InFocus INF6502WB User Manual page 15

Remote buttons
INF6502WB User Guide
Power: Switches the power on or puts the monitor into Standby.
POWER
Home: Changes the active source back to the embedded PC.
HOME
Input: Toggles the Input Source menu on and off, which allows the user to
INPUT
change sources.
Menu: Turns the OSD menu on and off.
MENU
Resize: Switches between screen modes. Modes vary based on the source.
RESIZE
PiP On/Off: Turns the PiP function on and off and changes the PiP
PIP
ON/OFF
configuration between two active PiP sources. Options include corner and
side-by-side configurations (50%-resized, 25%-resized and 50%-fullscreen),
depending on source types.
PiP Input: Switches the PiP window source. Note: The PiP window is not
PIP
INPUT
visible when a secondary source has not been selected.
PiP Swap: Switches the position of the main and secondary sources.
PIP
SWAP
PiP Position: Moves the PiP window position from corner to corner (upper left,
PIP
POSITION
upper right, lower left, lower right).
PiP Audio: Turns the PiP audio mix on and off.
PIP
AUDIO
Brightness: Opens the Brightness OSD menu. Use the right and left arrow
buttons to adjust.
BRIGHTNESS
Contrast: Opens the Contrast OSD menu. Use the right and left arrow buttons
to adjust.
CONTRAST
Back: Returns the user to the previous menu.
BACK
Left, Right, Up, Down Arrows and OK: Use these buttons to navigate through
OK
and make changes to the Onscreen Menu features.
Info: Displays source information.
INFO
i
Vol up: Increases the audio volume.
VOL UP
Vol down: Decreases the audio volume.
VOL DOWN
Mute: Switches the audio on or off.
MUTE
Page 13
