There is one route added for each Ethernet interface in the system. For example, if there two

interfaces named lan and wan with the IPv4 addresses 192.168.0.10 and 193.55.66.77, this will

result in the following routes existing:

When the system receives an IP packet whose destination address is one of the interface IPs, the

packet will be routed to the core interface. In other words, it is processed by NetDefendOS itself.

There is also a core route added for all multicast addresses:

To include the core routes when the active routing table is displayed, it is necessary to explicitly

specify that all routes are to be displayed. This is shown in the example below.

Example 4.3. Displaying the Core Routes

This example illustrates how to display the core routes in the active routing table.

Command-Line Interface

gw-world:/> routes -all

Flags Network

----- ------------------ ---------- ------------- -------- ------

213.124.165.181

192.168.0.0/24

213.124.165.0/24

Web Interface

Select the Routes item in the Status dropdown menu in the menu bar

Check the Show all routes checkbox and click the Apply button

The main window will list the active routing table, including the core routes

Tip: Understanding output from the routes command

For detailed information about the output of the CLI routes command, refer to the

separate CLI Reference Guide.

213.124.165.1

192.168.0.10

193.55.66.77

Local IP Metric
