Configuration 2 - InFocus INF6502WB User Manual

Configuration 2

OSD Turn Off: controls how many seconds the OSD menu remains on the screen Range: 5-120 (seconds). (Default: 10)
Freeze: When enabled, freezes the image which is currently displayed. Options: On and Off (default).
OSD H Position: adjusts the horizontal position of the OSD menu. Range: 0-100. (Default: 50)
OSD V Position: adjusts the vertical position of the OSD menu. Range: 0-100. (Default: 50)
OSD Rotation: rotates the image to either a landscape or portrait mode. Options include: Portrait and Landscape.
Monitor Information: This read-only submenu displays the model name, serial number, operation hours, and software
version.
INF6502WB User Guide
CONFIGURATION 2
OSD TURN OFF
FREEZE
OSD H POSITION
OSD V POSITION
OSD ROTATION
MONITOR INFORMATION
< >
Sel Adjust Enter
10
OFF
50
50
PORTRAIT
Back Quit
Page 33
