Chapter 1 Assigning the Switch IP Address and Default Gateway
TFTP Server Configuration (on UNIX)
The TFTP server base directory is set to /tftpserver/work/. This directory contains the network-confg file
used in the two-file read method. This file contains the hostname to be assigned to the switch based on
its IP address. The base directory also contains a configuration file for each switch (switcha-confg,
switchb-confg, and so forth) as shown in this display:
prompt> cd /tftpserver/work/
prompt> ls
network-confg
switcha-confg
switchb-confg
switchc-confg
switchd-confg
prompt> cat network-confg
ip host switcha 10.0.0.21
ip host switchb 10.0.0.22
ip host switchc 10.0.0.23
ip host switchd 10.0.0.24
DHCP Client Configuration
No configuration file is present on Switch A through Switch D.
Configuration Explanation
In Figure
•
•
•
•
•
Switches B through D retrieve their configuration files and IP addresses in the same way.

Configuring the DHCP Auto Configuration and Image Update Features

Using DHCP to download a new image and a new configuration to a switch requires that you configure
at least two switches: One switch acts as a DHCP and TFTP server. The client switch is configured to
download either a new configuration file or a new configuration file and a new image file.
Configuring DHCP Autoconfiguration (Only Configuration File)
Beginning in privileged EXEC mode, follow these steps to configure DHCP autoconfiguration of the
TFTP and DHCP settings on a new switch to download a new configuration file.
Command
Step 1
configure terminal
Step 2 ip dhcp poolname
Step 3 bootfile filename
OL-25303-03
1-3, Switch A reads its configuration file as follows:
It obtains its IP address 10.0.0.21 from the DHCP server.
If no configuration filename is given in the DHCP server reply, Switch A reads the network-confg
file from the base directory of the TFTP server.
It adds the contents of the network-confg file to its host table.
It reads its host table by indexing its IP address 10.0.0.21 to its hostname (switcha).
It reads the configuration file that corresponds to its hostname; for example, it reads switch1-confg
from the TFTP server.
Purpose
Enter global configuration mode.
Create a name for the DHCP Server address pool, and enter DHCP
pool configuration mode.
Specify the name of the configuration file that is used as a boot image.
Catalyst 3750-X and 3560-X Switch Software Configuration Guide
Assigning Switch Information
1-11
