PART LIST—Model No. PFIVEX79612.0
Item Description
1 Main frame
2 Front stabilizer tube
3 Rear stabilizer tube
4 Vertical tube
5 Handlebar
6 Saddle supporting tube
7 Saddle
8 Tension control cable
9 Meter
10 Pedal
11 End cap
12 End cap
13 Bolt M8×73
14 Arc washer Φ20×d8.5×R30
15 Acorn nut M8
16 Sensor wire
17 Square end cap
18 Bolt M8×15
19 Flat washer D10
20 Nut M10
21 Sensor connective wire
22 Flat washer D8
23 Fix Pipe
24 Handle cover
25 Round cap
26 Foam grip
27 Pulse wire
28 Knob bolt
29 Bushing
30 Bolt
31 Horizontal seal post
32 U - hinge block
33 Flat washer D5
34 Screw M4X12
35 Crank
36 Motor
37 Screw M4×15
38 Washer
Qty. Item Description
1 39 Circle
1 40 Crank cover a
1 41 Chain cover
1 42 Screw ST4.2×18
1 43 Spring washer D17
1 44 Screw ST3×10
1 45 Crank cover b
1 46 Nylon nut M6
1 47 Bearing 6003
1 each 48 Belt tray
2 49 Axle
2 50 Belt
4 51 Flywheel
8 52 Flywheel axle
4 53 Nut M10×1
1 54 Idler pulley
2 55 Nut M10×1.25
4 56 Idle wheel bracket
1 57 Spring
1 58 Hex nut M6
1 59 Hex bolt M6×55
1 60 Bolt M6×15
1 61 Flat washer D6
1 62 Spring washer D6
2 63 Spring washer D12
2 64 Magnet plate axle
2 65 Magnet plate
1 66 Magnet
1 67 Spring
1 68 Belt pulley
1 69 Bolt M6×50
1 70 Hex thin nut M10×1
2 71 Fix Pipe
2 72 Bearing 6000
1 each 73 Adapter
1 74 Nylon nut M8
4 75 Spring washer D8
2
19
Qty.
2
2
1each
10
2
2
2
3
2
1
1
1
1
1
1
1
2
1
1
4
1
5
2
2
2
1
1
8
1
1
2
2
1
2
1
2
1
