exposure beyond normal use within the specified operational and environmental parameters set forth in the applicable Product specification;... -
Page 24: Service Information
+1-954-255-2610 Outside US Europe/Mid-East Contact local distributor or call Distributor Operations +44 208 945 7360 Customer support is available 24 hours a day, 7 days a week. 72-58809-01 Revision B — May 2003 Symbol Technologies, Inc. One Symbol Plaza, Holtsville, N.Y. 11742-1300...
